Station Software 709.1 / Installation Manual Ausgabe 05/2016 Edition
12
3.7.2 X-Series Placement Machines
► Install the 709.1 station software, see chapter 5.
► If necessary, install the Coplan computer or feeder computer software, see chapter 6.
► Shut down the machine.
► Remove the tables.
► Switch on the machine again and perform the eSW download.
► Reboot the machine.
► Place the tables. The eSW download for the feeders starts automatically.
► Save the calibration data for the placement heads in the EEPROM (see section 7.11).
► Perform a component sensor calibration if a CPP placement head is used for 0201/01005
placement.
► Perform the closed vacuum calibration if Twin Heads are used.
► Start the production.
3.8 Upgrading from 701.xx Software Versions (X4I Placement
Machine)
► If necessary, perform an upgrade to the Microsoft Windows Embedded Standard 7 (WES7,
32-bit or 64-bit) operating system. See sections 4.1.1 and 5.3.1.
► Download the SIPLACE_UpgradePreparation.exe file (directory Upgrade_Preparation) from the
installation CD and execute the file.
► Reboot the machine and perform an eSW download for the placement heads.
► Install the 709.1 station software, see chapter 5.
► If necessary, install the Coplan computer or feeder computer software, see chapter 6.
► Shut down the machine.
► Remove the tables.
► Switch on the machine again and perform the eSW download.
► Reboot the machine.
► Place the tables.
The eSW download for the feeders starts automatically.
► Save the calibration data for the placement heads in the EEPROM (see section 7.11).
► Perform a component sensor calibration if a CPP placement head is used for 0201/01005
placement.
► Perform the closed vacuum calibration if Twin Heads are used.
► Calibrate the nozzle changer.
► Calibrate the conveyor.
► Start the production.
Station Software 709.1 / Installation Manual Ausgabe 05/2016 Edition
13
3.9 Upgrading from 60x Software Versions (X-Series Placement
Machines)
► Please contact the SIPLACE Service before upgrading from the 60x software version to 709.x.
The staff will advise you on the required modules and necessary steps.
Station Software 709.1 / Installation Manual Ausgabe 05/2016 Edition
14
4 Requirements
4.1 Software Components of SIPLACE Series X, X S, SX, DX, CA and
TX
4.1.1 Station
The station only uses one of the following operating system configurations on the station computer
and Coplan computer/feeder computer:
– Microsoft Windows Embedded Standard 7 (WES7, 32-bit or 64-bit)
The station computer has to be equipped with at least 2 GB memory with WES 7, 32-bit and 4 GB
memory with WES7, 64-bit respectively. If necessary, station computers in the field have to be
exchanged or upgraded with a memory extension. Please refer to the Technical Information
TI2014-09E04.
4.1.2 Machine Components
The following versions of other machine components are required for the station software to
function correctly:
SIPLACE station software SIPLACE Vision SIPLACE Pro
Version 709.1 Version 532 Version 13.1
*)
*)
in compatible mode: SIPLACE Pro 12.x
CAUTION
The functional statuses of the station computer, Vision computer and SIPLACE Pro
software must be compatible, as specified above. Another configuration is not supported.
