16 D33363 | Date 01/2020 Construction and description 2.9 Declaration of conformity Y ou can download the EC declaration of conformity of the appliance online: English: http://www .memmert.com/en/service/downloads/ce-sta…
D33363 | Date 01/2020 15
Construction and description
Appliance size 450 750 1060
Power [W]
I...
115 V, 50/60 Hz 1500 1800 –
230 V, 50/60 Hz 1800 2000 –
U...
400 V, 50/60 Hz 5800 7000 7000
3 x 230 V o. N., 50/60 Hz 5800 7000 7000
3 x 208 V, 50/60 Hz 4800 5700 5700
Current consumption
[A]
I...
230 V, 50/60 Hz 7,8 8,7 –
115 V, 50/60 Hz 13,0 15,6 –
U...
400 V, 50/60 Hz 3 x 8,4 3 x 10,1 3 x 10,1
3 x 230 V o. N., 50/60 Hz 3 x 14,6 3 x 17,6 3 x 17,6
3 x 208 V, 50/60 Hz 3 x 13,3 3 x 15,1 3 x 15,1
max. number of sliding shelves 8 14 14
max. load per sliding shelve [kg] 30 60
max. load per appliance [kg] 300
Setting temperature range
IN/IF +20 bis +80 °C
2
–
UN/UF +20 bis +300 °C
2 3
Adjustment precision
IN/IF 0,1 K –
UN/UF bis 99,9 °C: 0,1 K, ab 100 °C: 0,5 K
1
See Fig. 6 on page 15
2
With the interior lighting on, the minimum temperature might not be reached.
3
to +250 °C if your device is equipped with a glass door
Fig. 6 Dimensions (see table on page 14)
D
A
F
C
56
E
B
16 D33363 | Date 01/2020
Construction and description
2.9 Declaration of conformity
You can download the EC declaration of conformity of the appliance online:
English: http://www.memmert.com/en/service/downloads/ce-statement/
German: http://www.memmert.com/de/service/downloads/eg-konformitaetserklaerung/
2.10 Ambient conditions
► The appliance may only be used in enclosed rooms and under the following ambient
conditions:
Ambient temperature
+5 ºC to +40 ºC
Humidity rh max. 80 %, non-condensing
Overvoltage category II
Pollution degree 2
Altitude of installation max. 2,000 m above sea level
► The appliance may not be used in areas where there is a risk of explosion. The ambient air
must not contain any explosive dusts, gases, vapours or gas-air mixtures. The appliance is
not explosion-proof.
► Heavy dust production or aggressive vapours in the vicinity of the appliance could lead to
sedimentation in the interior and, as a consequence, could result in short circuits or dam-
age to electrical parts. For this reason, sufficient measures to prevent large clouds of dust
or aggressive vapours from developing should be taken.
2.11 Scope of delivery
► Power cable
► Tilt protection
► One or two sliding steel grids (load capacity 30 kg each)
► The operating instructions at hand
► Calibration certificate
2.12 Optional accessories
► AtmoCONTROL software for reading out
and processing of protocol log files
► USB to Ethernet converter (Fig. 7 ). Makes
it possible to connect the appliance's
network interface (see page 13) to the
USB port of a computer / laptop.
► Reinforced, sliding steel grids with a load
capacity of 60 kg each (for appliance size
110 and larger)
Fig. 7 Converter USB to Ethernet
D33363 | Date 01/2020 17
Delivery, transport and setting up
3. Delivery, transport and setting up
3.1 For your Safety
Warning!
Because of the heavy weight of the appliance, you could injure
yourself if you try to lift it. To carry appliances of the sizes 30 and
55, at least two persons, for appliances of the sizes 75, 110, 160 and
260, four people are needed. Appliances larger than that may not be
carried but must be transported with a manual pallet jack or forklift
truck.
30 55 75 110 160 260 450 750
Warning!
You may get your hands or feet squashed when transport-
ing and installing the appliance. Wear protective gloves and
safety boots. When grasping the bottom of the appliance,
grasp it only on the sides:
9
Warning!
The appliance could fall over and seriously injure you. Never
tilt the appliance and transport it in upright position and
without load only (except for standard accessories such as
steel grids or shelves). Appliances with castors always have to
be moved by two people.
