Station Software 709.1 / Installation Manual Ausgabe 05/2016 E dition 36 NOTICE The Coplan comput er software and feeder comput er software can not be combined wit h each other! The installation of the respective sof twa…
Station Software 709.1 / Installation Manual Ausgabe 05/2016 Edition
35
6.1.1 Selecting the Additional Vision Computer
The SIPLACE Choice Center dialog box opens.
Figure 6-1: "SIPLACE Choice Center" dialog box
► Click the Additional VISIONPC button.
The following dialog box opens:
Figure 6-2: Selecting computer / software
► Click the VISIONPC for COPLAN button to install the Coplan computer software.
Or:
► Click the VISIONPC for BulkFeeder X button to install the feeder computer software.
Station Software 709.1 / Installation Manual Ausgabe 05/2016 Edition
36
NOTICE
The Coplan computer software and feeder computer software cannot be combined with
each other!
The installation of the respective software continues with the welcome screen.
6.1.2 Welcome
Figure 6-3: Welcome
► Click the Next button.
The necessary files are installed on the Vision computer.
6.1.3 Finalizing the Installation
NOTICE
The STATUS only lists the programs that have just been installed.
If errors occurred during installation, the status is indicated by the Error button being
displayed next to the program name instead of the Ok button.
► If you wish to read the log of the installation of any program, click the Ok (or Error) button next
to the name of the program. The Notepad editor is started and displays the appropriate file.
Station Software 709.1 / Installation Manual Ausgabe 05/2016 Edition
37
Figure 6-4: Finalizing the installation
► Click on the Finish button.
CAUTION
► Wait a few seconds after you have clicked the Finish button, before you shut down
and switch off the computer / the machine!
As some installation steps are not performed until the end of the installation by the
InstallShield, the installation might otherwise be incomplete what may cause
problems during further installations.
NOTICE
To establish the connection between the SIPLACE Coplan computer software or feeder
computer software and the SIPLACE station software after the installation has been
completed, the Vision computer and the station computer must first be shut down and
the machine then switched off completely.
► To do this, open the Start menu on the station computer and select All Programs – SIPLACE
– Shutdown Vision_SR (all).
► Switch the machine off when the computer systems have shut down.
► Then, switch the machine on again. This reboots the Vision computer and the station computer.
