Installation Manual SIPLACE Engineering Data Manager (EDM) Version 1.9 02/2011 Edition
11 / 65
4 Installation
4.1 Requirements
4.1.1 EDM Master Server
Minimum Requirements
Hardware Intel Pentium 4.3 GHz
2 GB RAM
1 GB hard disk storage capacity
Network connection
Operating system Windows 2003 Server (SP2), Windows XP Professional SP3 (32-bit),
Windows Vista SP2, Windows 7, Windows 2008 Server (preferably 64-bit)
MSMQ runtime must be installed
SIPLACE Pro Version 9.2 Server installation
Microsoft SQL Server Preferably: SQL Server 2008, SQL Server 2008 Express Edition
Supported: SQL2000 SP 4, MSDE 2000 SP4, SQL Server 2005 SP3, SQL
Server 2005 Express SP3
.NET Framework Microsoft .NET 3.5 SP 1
Table 1 EDM Master Server software requirements
CAUTION:
Manually created maintenance jobs can be lost if SQL Server is updated.
Installation Manual SIPLACE Engineering Data Manager (EDM) Version 1.9 Issue 02/2009
12
4.1.2 EDM Line Server
Minimum Requirements
Hardware Intel Pentium 4
1 GB RAM
Network connection
Operating system Windows 2003 Server (SP2), Windows XP Professional SP3 (32-bit),
Windows Vista SP2, Windows 7
MSMQ runtime must be installed
SIPLACE Pro Version 9.2, complete installation
Microsoft SQL Server Preferably: SQL Server 2008, SQL Server 2008 Express Edition
Supported: SQL2000 SP 4, MSDE 2000 SP4, SQL Server 2005 SP3, SQL
Server 2005 Express SP3
.NET Framework Microsoft .NET 3.5 SP 1
Table 2 EDM Line Server software requirements
4.1.3 Clearing Pool / Data Transfer Manager
Minimum Requirements
Hardware Intel Celeron 1.7 GHz
512 MB RAM
Network connection
Operating system Windows 2003 Server (SP2), Windows XP Professional SP3 (32-bit),
Windows Vista SP2, Windows 7
MSMQ runtime must be installed
SIPLACE Pro SIPLACE Pro Desk 9.2
Table 3 Clearing Pool software requirements
Note:
Before installing a Clearing Pool on your local PC that has access to a remote EDM master
you must install SIPLACE Pro Desk on your local system. The local SIPLACE Pro Desk
installation must also have access to the remote EDM Master.
Push mode will also not work properly if this local installation does not access the SIPLACE
Pro server of the configured EDM Master.
4.2 Folder structure
In the following, we will discuss the folder structure created by the default installation.
Installation Manual SIPLACE Engineering Data Manager (EDM) Version 1.9 02/2011 Edition
13 / 65
Programme
SIPLACE
SIPLACE EDM
config
Database
DBScripts
de
en
help
logs
templateStorage
Figure 2 Folder structure of the default installation
Folder Contents
SIPLACE EDM Applications and libraries
config Application configuration, client workflow configuration, filter configuration, email
configuration and logging configuration
Database Database for change notifications and Clearing Pool (Master Server only )
DBScripts Scripts to create and access the database (Master Server only)
de, en, … Language-dependent resources
help Online documentation
logs Log files (for debugging among other things)
templateStorage Storage location for application templates
Table 4 Folders of the default installation
IMPORTANT:
Under Windows Vista, Windows Server 2008 and more recent systems, the
"templateStorage" and "logs" folders are located under
"%ProgramData%\SIPLACE\SIPLACE EDM".
The installation of the components of the system is performed in the following the order:
1. Installation of the EDM Master Server
2. The customer-specific application configuration is copied to the Master Server
3. Installation of the EDM Line Servers
4. The customer-specific application configuration is copied to the Line Servers
5. Installation of the Clearing Pool host
