D33363 | Date 01/2020 37
Menu mode
7.2 Basic operation in menu mode using the example of language
selection
In general, all settings in menu mode are done just like in manual mode: Activate the re-
spective display, use the turn control for setting and press the confirmation key to accept
the change. A more detailed description is provided in the following, using the example of
language selection.
1. Activate the desired parameter (in this
example the language). To do so, press
the corresponding activation key on the
left or right of the respective display. The
activated display is enlarged.
ENGLISH
DEUTSCH
ESPANOL
POLSKI
CESTINA
FRANCAIS
If you want to exit or cancel your settings,
again press the activation key which you
have used to activate the display. The
appliance returns to the menu overview.
Only the settings that you have con-
firmed by pressing the confirmation key
before cancelling the setting procedure
are accepted.
SETUP
SIGNALTÖNE
CALIB
LANGUAGE
TIME
ON
O
O
ON
N
N
N
O
O
N
O
2. With the turn control, select the desired
new setting, e.g. Español (Spanish).
3. Save the setting by pressing the confir-
mation key.
SPRACHE
ENGLISH
DEUTSCH
MAGYAR
ITALIANO
ESPANOL
FRANCAIS
POLSKI
CESTINA
4. To return to the menu overview, press the
activation key again.
SETUP
SIGNALTÖ
N
CALI
B
LANGUAGE
TIM
You can now
► activate another menu function by press-
ing the corresponding activation key or
► return to manual mode by pressing the
MENU key.
Balance
Einheit
IP Adresse
Alarm Tem
p
Timer Mod
e
Unit
IP address
Subnet mas
k
Alarm temp
Timer mode
Slide-in unit
SPRACHE
ENGLISH
DEUTSCH
MAGYAR
ITALIANO
ESPANOL
FRANCAIS
POLSKI
38 D33363 | Date 01/2020
Menu mode
All other settings can be made accordingly. The settings possible are described in the follow-
ing sections.
If no new values are entered or confirmed for approx. 30 seconds, the appliance automati-
cally returns to the main menu and restores the former values.
7.3 Setup
In the SETUP display, you can set the following parameters:
► the IP address and Subnet mask of the appliance's Ethernet interface (for connection to
a network)
► the Unit of the temperature display (°C or °F, see page 39)
► the type of temperature monitoring (TWW or TWB, Alarm Temp, only if equipped with
a second temperature sensor, option A6) and the trigger temperature of the monitoring
function (
Max alarm, see page 40)
► how the digital backwards counter with target time setting works (Timer mode, see page
41)
► the type of the slide-in unit (Grid or Shelf, see page 41)
► Remote control (see page 41)
► Gateway (see page 42)
If the SETUP menu contains more entries than can be
displayed, this is indicated by the display “1/2”. This
means that there is a second „page“ of entries.
To display the hidden entries, use the turn control
to scroll beyond the lowest entry. The page display
changes to “2/2”.
7.3.1 IP address and subnet mask
If you want to operate one ore more appliances in a network, each appliance must have its
own unique IP address for identification. By default, each appliance is delivered with the IP
address 192.168.100.100.
LAN 1: 192.168.1.233
192.168.1.216
LAN 2: 192.168.1.215
LAN 3: 192.168.1.241
1
9
2.1
68
.
1
Editor
Programmname
Simulation Protokoll
-
+
-
+
INP 250 Test 01
180
.0°C
i
HPP 250 Labor
i
37
.0°C
44
.4%rh
151
5
STAND BY
Programm negnulletsniEllokotorPtäreG efliHnekcurD
AtmoCONTROL
Fig. 22 Operation of several appliances in a network (schematic example)
Setu
p
Unit
IP adress 255.145.136.
2
Subnet mask 255.255.0. 0
°C F
1/2
D33363 | Date 01/2020 39
Menu mode
1. Activate the
SETUP display. The entry
IP address is automatically highlighted.
SETUP
Balance
Einheit
IP Adresse
+30%
192.168. 1 0 0 .100
Alarm Temp
°C F
TWW TWB
Timer Mode
Setup
Unit
IP address 192.168. 1 0 0. 100
Subnet mask 255.255. 0 . 0
Alarm temp
°C F
TWW TWB
Timer mode
Slide-in unit
Grid Shelf
2. Accept the selection by pressing the con-
firmation key. The first three digits of the
IP address are automatically selected.
SETUP
Unit
IP address 192.168.100.100
Subnet mask 255.255. 0 .0
Alarm temp
°C F
TWW TWB
Timer mode
3. With the turn control, set the new num-
ber, e.g. 255.
SETUP
Unit
IP address 255.168.100.100
Subnet mask 255.255. 0 .0
Alarm temp
°C F
TWW TWB
Timer mode
4. Accept the selection by pressing the con-
firmation key. The next three digits of the
IP address are automatically selected. Set-
ting these is done with the turn control
according to the description above.
SETUP
Unit
IP address 255.168.100.100
Subnet mask 255.255. 0 .0
Alarm temp
°C F
TWW TWB
Timer mode
5. After setting the last three digits, accept
the new IP address by pressing the con-
firmation key. The selection returns to the
overview.
The subnet mask is set accordingly.
SETUP
Unit
IP address 255.145.136.225
Subnet mask 255.255. 0 .0
Alarm temp
°C F
TWW TWB
Timer mode
7.3.2 Unit
Here, you can choose whether the temperature is displayed in °C
or °F.
7.3.3 Temperature monitoring ( Alarm Temp and Max
Alarm)
Here, the type of monitoring function that should be activated (TWW or TWB, description
from page 30) can be set (
Alarm Temp), as well as the temperature at which the automatic
temperature monitoring should be triggered (
Max alarm).
The selection option TWW/TWB is only available for appliances with a second temperature
sensor (option A6).
The monitoring temperature must be set sufficiently high above the maximum set tem-
perature. We recommend 5 to 10 K difference for UN
.../UF... and 1 to 3 K difference for IN.../
IF
...
SETUP
Unit
IP address 255.145.136.225
Subnet mask 255.255. 0 .0
Alarm temp
°C °F
TWW TWB
Timer mode
