Chapter 3 3.1 Proper Data Listing
Edition 1.0 3-7 GL-541E Level 3 Reference
No. Name Range
$ 184: MG4SDQZ1 Spot_down_Q_point_Z1 = 50
$ 185: MG4SDQZ2 Spot_down_Q_point_Z2 = 50
$ 186: MG4SDQZ3 Spot_down_Q_point_Z3 = 50
$ 187: MG4S80 spare = 0
$ 188: MG4S81 spare = 0
$ 189: MG4S82 spare = 0
# 190: MG4SCTZ1 Spot_cd_timer_Z1 = 0
# 191: MG4SCTZ2 Spot_cd_timer_Z2 = 0
# 192: MG4SCTZ3 Spot_cd_timer_Z3 = 0
# 193: MG4SUEZ1 Spot_up_end_timer_Z1 = 0
# 194: MG4SUEZ2 Spot_up_end_timer_Z2 = 0
# 195: MG4SUEZ3 Spot_up_end_timer_Z3 = 0
# 196: MG4SLEZ1 Spot_low_end_height_Z1 = -20
# 197: MG4SLEZ2 Spot_low_end_height_Z2 = -20
# 198: MG4SLEZ3 Spot_low_end_height_Z3 = -20
# 199: MG4SOZ1 Spot_on_XY_position_Z1 = 732
# 200: MG4SOZ2 Spot_on_XY_position_Z2 = 732
# 201: MG4SOZ3 Spot_on_XY_position_Z3 = 732
# 202: MG4SOQZ1 Spot_on_Q_position_Z1 = 40
# 203: MG4SOQZ2 Spot_on_Q_position_Z2 = 40
# 204: MG4SOQZ3 Spot_on_Q_position_Z3 = 40
$ 205: MG4SOBO Spot_on_border = 0
$ 206: MG4S83 spare = 0
$ 207: MG4S84 spare = 0
$ 208: MG4S85 spare = 0
$ 209: MG4S86 spare = 0
$ 210: MG4S87 spare = 0
$ 211: MG4S88 spare = 0
$ 212: MG4S89 spare = 0
$ 213: MG4S90 spare = 0
$ 214: MG4S91 spare = 0
$ 215: MG4S92 spare = 0
$ 216: MG4S93 spare = 0
$ 217: MG4S94 spare = 0
$ 218: MG4S95 spare = 0
$ 219: MG4S96 spare = 0
$ 220: MG4S97 spare = 0
Chapter 3 3.1 Proper Data Listing
Edition 1.0 3-8 GL-541E Level 3 Reference
No. Name Range
$ 221: MG4S98 spare = 0
$ 222: MG4S99 spare = 0
$ 223: MG4S100 spare = 0
$ 224: MG4S101 spare = 0
$ 225: MG4S102 spare = 0
$ 226: MG4S103 spare = 0
$ 227: MG4S104 spare = 0
$ 228: MG4S105 spare = 0
$ 229: MG4S106 spare = 0
$ 230: MG4S107 spare = 0
$ 231: MG4S108 spare = 0
$ 232: MG4S109 spare = 0
$ 233: MG4S110 spare = 0
$ 234: MG4S111 spare = 0
$ 235: MG4S112 spare = 0
$ 236: MG4S113 spare = 0
$ 237: MG4S114 spare = 0
$ 238: MG4S115 spare = 0
$ 239: MG4S116 spare = 0
$ 240: MG4S117 spare = 0
$ 241: MG4S118 spare = 0
$ 242: MG4S119 spare = 0
$ 243: MG4S120 spare = 0
$ 244: MG4S121 spare = 0
$ 245: MG4S122 spare = 0
$ 246: MG4S123 spare = 0
$ 247: MG4S124 spare = 0
$ 248: MG4S125 spare = 0
$ 249: MG4S126 spare = 0
$ 250: MG4S127 spare = 0
$ 251: MG4S128 spare = 0
$ 252: MG4S129 spare = 0
$ 253: MG4S130 spare = 0
# 254: MG4GCPX glue_check_orgn_position_x = 36500
# 255: MG4GCPY glue_check_orgn_position_y = 39200
%*256: MG4NOXZ1 Needle_offset_X_Z1 = 0
%*257: MG4NOXZ2 Needle_offset_X_Z2 = 0
Chapter 3 3.1 Proper Data Listing
Edition 1.0 3-9 GL-541E Level 3 Reference
No. Name Range
%*258: MG4NOXZ3 Needle_offset_X_Z3 = 0
%*259: MG4NOYZ1 Needle_offset_Y_Z1 = 0
%*260: MG4NOYZ2 Needle_offset_Y_Z2 = 0
%*261: MG4NOYZ3 Needle_offset_Y_Z3 = 0
%*262: MG4NOQZ1 Needle_offset_Q_Z1 = 0
%*263: MG4NOQZ2 Needle_offset_Q_Z2 = 0
%*264: MG4NOQZ3 Needle_offset_Q_Z3 = 0
# 265: MG4ZUAZ1 Z_up_app_Z1 = 600
# 266: MG4ZUAZ2 Z_up_app_Z2 = 600
# 267: MG4ZUAZ3 Z_up_app_Z3 = 600
$ 268: MG4S133 spare = 0
$ 269: MG4S134 spare = 0
$ 270: MG4S135 spare = 0
%*271: MG4MCPX Mark_camera_pixel_X = 1152000
%*272: MG4MCPY Mark_camera_pixel_Y = 1228800
%*273: MG4MCRO Mark_camera_Rotation = 0
$ 274: MG4MCGA Mark_camera_gain = 0
$ 275: MG4MCOF Mark_camera_offset = 0
$ 276: MG4GCGA Glue_camera_gain = 0
$ 277: MG4GCOF Glue_camera_offset = 0
