3.1 Proper Data Listing
The Proper data is a list of machine calibration variables and initialization
parameters used to compensate the subtle differences between machines.
Whether physically different or the way the machines are used in production,
these values can seriously affect the performance of a machine if altered
improperly.
After altering any of the Proper data items, a printed copy of the new Proper data
file should be placed in the machine’s Control Box. A plastic folder to hold this
copy is mounted to the right hand door of Control Box 2 for this purpose. Do not
forget to write the date, the machine’s serial number and your initials at the top of
the printout. Also, always keep the previous copy. This will be useful if a
problem should occur. We highly recommend that you also make a copy of the
Proper file to a floppy disk. Save it with a name that includes the machine’s serial
number and the date.
The Proper data items are classified according to the following symbols.
%: Varies from machine to machine. Proper data must be measured.
*: Cannot be changed by the user.
#: Can be changed by the user.
@: Automatically set by the machine (or it may be changed by the user.)
$: Not currently in use.
Warning
The Proper data should never be altered without the use of this manual
or without contacting a Fuji technical support engineer. Altering the
Proper data items incorrectly will damage the machine.
WN003
Chapter 3 3.1 Proper Data Listing
Edition 1.0 3-1 GL-541E Level 3 Reference
The meaning of each Proper data item is described later in this section. Please
refer to this section when setting Proper data on GL-541E machines.
No. Name Range
# 1: MG4ID ID_Code =
# 2: MG4LG Language = 0
# 3: MG4REL Red_Light = 1024
# 4: MG4YEL Yellow_Light = 16420
# 5: MG4BLL Blue_Light = 768
# 6: MG4REB Red_Flash = 8
# 7: MG4YEB Yellow_Flash = 8210
# 8: MG4BLB Blue_Flash = 2241
$ 9: MG4USDA User_Define_A = 0
$ 10: MG4S1 spare = 0
# 11: MG4MASA Machine_Status_A = 0
# 12: MG4MASB Machine_Status_B = 0
# 13: MG4MAID Machine_ID = 0
# 14: MG4PCBL PCB_Location = 0
$ 15: MG4RCTM Recovery_Times = 0
$ 16: MG4S2 spare = 0
$ 17: MG4S3 spare = 0
$ 18: MG4S4 spare = 0
$ 19: MG4S5 spare = 0
# 20: MG4LOSA Loader_Status_A = 0
# 21. MG4LOSB Loader_Status_B = 0
# 22: MG4CVT Conveyor_Type = 0
# 23: MG4WASG Wait_Signal = 0
# 24: MG4BUI Busy_Invalid = 0
# 25: MG4CVC Conveyor_Control = 0
# 26: MG4CVAL Conveyor_Adj_Limit = 50
# 27: MG4CVSO Conveyor_Stop_Offset = 30
# 28: MG4CVAT Conveyor_adj_Timer = 60000
% 29: MG4WMAL Width_max_Limit = 46000
% 30: MG4WMIL Width_min_Limit = 5000
$ 31: MG4S6 spare = 0
$ 32: MG4S7 spare = 0
$ 33: MG4S8 spare = 0
$ 34: MG4S9 spare = 0
$ 35: MG4S10 spare = 0
Chapter 3 3.1 Proper Data Listing
Edition 1.0 3-2 GL-541E Level 3 Reference
Chapter 3 3.1 Proper Data Listing
Edition 1.0 3-3 GL-541E Level 3 Reference
No. Name Range
$ 36: MG4S11 spare = 0
$ 37: MG4S12 spare = 0
$ 38: MG4S13 spare = 0
$ 39: MG4S14 spare = 0
# 40: MG4LMS LMS_Flag = 0
# 41: MG4CELL Cell_Status = 0
# 42: MG4CHGOM Change_Over_Mode = 0
# 43: MG4AUTOS Auto_Start = 0
$ 44: MG4BKPC Backup_Plate_Check = 0
# 45: MG4CMLS Command_Line_Status = 0
# 46: MG4CMLP Command_Line_Port = 0
# 47: MG4IDST ID_Station_Type = 0
# 48: MG4BUZW Buzzer_Warning = 0
# 49: MG4PROT Process_Timer = 10000
# 50: MG4RDT Reader_Type = 0
# 51: MG4CDRT Code_Reader_Timer = 10000
# 52: MG4CDRR Code_Reader_Retry = 0
# 53: MG4RD1P Reader1_Port_No = 0
# 54: MG4RD2P Reader2_Port_No = 0
# 55: MG4PCBCT PCB_Code_Terminal = 0
# 56: MG4TERT Terminal_Type = 0
# 57: MG4CDTP Code_Terminal_Port = 0
$ 58: MG4S15 spare = 0
$ 59: MG4S16 spare = 0
$ 60: MG4S17 spare = 0
$ 61: MG4S18 spare = 0
$ 62: MG4S19 spare = 0
$ 63: MG4S20 spare = 0
$ 64: MG4S21 spare = 0
$ 65: MG4S22 spare = 0
$ 66: MG4S23 spare = 0
$ 67: MG4S24 spare = 0
$ 68: MG4S25 spare = 0
$ 69: MG4S26 spare = 0
$ 70: MG4DCSW Device_Check_SW = 1
$ 71: MG4VFT Verifier_Tool = 0
$ 72: MG4BART Barcode_Reader_Type = 0
