BM122/123/133/221/231
HOST COMPUTER SYSTEM
3.3 C commands
E35HEC-4A-181-B0
3.3-6
Setting the program name
Data Identifier Name
Product program P
15 characters
Part library L None
Mark library B None
Nozzle library V None
Supply library Y None
Machine data G None
Command sequence
Host computer system Equipment
C1
+ Program name
(1)
(2) D0 + data
A0 (Requests the next data) (1) End
(1) A2 (Data transfer end)
(1) No data type (2) Data-attached type
Ex.: D0 command
Command D0
Data size
256 (No. of characters from %HEADER to ∗[CR][LF])
Data %HEADER[CR][LF]
NAME= P123456789ABC[CR][LF]
MACHINE=BM[CR][LF]
MNAME= BM[CR][LF]
CREATE=2003/01/01[CR][LF]
REVISE=2003/01/01[CR][LF]
TYPE=ABS[CR][LF]
BLOCK=00001[CR][LF]
MLSTEP=00000
PANASONIC=3010[CR][LF]
COMMENT=[CR][LF]
%BOARDDATA
&BOARD
BD(0,0,0)
DM(0,0,0)
&CONVEYOR
TP0CS1TSF1TSR1
%POFFSET[CR][LF]
X0Y0HM0F1[CR][LF]
%NCDATA[CR][LF]
N1X0Y0W0V0Z1PN( )C( )H0M000000T000000PW0BK0GR0DP0/0[CR][LF]
∗ [CR][LF]
Terminator 0
Terminator 0
Terminator 0
== For program data formats, refer to ‘Prg. / DATA FORMAT’.
BM122/123/133/221/231
HOST COMPUTER SYSTEM
3.3 C commands
E35HEC-4A-181-B0
3.3-7
3.3.4 C1M, C1N and C1Z Commands
(Uploading Production Management Information)
Item Description
Command name Uploading production management
COM port used Port 1
Data format
Item Description
Command field C1 + Kind of production management to be uploaded
Data size field 0
Data field None
C1M command
Used to read out production management information (grand total).
Command format: C1M∗∗∗
∗∗∗ Code Application
∗∗∗
Description
000
After read-out, production management information (machine/mount information of
grand total) on the machine is not cleared.
900
After read-out, production management information (machine/mount information of
grand total) on the machine is cleared.
=REMARKS=
Among the production information (grand total), nozzle information and feeder information will not be cleared
by the C1M900 command.
Use C1N900 and C1Z900 commands respectively to clear these data.
C1M∗∗∗P command
Used to read out production management information (current total).
Command format: C1M∗∗∗P
∗∗∗ Code Application
∗∗∗
Description
000
After read-out, production management information (machine/mount/nozzle/feeder
information of current total) on the machine is not cleared.
900
After read-out, production management information (machine/mount/nozzle/feeder
information of current total) on the machine is cleared.
=REMARKS=
Among the production information (current total), nozzle information and feeder information will be cleared at
the same time by the C1M900P command.
Note that its function differs from that of the C1M900 command.
C1N command
Used to read out nozzle information.
Command format: C1N∗∗∗
∗∗∗ Code Application
∗∗∗
Description
000 After read-out, nozzle information on the machine is not cleared.
900 After read-out, nozzle information on the machine is cleared.
BM122/123/133/221/231
HOST COMPUTER SYSTEM
3.3 C commands
E35HEC-4A-181-B0
3.3-8
C1Z command
Used to read out feeder information.
Command format: C1Z∗∗∗
∗∗∗ Code Application
∗∗∗
Description
000 After read-out, feeder information on the machine is not cleared.
900 After read-out, feeder information on the machine is cleared.
Command sequence
Host computer system Equipment
C1
+ Production management
type
(1)
(2) D0 + Production
management data
A0 (Requests the next data) (1) End
(1) A2 (Data transfer end)
(1) No data type (2) Data-attached type
Ex.: C1M000 command
Command C1M000
Data size 0
Terminator 0
Terminator 0
Terminator 0
