BI2000 Board Inverter Manual
Revision F / January 2022
Page 27 of 37
Error Messages
303BThe following are all the possible error messages generated by the PLC program.
76B
MSG #
400BDescription
304B
0
305B
Disengage Emergency Stop
306B0a 307BClose Door (*If Door Bypass Off)
308B
1
309B
Rotate 0 Failure: Remove Board
310B2 311BRotate 180 Failure: Remove Board
312B
3
313B
Board Stop Did Not Extend
314B4 315BBoard Stop Did Not Retract
316B
5
317B
Board Failed to Reach Stops
318B6 319BInlet Shutter Failed to Open
320B
7
321B
Inlet Shutter Failed to Close
322B8 323BOutlet Shutter Failed to Open
324B
9
325B
Outlet Shutter Failed to Close
326B10 327BConveyor Adjust Drive Fault
63BFigure 24: Error Messages
BI2000 Board Inverter Manual
Revision F / January 2022
Page 28 of 37
Maintenance
328B
Interval
329B
Action
330B
Weekly
•
167BClean the sensors with a lint-free damp cloth.
331B
Monthly
•
168BMake sure the conveyor belts are not worn.
• 169BApply grease to the chain.
•
170BCheck the pressure regulator for water and drain if
necessary.
•
171BMake sure the shock absorbers are tight and apply
grease.
Conveyor Belt Replacement
Note: Not all systems have conveyor belts, some have chains.
1.
172BLockout the power supply.
2.
173BRemove the old conveyor belt from the pulley wheels.
3.
174BInstall the belt on the pulley wheels farthest from the motor.
Note: Make sure there are no twists in the belt.
4.
175BInstall the belt around the large pulley wheel, then around the other wheels.
5.
176BRotate the pulley wheels several turns by hand to make sure the belt is correctly
seated.
Board Sensor Adjustment
332BUse a small screwdriver to turn the adjustment screw as necessary.
333B
64BFigure 25: Board Sensor Adjustment Screw
BI2000 Board Inverter Manual
Revision F / January 2022
Page 29 of 37
Board Thickness Adjustment
334BThis procedure will adjust the distance between the chains, there should be a 1mm gap
between the board and the chain. The gap between the upper and lower conveyor chain is
adjustable from 0.28” to 0.154” to reduce product movement during rotation. To adjust the
opening size, perform the procedure below.
Note: Make sure you know the current orientation of the roll cage so that you can
adjust the chain correctly.
Note: Adjust both sides of the conveyer evenly.
1.
177BEngage the Emergency Stop button.
2.
178BTurn the main air pressure to “Off”.
3.
179BLoosen the four shoulder bolts at the end of the turnbuckle. There are four bolts at
each end of the conveyor and each end is adjusted independently.
65BFigure 26: Loosen the Bolts Shown
4. 180BUse a ½” wrench to turn the turnbuckle.
66BFigure 27: Turnbuckle Adjustment
5. 181BWith the shoulder bolts loose, rotate the turnbuckle clockwise to increase the gap or
counterclockwise to reduce the gap.
