6-3 Tape feeders
6-3-1 Tape feeder for an electric bank
Electric tape feeders (ETFs) use a motor as the drive system, and this allows the machine to suppress
vibrations and supply each component in a stable posture. Moreover, as compared to a conventional
mechanical feeder, its utilization rate gets higher thanks to its features such as simplification of feed pitch
change operation and support of a tape splicing function.
1. List of specifications
RF series Electric feeder
Product code
Tape type
Feed pitch (mm)
Supported
tape width
Supported
component
emboss depth
Remarks
Paper Embossed
RF04AS ― ○ 1 mm 4 mm 1.1mm or less
4 mm size in
general
RF08AS ○ ○ 1/2/4 mm 8 mm
3.5 mm or
less
8 mm size in
general
RF12AS － ○ 2/4/8/12 mm 12 mm 17 mm or less
12 mm size in
general
RF16AS － ○ 4/8/12/16 mm 16 mm 17 mm or less
16 mm size in
general
RF24AS － ○
4/8/12/16/
20/24 mm
24 mm 17 mm or less
24 mm size in
general
RF32AS － ○
4/8/12/16/
20/24/28/32 mm
32 mm 26 mm or less
32 mm size in
general
RF series Electric feeder
Product code Voltage
Maximum
allowable current
Outside dimensions
Mass
Total length L
Height H
RF04AS
DC24V
DC5V
3.5A
(DC24V)
0.15A
(DC5V)
530mm 300mm
1.35kg
RF08AS 1.3kg
RF12AS
1.5A
(DC24V)
0.15A
(DC5V)
1.8kg
RF16AS
1.8kg
RF24AS 2.2kg
RF32AS
1.8A
(DC24V)
0.15A
(DC5V)
3.0kg
2. Options
① Tape cutting jigs A and B (scissors)
When you use the dedicated scissors to cut a tape in order to splice tapes, you can correctly
and quickly position a tape feeder being used for PWB production with a tape feeder whose
tape is to be connected.
- Tape cutting jig A: supports feeding pitches 4, 12, 20, 28, 36, 44 and 52
- Tape cutting jig B: supports feeding pitches 8, 16, 24, 32, 40, 48 and 56.
② Joint tape
This is a tape that splices an old tape reel and a new tape reel.
A dedicated type is provided for each tape width.
27
6-3-2 Tape reel mounting base
This is a mounting base for attaching a tape reel onto a tape feeder. Since it allows you to attach a tape
reel on a tape feeder while keeping the tape feeder in position, the tape attachment capability is
improved and it also functions to prevent a tape feeder from falling.
Specifications
1. RF-FSS
Feeder setup stand RF
Power supply
Input side: 90 to 250 V AC
Output side: DC 24V, DC5V
Frequency Input side: 50/60 Hz
Current
Input side: 1.4A / 0.7A (100V/200V) typical
Output side:3 A (maximum)
Outside dimensions
L=550mm
W=470mm
H=950±50mm
Mass
25kg (Equipped with a stand)
Number of feeders to which
power can be supplied
1
* The outside dimensions/mass described above indicated values to be applied when any feeder is
not mounted on the base.
6-3-3 Electric Trolley Power Station
Power supply for an electric feeder exchange trolley
This is an optional unit that supplies power to a feeder exchange trolley for an electric feeder in order to
set a tape onto an electric tape feeder (ETF type) without removing the feeder from the electric feeder
exchange trolley. This shall be used for an electric feeder exchange trolley only.
Model PW02
Power supply 100 – 120 V/200 – 240 V AC
Frequency 50/60 Hz
Rated power 600 VA
Output voltage DC 24 V ± 10 %
Output current 18.0 A (Max)
External dimensions (L/W/H) 308mm × 290mm × 540mm
Mass Approximately 16 kg
Connection feeder exchange
trolley number
2
Remarks
Equipped with a MPC-CAN.
It can communicate with the IFS-NX server by connecting
a LAN cable.
* When using Electric Trolley Power Station, Electric Trolley Power Station and TROLLEY POWER
CABLE ASM are needed.
28
7. Control System
7-1 Control
7-1-1 Saving a program
This machine saves a production program onto the SSD in the main unit.
When you use a USB port, you can store it on an external storage device also.
7-1-2 Production program capacity
Maximum number of circuits per board: 1,200 for a matrix board
Maximum number of placement positions per board: 10,000 positions
Maximum number of component data records: maximum number of component types that
can be placed on the machine
Maximum number of pick data records: same as the above.
Maximum number of marks that can be registered to the machine: 1,250 sets of BOC marks
7-2 Operation mode
The following three operation modes are available during PWB production.
• Normal
The machine produces PWBs in Normal mode.
• Trial
The machine produces PWBs in Trial mode.
• Pass-through
The machine transports boards from an upstream device to a downstream device only without
placing any component on a board.
