Wiring Diagram Production Modula r NPM-W2 Model No. NM-EJM7D Model No. NM-EJM7D-MA Model No. NM-EJM7D-MD Model No. NM-EJM7D-A Model No. NM-EJM7D-D N7205A1 10B00 201502
Wiring Diagram
Production Modula
r
NPM-W2
Model No. NM-EJM7D
Model No. NM-EJM7D-MA
Model No.
NM-EJM7D-MD
Model No. NM-EJM7D-A
Model No. NM-EJM7D-D
N7205A110B00
201502
Wiring diagram
D00ABE-00-602-01 Page 1
1.
How to order parts
1. Order details
Make sure to specify the product number, cable ordering part number, part name and quantity of a
part in your order.
2. Order to
Please place your order with your sales company /agent.
[NOTICE]
In the presence of
“Wiring diagram (Custom)
,
”
cables different from the ones listed in
“Wiring
diagram (Standard)”
may be used in the machine.
Therefore, if there is
“Wiring diagram (Custom)
,
”
please specify the cables listed in
“Wiring di-
agram (Custom)”
first and then those in
“Wiring diagram (Standard)
.
”
NM-EJM5D N61012345AA CABLE 1
Product
number
Cable ordering part
number
Part name
Quantity
