Maintenance Manual | 37 1.2.9. C ONVEYOR H EIGHT G UIDE Figure 1-10. Height Guide Item Description Item Description 1 Sp r i n g 4 Height Guide Cylinder 2 Cylinder Shaf t Joint 5 S peed Controller 3 Height Joint Bracket …
36 | KY-8030 2
3DSolderPasteInspectionSystem
Version 1.0
KOH YOUNG TECHNOLOGY INC.
Connector.
4. AssemblenewUp/DownLimitSensortoFixRailandassembleConnectorcheckingI/O
Number.
5. Disassemble Rail Fix Bracket from Fix Rail and disassemble Up/Down Cylinder from
Up/DownCylinderBracket.(first,eliminateair‐hosefromFitting)
6. DisassembleUp/DownCylinderJointfromUp/DownCylinder.
7. AssemblenewUp/DownCylinderin
reverseorderofdisassembly.
8. Supply power and check if the Up/Down Cylinder and Up/Down Limit Sensor is
operatingproperlyattheI/Oscreen.
ÚNote:
Up/DownCylinderandUp/DownCylinderJointshouldbeassembledasthesizeofdiagram.
SensorCableshouldnotinterferewhenUp/DownCylinderisoperating.
SettheUp/DownCylinderspeedbytheSpeedControllerindicatedinthediagram.
Maintenance Manual | 37
1.2.9. CONVEYOR HEIGHT GUIDE
Figure 1-10. Height Guide
Item Description Item Description
1 Spring 4 Height Guide Cylinder
2 Cylinder Shaft Joint 5 Speed Controller
3 Height Joint Bracket
1. Cutthepower/theairsupplyandpressemergencyswitch.
② ①
④
③
⑤
Fixed Rail
38 | KY-8030 2
3DSolderPasteInspectionSystem
Version 1.0
KOH YOUNG TECHNOLOGY INC.
2. Openthe FrontDoor/WindowanddisassembleRearCover/RightSideCover.
3. DisassembleHeightJointBracketfromHeightGuide.
4. Disassemble Height Cylinder Bracket from Fix Rail (first, Eliminate air‐hose from
Fitting)
5. Disassemble Height Guide Cylinder from Height Cylinder Bracket and, assemble
CylinderShaftJointandSpeedControllerat
theHeightGuideCylinder.
6. AssemblenewHeightGuideCylinderinreverseorderofdisassembly.
7. Supply power andcheck if the HeightGuide Cylinderis operating properly at theI/O
screen.
ÚNote:
HeightGuideCylinderandCylinderShaftJointshouldbeassembledasthesizeofthediagram.
IfanyforeignsubstancejammedbetweenthenarrowspaceofHeightGuideandFixRail,eliminateit
withcompressedairtopreventmalfunctioning.
