SM471 Maintenance Handbook
66
Chapter 5
Fast & Flexible Chip Shooter
460mm
40mm
460mm
40mm
40mm
460mm
- Work Station
- Exit Station
- Entry Station
每月检验
4. 使用超细纱布清除Work Station, Exit Station, Entry Station的 Lead Screw与
LM Guide Rail的灰尘等杂质。
SM471 Maintenance Handbook
67
Chapter 5
Fast & Flexible Chip Shooter
Chapter 5
每月检验
460mm
40mm
460mm
40mm
40mm
460mm
- Work Station
- Exit Station
- Entry Station
每月检验
5. 使用片涂刷在Work Station, Exit Station, Entry Station的 Lead Screw与LM
Guide Rail涂敷Grease。
SM471 Maintenance Handbook
68
Chapter 5
Fast & Flexible Chip Shooter
A1 A2 B1 B2
A1
B1
B2
A2
460mm
40mm
A1
A2
B1
B2
A1 A2 B1 B2
460mm
40mm
A1
A2
B1
B2
A1 A2 B1 B2
40mm
460mm
- Work Station
- Exit Station
- Entry Station
每月检验
6. 使用注油器通过Work Station, Exit Station, Entry Station的 LM Guide Rail
Nipple注入Grease。
