Maintenance tasks for CPP
Tools, Consumables, Spare and Wear Parts
Maintenance Manual SIPLACE Placement Heads CPP, C&P20, Twin 19
Clamping ring mount front plate CPP 03077754- xx X*
Antistatic tweezers, type Bernstein 5-192 00377393- xx X
Antistatic tweezers, type Bernstein 5-195 00377394- xx
Tweezers for filter disk, anti-magnetic 03092319- xx
Tweezers, blunt 145 mm size 3 mm 00376493- xx X
Tweezers 150 mm pointed, angled 00096487- xx
TorqueVario-S screwdriver (1.0-5.0 Nm) 03078400- xx X
Bit holder for TorqueVario screwdriver 03078706- xx X*
Bit extension 150 TX20 03073256- xx
Bit extension 150 Allen key 2.5 03043440- xx
Allen key set 0.7 - 2 mm 00320265- xx X
Torx Allen screwdriver TX8 03080081- xx
Calibration tool version 3 03010565- xx
Calibration tool version SST23 03034148- xx
Nozzle assembly type 2057 03070280- xx
Set of Allen keys 00376492- xx
Set of fork wrenches 00096290- xx
Component sensor protective cap 03080984- xx
Torque wrench snap off, 0.2 – 2 Nm 03090000- xx
Jaw plug tool 1-17 for torque wrench 03090001- xx
Torque screwdriver 20-120 Ncm 00386253- xx X
Torque interchangeable blades 2.5 mm, hexagonal 03090019- xx X
Diagonal cutter electronics, size 110 00318673- xx X*
Torque interchangeable blades 3 mm hexagonal 03109522- xx X
Torque screwdriver ESD 0.1-0.6 Nm 00386132- xx X
Torque interchangeable blades 2 mm, hexagonal 00386136- xx X
Tweezers filter disk CPP 03046190- xx X*
Open-ended wrench, size 17 03109304- xx X*
Bit WS 1.5 with spherical head 03078707- xx X*
Philips inset PH1 03075861- xx
Wrench socket size 8
Additionally required documentation Item no. HMK
If required, service manual for removal and installation of placement
head in your machine.
► Note: You need more tools etc.
If required, technical information "Maintenance level for DP unit on
CPP head incorrect in the software"
DE: TI2013-06D02
EN: TI2013-06E02
If required, technical information "Defective silencer at CPP head". DE: TI2013-04D01
EN: TI2013-04E01
If required, assembly instructions "Universal placement head
mounting rack"
00196371- xx
Checklist for head maintenance kit CPx DE+EN 00197488- xx
Tools Item no. HMK
Maintenance tasks for CPP
Preparatory Steps
20 Maintenance Manual SIPLACE Placement Heads CPP, C&P20, Twin
3.3
3.3 Preparatory Steps
Preparatory Steps
Preparing the Head Mount
Preparing the Head Mount
► Assemble the head mount. For details, refer to the assembly instructions "Universal placement head
mounting rack" [DE+EN: 00196371-xx].
Vacuum test
► Set the nozzles for the current nozzle configuration down in the nozzle changer.
► Before you begin maintenance work, perform a vacuum test. Use the calibration nozzles 2057 for
this. If vacuum value irregularities occur at certain segments, take a closer look at these during main-
tenance work. Note down the numbers of the problematic segments for later reference.
Spare parts Item no. HMK
Holding circuit assembly for CPP version <= 04 03055424- xx
Holding circuit assembly for CPP version >= 05 03081381- xx
Silencer assembly CPP 03061440- xx
Nozzle magazine type 20xx 03066107- xx
CAUTION
Perform a software update if required
Due to an incorrect value in the station software, the request to perform maintenance may be
shown too late or not at all.
► From SW 706.01 SP2 (or 705.05.SP2) onwards, the request is shown correctly.
► For older software, perform a software update. For details, refer to the technical information
"Maintenance level for DP unit on CPP head incorrect in the software" [DE: TI2013-06D02]
[EN: TI2013-06E02].
CAUTION
ESD
► Connect the assembly mount ESD connection to an ESD connection at the workplace.
► Always observe the ESD regulations described in the user manual.
NOTICE
Error messages
The following error messages could indicate that the holding circuit is dirty:
► During the reference run: "FM 30614 Holding circuit vacuum for nozzle of specified type too
small"
► During placement: "FM 30565 Measured pressure in holding circuit is too low"
Maintenance tasks for CPP
Preparatory Steps
Maintenance Manual SIPLACE Placement Heads CPP, C&P20, Twin 21
Preparing the Placement Head
► Dismantle the placement head and remove it from the placement machine. For details, refer to the
service manual for your machine.
Use the FHE function if possible.
► Fit the placement head onto the head mount.
Dismantling the Front Plate
► Dismantle the front plate. For details, refer to the "Service manual CPP".
Multipette
Multipette
► Prepare the multipette. For more information about this, read section "9 Handling the Multipette"
[ ➙ 89]. Also observe the following instructions:
Color-coding of dosage devices and lubricants
► Fit the protective cap onto the component sensor for
the placement head.
CAUTION
Do not combine lubricants!
Contamination (combination) of lubricants can affect the service life of the bearings!
► Only use the combitip specifically marked for each lubricant, to avoid combining the lubri-
cants.
Color Lubricant Application
Black Black combitip
Klüberalfa DH 3-100
Driver bearing
Blue Blue combitip
Lubcon Thermoplex ALN 1001/00 50 ml
Segment guide/Z linear guide
Yellow Yellow combitip
Klüber oil GEM 1 220 N
Support roller
Green Green combitip
Isoflex Topas NCA 5051
Star bearing
