Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-20 GL-541E Level 3 Reference
121. MG4Z0Z2 Z0_Z2 (-300000 to 30000) [pulse] = 0
Specify the Z coordinate when the Z2 nozzle touches the surface of the board.
Standard setting: 0
122. MG4Z0Z3 Z0_Z3 (-300000 to 30000) [pulse] = 0
Specify the Z coordinate when the Z3 nozzle touches the surface of the board.
Standard setting: 0
123. MG4XCZ1 XC_Z1 (-300000 to 300000) [pulse] = 0
Specify the X coordinate of the camera with respect to the center of the Z1 nozzle.
Standard setting: 0
124. MG4XCZ2 XC_Z2 (-300000 to 300000) [pulse] = 0
Specify the X coordinate of the camera with respect to the center of the Z2 nozzle.
Standard setting: 0
125. MG4XCZ3 XC_Z3 (-300000 to 300000) [pulse] = 0
Specify the X coordinate of the camera with respect to the center of the Z3 nozzle.
Standard setting: 0
126. MG4YCZ1 YC_Z1 (-300000 to 300000) [pulse] = 0
Specify the Y coordinate of the camera with respect to the center of the Z1 nozzle.
Standard setting: 0
127. MG4YCZ2 YC_Z2 (-300000 to 300000) [pulse] = 0
Specify the Y coordinate of the camera with respect to the center of the Z2 nozzle.
Standard setting: 0
128. MG4YCZ3 YC_Z3 (-300000 to 300000) [pulse] = 0
Specify the Y coordinate of the camera with respect to the center of the Z3 nozzle.
Standard setting: 0
131. MG4GCMZ1 G_check_multi_Z1 (1 to 200) [%] = 0
Specify the feedback coefficient for the Z1 nozzle during glue feedback control.
Standard setting: 100
132. MG4GCMZ2 G_check_multi_Z2 (1 to 200) [%] = 0
Specify the feedback coefficient for the Z2 nozzle during glue feedback control.
Standard setting: 100
133. MG4GCMZ3 G_check_multi_Z3 (1 to 200) [%] = 0
Specify the feedback coefficient for the Z3 nozzle during glue feedback control.
Standard setting: 100
134. MG4GLCL3 G_check_limit (1 to 200) [%] = 0
Specify the range over which the glue feedback control is carried out.
Feedback is carried out if the dot diameter lies within the limit set by the equation;
reference data diameter x (1 ± Glue check limit / 100).
Standard setting: 30
Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-21 GL-541E Level 3 Reference
135. MG4DEZ1 Delta_Z1 (-32768 to 32767) [pulse] = 0
Specify the offset value from the zero-setting point for the Z1 nozzle’s Q-axis.
Standard setting: 0
136. MG4DEZ2 Delta_Z2 (-32768 to 32767) [pulse] = 0
Specify the offset value from the zero-setting point for the Z2 nozzle’s Q-axis.
Standard setting: 0
137. MG4DEZ3 Delta_Z3 (-32768 to 32767) [pulse] = 0
Specify the offset value from the zero-setting point for the Z3 nozzle’s Q-axis.
Standard setting: 0
138. MG4NEZ1 Needle_Z1 0: Single 1: Twin = 1
Specify the type of needle attached to the Z1 nozzle. Used for the glue feedback
control and needle offset.
Standard setting: 1
139. MG4NEZ2 Needle_Z2 0: Single 1: Twin = 1
Specify the type of needle attached to the Z2 nozzle. Used for the glue feedback
control and needle offset.
Standard setting: 1
140. MG4NEZ3 Needle_Z3 0: Single 1: Twin = 1
Specify the type of needle attached to the Z3 nozzle. Used for the glue feedback
control and needle offset.
Standard setting: 1
141. MG4GLDZ1 Glue_area_Z1 (1 to 200) [um/%] = 100
Specify the increase in the glue dot area for the Z1 nozzle for a 1% increase in air
pressure. Used for the glue feedback control.
Standard setting: 100
142. MG4GLDZ2 Glue_area_Z2 (1 to 200) [um/%] = 100
Specify the increase in the glue dot area for the Z2 nozzle for a 1% increase in air
pressure. Used for the glue feedback control.
Standard setting: 100
143. MG4GLDZ3 Glue_area_Z3 (1 to 200) [um/%] = 100
Specify the increase in the glue dot area for the Z3 nozzle for a 1% increase in air
pressure. Used for the glue feedback control.
Standard setting: 100
144. MG4GLCDE Glue_check_delay (0 to 4999) = 0
Specify the delay (in number of sequences) after the glue check dots are dispensed
before the camera measures the dots.
After making this setting in Proper data and transmitting the Proper data to the
machine, either transmit a production program from F4G or change the
production program at the machine in order to enable this setting.
Standard setting: 0
Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-22 GL-541E Level 3 Reference
149. MG4MASX Max_speed_X (1 to 100) [%] = 100
Specify the maximum speed of the X-axis servomotor.
Standard setting: 100
150. MG4MASY Max_speed_Y (1 to 100) [%] = 100
Specify the maximum speed of the Y-axis servomotor.
Standard setting: 100
151. MG4MASQ Max_speed_Q (1 to 100) [%] = 100
Specify the maximum speed of the Q-axis servomotor.
Standard setting: 100
152. MG4MASZ1 Max_speed_Z1 (1 to 100) [%] = 100
Specify the maximum speed of the Z1-axis servomotor.
Standard setting: 100
153. MG4MASZ2 Max_speed_Z2 (1 to 100) [%] = 100
Specify the maximum speed of the Z2-axis servomotor.
Standard setting: 100
154. MG4MASZ3 Max_speed_Z3 (1 to 100) [%] = 100
Specify the maximum speed of the Z3-axis servomotor.
Standard setting: 100
167. MG4LMIX Travel_limit_min_X (-10000 to 10000) [pulse] = 0
Specify the minimum limit of the X-axis travel range.
Standard setting: 0
168 MG4LMIY Travel_limit_min_Y (-10000 to 10000) [pulse] = 0
Specify the minimum limit of the Y-axis travel range.
Standard setting: 0
169. MG4LMIQ Travel_limit_min_Q (-10000 to 10000) [pulse] = 0
Presently not used.
Standard setting: 0
170. MG4LMIZ1 Travel_limit_min_Z1 (-10000 to 10000) [pulse] = 0
Specify the minimum limit of the Z1-axis travel range.
Standard setting: 0
171. MG4LMIZ2 Travel_limit_min_Z2 (-10000 to 10000) [pulse] = 0
Specify the minimum limit of the Z2-axis travel range.
Standard setting: 0
172. MG4LMIZ3 Travel_limit_min_Z3 (-10000 to 10000) [pulse] = 0
Specify the minimum limit of the Z3-axis travel range.
Standard setting: 0
