Installation Manual SIPLACE SWS Software 2.0
Edition 10/2013
55
1 General
1.1 Brief Description
This manual contains the installation guide for the operating system and the software (control and
operating software ) for the SIPLACE Wafer Systems (SWS). It also includes a description of the
backup and restore scenarios. 1
1.2 Scope of Delivery
The operating system and the software (control and operating software) for the SIPLACE Wafer
Systems (SWS) is preinstalled and will be supplied with the SWS module. 1
1.2.1 SWS Software Package
You need two files for installation of the current SWS software. These need to be on a USB stick.1
– SIPLACE SWS software 2.0
– SWS_<versionsnummer>_bin.tgz
– update_sw.tgz
– SWS operating system
– ISO image (*.iso)
– Halcom license on USB stick (software is preinstalled)
1.3 Requirements
The computer hardware with the relevant system requirements is supplied together with the
SIPLACE Wafer System (SWS). 1
1.4 Languages
German 1
English 1
Other languages on request 1
Installation Manual SIPLACE SWS Software 2.0
Edition 10/2013
56
1.5 Legend
Different symbols and notes have been used to help you read and understand this document. 1
1
1
1
1
1.5.1 Where Can You Get Information?
If you have questions about this software manual or if you would like more information about
certain subjects, please contact your local SIPLACE branch or us directly at: 1
ASM Assembly Systems GmbH & Co. KG
Rupert-Mayer-Str. 44
D-81379 Munich, Germany 1
1
1
Requires action
(e.g. mouse click, opening a file)
1
Words in bold print
1
Relates to dialogs, dialog windows, menu items and com-
mands
1
1
–
1
Result of an action or list
PLEASE NOTE
Definition
A note as used in this manual contains important, explanatory information.
WARNING
Definition
A warning as used in this manual means that the information is very important for suc-
cessful execution of work.
Installation Manual SIPLACE SWS Software 2.0
Edition 10/2013
57
1.5.2 SIPLACE on the World Wide Web (WWW)
You can also log onto our SIPLACE website at http://www.siplace.com. 1
The menu navigation and information are available in two languages. You can choose between
the German and English versions. 1
The various headings contain information on 1
Our products 1
Services 1
Contact persons etc. 1
Registered customers can also access the SIPLACE User Group. There you can call up special
information on our placement machines, such as 1
Technical documentation 1
Technical informations 1
Spare parts lists etc. 1
Registering for access to the User Group is sheer child’s play: 1
Click on 'Register’.
Fill in the registration form and send it off to us.
Soon afterwards, you will receive a access authorization with USER-ID and password. 1
1.6 Overview of the Editions
1
1
Guide Software version Edition
First edition Installation Manual
V 2.0 10/2013
