Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-27 GL-541E Level 3 Reference
273. MG4MCRO Mark_camera_rotation (-196608000 to 196608000)
[1/1000 deg] = 0
Specify the degree of tilt in the installation angle of the camera.
A unit of 1/1000 degrees is used to ensure accuracy. Therefore the data is
multiplied by 65536. This data is obtained through Proper data measurement and
it cannot be changed.
Standard setting: 0
274. MG4MCGA Mark_camera_gain (0 to 255) = 0
This is the degree of magnification when the video image is acquired from the
mark camera.
Standard setting: 0
275. MG4MCOF Mark_camera_offset (0 to 255) = 0
This value determines the mark video signal’s zero point. This data sets the
background and the contrast.
Standard setting: 0
276. MG4GCGA Glue_camera_gain (0 to 255) = 0
Presently not used.
277. MG4GCOF Glue_camera_offset (0 to 255) = 0
Presently not used.
Chapter 3 3.2 Definitions of Proper Data
Edition 1.1 3-28 GL-541E Level 3 Reference
Notes:
GL-541E Level 3 Reference Manual
Edition 1.0 May 31, 2000
Edition 1.1 August 31, 2000
FUJI Machine Manufacturing Co., Ltd.
SMT Equipment
19 Chausuyama, Yamamachi, Chiryu,
Aichi Prefecture, 472-8686 Japan
Copyright 2000 by Fuji Machine Manufacturing Co., Ltd.
Printed in Japan
