BI2000 Board Inverter Manual
Revision F / January 2022
Page 8 of 37
Do not smoke near the PVA UV cure machine. Always have a fire
extinguisher available for emergency use.
Before performing any repairs or maintenance to the system, turn off power
and lock out the power disconnect switch.
Warning notices are used to emphasize that hazardous voltages, current,
temperatures, or other conditions that could cause personal injury exist in
this equipment or may be associated with its use. Only qualified personnel
should enter areas designated with this symbol.
Laser light source present. Do not stare directly into the beam. Do not use in
the presence of highly reflective surfaces
Pinch hazard from moving parts. Avoid contact.
Hot surface. Avoid contact.
Warning, Ultraviolet (UV) light hazard. Do not look directly at the UV light
source.
BI2000 Board Inverter Manual
Revision F / January 2022
Page 9 of 37
Notices and Warnings
• 77BWear safety glasses, gloves, and long-sleeved clothing when working with
automated industrial equipment.
• 78BRead and understand all operating manuals before using this equipment.
• 79BDo not disable the safety features of the machine.
• 80BLock-out and tag-out the air and power supplies before any service is done.
• 81BReduce the air pressure to 0 psi before any hoses are removed.
• 82BMake sure all replacement parts are correctly rated for use.
• 83BAlways remain clear of all moving parts when the system is in operation.
Personal Protective Equipment
222BOperators must use eye protection because material contents are under pressure. Always
wear gloves when handling materials and solvents. Refer to MSDS sheets on the material
being dispensed for other precautions.
Environmental
Noise Levels
223BThe audible noise level of the board invertor is below 65 dBA.
Materials/Chemicals
224BThere are no dangerous materials or chemicals used in the operation of the machine.
Transportation, Operation, and Storage
Handling and Transportation
225BHandling and transportation should be done with minimal vibration and shock to the
system. An air-ride truck is recommended for roadway transport.
Storage
226BAll enclosures and connector covers should be closed tightly. The system should be
covered if dust or other airborne debris is present in the storage area.
BI2000 Board Inverter Manual
Revision F / January 2022
Page 10 of 37
Temperature and Humidity
227BOperation and storage should be done at 40–105°F (4–41°C) and low humidity. Do not let
condensation collect on the machine. Install the system on a level surface, away from
standing water, possible over spray, and overhead leaks.
Description of Components
228BThe PVA Board Inverter can process and invert multiple boards. It is SMEMA (Surface
Mount Equipment Manufacturers Association) rated for easy integration into a production
line. The unit is designed to operate with PVA workcells.
229BThe operator can control the system with the user interface. The machine status and error
messages are displayed on the LCD screen and the light tower (optional). Operators must
be trained or have read the manual.
230BAny uses other than listed above could result in a dangerous condition and cannot be
protected against by the safety features installed on the system.
231B
41BFigures 1 and 2: Functional Block Diagram and SMEMA Cables and Process Flow
Hazards Due to Contact
232BThe board invertor is designed to minimize injury from contact with the machine. In certain
modes of operation, you can enter the work area while the module is in operation. Only a
qualified person should do this. Examine warning labels.
