Troubleshooting
73B
Troubleshooting
Problem
74B
Possible Cause
75B
Corrective Action
0B
The machine is
On and the
operator
interface has no
power
•
1BCables are loose or not
connected
• 2BA fuse is blown
•
3BExamine the cable connections
and tighten loose connections
• 4BCheck the FU-1 fuse in the
electrical enclosure
5BBoard does not
transfer to or
from adjacent
station
•
6BThe SMEMA
connection is broken
• 7BA module in the line
is turned off
• 8BA fuse is blown
•
9BExamine the cable connections
and tighten loose connections
• 10BTurn the module on
• 11BCheck fuses FU-3 and FU-4 in
the electrical enclosure
12BThe part-in-place
sensor fails
•
13BA cable is loose or not
connected
• 14BThe sensor is positioned
incorrectly
•
15BThe sensor is out of
adjustment
•
16BExamine the cable connections
and tighten loose connections
• 17BMove the sensor
•
18BAdjust the sensor
19BConveyor does
not operate or
communication
error
•
20BConveyor belt stuck to
rails
• 21BChain does not operate
smoothly
• 22BCable is loose or not
connected
• 23BControl relay not on, or
Power On light not on
• 24BA fuse is blown
•
25BClean or replace belt
• 26BApply lubricant to the chain
• 27BExamine the cable connections
and tighten loose connections
• 28BCheck the system voltage and
electrical connections
• 29BCheck fuses FU-10 and FU-11 in
the electrical enclosure
30BPneumatic
position failure
•
31BNo air pressure
• 32BThe air lines are kinked
or torn
•
33BThe sensor is positioned
incorrectly
•
34BThe position sensor is
out of adjustment
•
35BThe rotary is out of
adjustment
•
36BMake sure main air regulator and
main air are both “On” and have
pressure
• 37BRepair or replace the lines
•
38BReplace the sensor
•
39BMove the sensor
•
40BAdjust the rotary
BI2000 Board Inverter Manual
Revision F / January 2022
Page 35 of 37
Notes
BI2000 Board Inverter Manual
Revision F / January 2022
Page 36 of 37
Warranty
347BPVA Warranty Policy
348BPVA warrants the enclosed product against defects in material or workmanship on all
components for one year from the date of shipment.
349BThe warranty does not extend to components damaged due to misuse, negligence, or
installation and operation that are not in accordance with the recommended factory
instructions. Unauthorized repair or modification of the enclosed product, and/or the use of
spare parts not directly obtained from PVA (or from factory authorized dealers) will void all
warranties.
350BAll PVA warranties extend only to the original purchaser. Third party warranty claims will not
be honored at any time.
351BPrior to returning a product for a warranty claim, a return authorization must be obtained
from PVA’s Technical Support department. Authorization will be issued either via the
telephone, facsimile, or in writing upon your request.
352BTo qualify as a valid warranty claim, the defective product must be returned to the factory
during the warranty period. Upon return, PVA will repair (or replace) all components found
to be defective in material or workmanship.
353B(Retain this for your records)
354BProduct Information
355BPRODUCT:
356BSERIAL NUMBER:
357BDATE OF PURCHASE:
