Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-21 GL-541E Level 3 Reference
135. MG4DEZ1 Delta_Z1 (-32768 to 32767) [pulse] = 0
Specify the offset value from the zero-setting point for the Z1 nozzle’s Q-axis.
Standard setting: 0
136. MG4DEZ2 Delta_Z2 (-32768 to 32767) [pulse] = 0
Specify the offset value from the zero-setting point for the Z2 nozzle’s Q-axis.
Standard setting: 0
137. MG4DEZ3 Delta_Z3 (-32768 to 32767) [pulse] = 0
Specify the offset value from the zero-setting point for the Z3 nozzle’s Q-axis.
Standard setting: 0
138. MG4NEZ1 Needle_Z1 0: Single 1: Twin = 1
Specify the type of needle attached to the Z1 nozzle. Used for the glue feedback
control and needle offset.
Standard setting: 1
139. MG4NEZ2 Needle_Z2 0: Single 1: Twin = 1
Specify the type of needle attached to the Z2 nozzle. Used for the glue feedback
control and needle offset.
Standard setting: 1
140. MG4NEZ3 Needle_Z3 0: Single 1: Twin = 1
Specify the type of needle attached to the Z3 nozzle. Used for the glue feedback
control and needle offset.
Standard setting: 1
141. MG4GLDZ1 Glue_area_Z1 (1 to 200) [um/%] = 100
Specify the increase in the glue dot area for the Z1 nozzle for a 1% increase in air
pressure. Used for the glue feedback control.
Standard setting: 100
142. MG4GLDZ2 Glue_area_Z2 (1 to 200) [um/%] = 100
Specify the increase in the glue dot area for the Z2 nozzle for a 1% increase in air
pressure. Used for the glue feedback control.
Standard setting: 100
143. MG4GLDZ3 Glue_area_Z3 (1 to 200) [um/%] = 100
Specify the increase in the glue dot area for the Z3 nozzle for a 1% increase in air
pressure. Used for the glue feedback control.
Standard setting: 100
144. MG4GLCDE Glue_check_delay (0 to 4999) = 0
Specify the delay (in number of sequences) after the glue check dots are dispensed
before the camera measures the dots.
After making this setting in Proper data and transmitting the Proper data to the
machine, either transmit a production program from F4G or change the
production program at the machine in order to enable this setting.
Standard setting: 0
Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-22 GL-541E Level 3 Reference
149. MG4MASX Max_speed_X (1 to 100) [%] = 100
Specify the maximum speed of the X-axis servomotor.
Standard setting: 100
150. MG4MASY Max_speed_Y (1 to 100) [%] = 100
Specify the maximum speed of the Y-axis servomotor.
Standard setting: 100
151. MG4MASQ Max_speed_Q (1 to 100) [%] = 100
Specify the maximum speed of the Q-axis servomotor.
Standard setting: 100
152. MG4MASZ1 Max_speed_Z1 (1 to 100) [%] = 100
Specify the maximum speed of the Z1-axis servomotor.
Standard setting: 100
153. MG4MASZ2 Max_speed_Z2 (1 to 100) [%] = 100
Specify the maximum speed of the Z2-axis servomotor.
Standard setting: 100
154. MG4MASZ3 Max_speed_Z3 (1 to 100) [%] = 100
Specify the maximum speed of the Z3-axis servomotor.
Standard setting: 100
167. MG4LMIX Travel_limit_min_X (-10000 to 10000) [pulse] = 0
Specify the minimum limit of the X-axis travel range.
Standard setting: 0
168 MG4LMIY Travel_limit_min_Y (-10000 to 10000) [pulse] = 0
Specify the minimum limit of the Y-axis travel range.
Standard setting: 0
169. MG4LMIQ Travel_limit_min_Q (-10000 to 10000) [pulse] = 0
Presently not used.
Standard setting: 0
170. MG4LMIZ1 Travel_limit_min_Z1 (-10000 to 10000) [pulse] = 0
Specify the minimum limit of the Z1-axis travel range.
Standard setting: 0
171. MG4LMIZ2 Travel_limit_min_Z2 (-10000 to 10000) [pulse] = 0
Specify the minimum limit of the Z2-axis travel range.
Standard setting: 0
172. MG4LMIZ3 Travel_limit_min_Z3 (-10000 to 10000) [pulse] = 0
Specify the minimum limit of the Z3-axis travel range.
Standard setting: 0
Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-23 GL-541E Level 3 Reference
174. MG4LMAX Travel_limit_max_X (-10000 to 10000) [pulse] = 0
Specify the maximum limit of the X-axis travel range.
Standard setting: 0
175. MG4LMAY Travel_limit_max_Y (-10000 to 10000) [pulse] = 0
Specify the maximum limit of the Y-axis travel range.
Standard setting: 0
176. MG4LMAQ Travel_limit_max_Q (-10000 to 10000) [pulse] = 0
Presently not used.
177. MG4LMAZ1 Travel_limit_max_Z1 (-10000 to 10000) [pulse] = 0
Specify the maximum limit of the Z1-axis travel range.
Standard setting: 0
178. MG4LMAZ2 Travel_limit_max_Z2 (-10000 to 10000) [pulse] = 0
Specify the maximum limit of the Z2-axis travel range.
Standard setting: 0
179. MG4LMAZ3 Travel_limit_max_Z3 (-10000 to 10000) [pulse] = 0
Specify the maximum limit of the Z3-axis travel range.
Standard setting: 0
181. MG4SDZ1 Spot_down_XY_point_Z1 (5 to 10000) [pulse] = 250
Presently not used.
182. MG4SDZ2 Spot_down_XY_point_Z2 (5 to 10000) [pulse] = 250
Presently not used.
183. MG4SDZ3 Spot_down_XY_point_Z3 (5 to 10000) [pulse] = 250
Presently not used.
184. MG4SDQZ1 Spot_down_Q_point_Z1 (5 to 10000) [pulse] = 250
Presently not used.
185. MG4SDQZ1 Spot_down_Q_point_Z2 (5 to 10000) [pulse] = 250
Presently not used.
186. MG4SDQZ3 Spot_down_Q_point_Z3 (5 to 10000) [pulse] = 250
Presently not used.
190. MG4SCTZ1 Spot_cd_timer_Z1 (0 to 1000) [msec] = 0
Specify the delay timer for the Z1-axis lower limit.
Standard setting: 0
191. MG4SCTZ2 Spot_cd_timer_Z2 (0 to 1000) [msec] = 0
Specify the delay timer for the Z2-axis lower limit.
Standard setting: 0
