Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-15 GL-541E Level 3 Reference
13. MG4MAID Machine_ID = 0
Parameter to set special machine software modes.
Normally set to 0.
Input a decimal number after making the setting using a 16 bit binary format.
Use the calculator function in the Windows Accessories icon group to perform this
conversion.
Standard setting: 0
14. MG4PCBL PCB_Location = 0
Specify whether the reference pin is used or not used.
[0] Corner: Reference pin is not used.
[1] Pin: Reference pin is used.
Standard setting: 0
20. MG4LOSA Loader_Status_A = 0
Board loader operating conditions. Not used at present.
21. MG4LOSB Loader_ Status_B = 0
Board loader operating conditions. Not used at present.
22. MG4CVT Conveyor_Type = 0
Specify the direction of board flow.
[0] L → R: Board flow is from left to right (standard).
[1] R → L: Board flow is from right to left (optional).
Standard setting: 0
23. MG4WASG Wait_Signal = 0
Specify whether the wait signal is valid or invalid.
[0] Off: Wait signal is not valid.
[1] On: Wait signal is valid.
24. MG4BUI Busy_Invalid = 0
Specify whether or not the machine refers to board request signals from the next
machine (when unloading a board).
[0] No: Refer to board request signals from next machine.
[1] Yes: Ignore board request signals and feed out boards when they become
available.
Standard setting: 0
25. MG4CVC Conveyor_Control = 0
Specify whether the machine is fitted with the automatic conveyor width
adjustment mechanism.
[0] Manu: Manual conveyor adjustment
[1] Auto: Automatic conveyor adjustment
Standard setting: 0
Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-16 GL-541E Level 3 Reference
26. MG4CVAL Conveyor_Adj_Limit (0.05 to 1.00) [mm] = 50
Specify the tolerance for the conveyor width setting when using automatic
conveyor width adjustment.
Standard setting: 50
27. MG4CVSO Conveyor_Stop_Offset (0.00 to 2.00) [mm] = 30
Specify the offset value for stopping the motor at the target position when using
automatic conveyor width adjustment.
Standard setting: 30
28. MG4CVAT Conveyor_adj_Timer (0 to 120000) [msec] = 60000
Specify the time for automatic conveyor width adjustment. If this time is
exceeded, a time-up error occurs.
Standard setting: 60000
29. MG4WMAL Width_Max_Limit (0.00 to 655.35) [mm] = 360
Specify the maximum conveyor width.
Standard setting: 360.00
30. MG4WMIL Width_Min_Limit (0.00 to 655.35) [mm] = 50
Specify the minimum conveyor width.
Standard setting: 50.00
40. MG4LMS LMS_Flag = 0
Specify whether the machine is HELPS-compatible or not HELPS-compatible.
[0] Off: Non HELPS-compatible machine
[1] On: HELPS-compatible machine
Standard setting: 0
41. MG4CELL Cell_Status = 0
Specify the cell status.
[0] Unit: Unit cell
[1] Active: Active cell
[2] Passive: Passive cell
Standard setting: 0
42. MG4CHGOM Change_Over_Mode (0 to 200) = 0
Specify the board type report for a HELPS machine.
[0]: Manual terminate
[2]: Pattern code (upper surface)
[4]: Bar code 1 (upper surface)
[5]: Bar code 2 (lower surface)
[25]: Bar code 3 (when using two bar codes; both surfaces)
Standard setting: 0
Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-17 GL-541E Level 3 Reference
43. MG4AUTOS Auto_Start = 0
Specify whether the machine enters automatic operation without the START
button being pressed when changeover is complete on a HELPS machine.
[0] No: After changeover is complete, the START button is enabled.
[1] Yes: After changeover is complete, the machine starts automatically.
Standard setting: No
44. MG4BKPC Backup_Plate_Check = 0
Specify whether a back-up plate change request is issued.
[0] No: No backup plate change request is issued.
[1] Yes: A backup plate change request is issued.
Standard setting: No
45. MG4CMLS Command_Line_Status = 0
Specify the mode of transmission with the LAN.
[0] RS232C: Use RS232C
[1] LAN: Use LAN
[2] ETHERNET: Use ETHERNET
Standard setting: 0
Note: Do not set LAN or ETHERNET as they are not available.
46. MG4CMLP Command_Line _Port (0 to 30) = 0
Specify the communication board port number when an RS-232C is used.
0: Command line is not used.
11 ~ 16: Port numbers 1 to 6 on the first VM1440 board
Standard setting: 0
48. MG4BUZW Buzzer_Warning = 0
Specify whether a buzzer sounds when HELPS changeover is performed.
[0] On: Buzzer will sound.
[1] Off: Buzzer will not sound.
Standard setting: 0
49. MG4PROT Process_Timer (0 to 120000) [msec]
Specify the protocol timer value.
Standard setting: 10000
Note: A setting of about 2000 ms is appropriate.
50. MG4RDT Reader Type (0 to 9) = 0
Specify the code reader type when using a code reader to identify the board types
on a HELPS machine.
[0]: Fuji standard bar-code reader
[1]: Fuji standard pattern code reader
[2]: AT&T bar-code reader
[3]: Keyence bar-code reader
Standard setting: 0
