BM122/123/133/221/231
HOST COMPUTER SYSTEM
3.3 C commands
E35HEC-4A-181-B0
3.3-8
C1Z command
Used to read out feeder information.
Command format: C1Z∗∗∗
∗∗∗ Code Application
∗∗∗
Description
000 After read-out, feeder information on the machine is not cleared.
900 After read-out, feeder information on the machine is cleared.
Command sequence
Host computer system Equipment
C1
+ Production management
type
(1)
(2) D0 + Production
management data
A0 (Requests the next data) (1) End
(1) A2 (Data transfer end)
(1) No data type (2) Data-attached type
Ex.: C1M000 command
Command C1M000
Data size 0
Terminator 0
Terminator 0
Terminator 0
BM122/123/133/221/231
HOST COMPUTER SYSTEM
3.3 C commands
E35HEC-4A-181-B0
3.3-9
Ex.: D0 command (Data response)
Command D0
Data size
685 (No. of characters from %HEADER to ∗[CR][LF])
Data %HEADER[CR][LF]
NAME=M$$$$$$$$$$$$$$$[CR][LF]
MACHINE=BM[CR][LF]
MNAME=BM[CR][LF]
START=2003/01/01 14/18/48[CR][LF]
END=2003/01/01 14/45/35[CR][LF]
PANASONIC=3010[CR][LF]
%MANAGEMENT[CR][LF]
PRODUCTPLAN1=0000000[CR][LF]
PRODUCTPLAN2=0000000[CR][LF]
PRODUCT1=0000005[CR][LF]
|| (Omitted)
%CHARACTER[CR][LF]
PICKUP_RATE=075.75[CR][LF]
MOUNT_RATE=075.75[CR][LF]
PARTS_EXHAUST_C=0000000[CR][LF]
PARTS_EXHAUST_T=0000/00/00[CR][LF]
PICKUP=0000066[CR][LF]
MOUNT=0000050[CR][LF]
PICKUP_ERR=0000015[CR][LF]
PICKUP_MISS=0000001[CR][LF]
RECOG_ERR1=0000000[CR][LF]
RECOG_ERR2=0000000[CR][LF]
BRECOG_ERR1=0000000[CR][LF]
BRECOG_ERR2=0000000[CR][LF]
∗ [CR][LF]
Terminator 0
Terminator 0
Terminator 0
== For production management information formats, refer to ‘Prg. / DATA FORMAT’.
BM122/123/133/221/231
HOST COMPUTER SYSTEM
3.3 C commands
E35HEC-4A-181-B0
3.3-10
3.3.5 C1RP Command (Program List)
Item Description
Command name Program list
COM port used Port 1
Data format
Item Description
Command field C1RP
Data size field 0
Data field None
Command sequence
Host computer system Equipment
C1RP (1)
(2) D0 + Program list
A0 (Requests the next data) (1) End
(1) A2 (Data transfer end)
(1) No data type (2) Data-attached type
Program list is sent in the following format.
Data registered or revised yy/mm/dd
Ex.: January 09, 2000 00/01/09
Program name Pxxx...xxx (Fixed at
15 characters)
Program names less than 15 characters will be padded with spaces.
Ex.: D0 command
Command D0
Data size
81 (No. of characters from the beginning of data to ∗[CR][LF])
Data 03/01/30PABC [CR][LF]
03/02/01PDEF [CR][LF]
03/02/02PGHI [CR][LF]
∗ [CR][LF]
Terminator 0
Terminator 0
Terminator 0
