Station Software 709.1 / Installation Manual Ausgabe 05/2016 E dition 20 Name SIMATIC MicroBox 427D CPU / clock frequen cy Intel ® Core (TM) / 1,6 GHz RAM 4 GB Harddisk Yes (80 GB SSD) External DVD drive Yes Internal DVD…

Station Software 709.1 / Installation Manual Ausgabe 05/2016 Edition

Name SIMATIC BoxPC 627C

CPU / clock frequency Intel® Celeron® P4505 / 1.87 GHz

RAM 2 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 4-5: Station computer hardware SIPLACE X-, X S-, SX- and DX-series

Name SIMATIC BoxPC 827C

CPU / clock frequency Intel® Core

(TM)

i3 / 2.13 GHz

RAM 2 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 4-6: Station computer hardware SIPLACE X-, X S-, SX-, DX- and CA-series

Name I-Base ABP 402-A

CPU / clock frequency Intel® Celeron® CPU 1020E / 2,2 GHz

RAM 4 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 2

USB interfaces and external USB hub Yes

Network 2x 1000 MBit

Table 4-7: Station computer hardware SIPLACE SX-series

Station Software 709.1 / Installation Manual Ausgabe 05/2016 Edition

Name SIMATIC MicroBox 427D

CPU / clock frequency Intel® Core

(TM)

/ 1,6 GHz

RAM 4 GB

Harddisk Yes (80 GB SSD)

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 1000 Mbit

Table 4-8: Station computer hardware SIPLACE X-Series S and TX-series

4.2.1.1 Station Computer/Coplan Computer with 3D Coplan Sensor

Optionally, the coplanarity module with the 3D coplan sensor (type 37) can be installed in the

SIPLACE X-series, SX1/SX2 (V2) and X-series S placement machines.

Detailed information on the 3D coplanarity module can be found in the corresponding Assembly

Instructions, item numbers [00195344-xx] (for X-series), [00196842-xx] (for SX1/SX2) und

[00197395-xx] (for X-series S).

4.2.1.2 Station Computer/Feeder Computer for SIPLACE BulkFeeder X

Optionally, the SIPLACE BulkFeeder X can be set up and installed at the X-series, X-series S,

X4 S micron and SX1/SX2 (V2) placement machines.

Detailed information on the SIPLACE BulkFeeder X can be found in the SIPLACE BulkFeeder X

Operating Manual, item no. [00198045-xx].

Station Software 709.1 / Installation Manual Ausgabe 05/2016 Edition

4.3 Network Configuration

Station

computer

Coplan computer /

feeder computer

Private network between

station computer and Coplan

computer / feeder computer

SIPLACE LAN

SIPLACE Pro

Figure 4-1: Network connections between the machine and SIPLACE Pro

In two-computer operation a separate private network is set up between the station computer and

the Coplan computer or feeder computer via a subnet mask.

Fixed IP addresses for the station computer, Coplan computer or feeder computer can thus be

assigned for all SIPLACE machines. These IP addresses are not known outside the private

network, for instance in the SIPLACE LAN.

These IP addresses need not be further configured by the operator while the station software is

being installed.

Please also refer to chapter 6.
