Issue 6, Nov 14 11 Objective MO2: State Monitor Areas Identify the areas of the display below

10 Issue 6, Nov 14

Objective MO1: Identify initialisation sequence

Observe the machine as it initializes.

Number these axes in the order that they initialize:

__ Camera X __Front Squeegee

__ Rising table __ Screen actuator Y

NOTES:

Issue 6, Nov 14

Objective MO2: State Monitor Areas

Identify the areas of the display below

12 Issue 6, Nov 14

Objective MO3: Create a product file

Using the board and stencil provided by your instructor create a new product file.

Creating a New Product File From an Existing File

This is often the quickest way to get started. It is the most efficient method if the new

product has similarities in size, process or 2Di to an existing one. There are however,

precautions to remember: always zero any offsets from the old file and never assume that

the under-screen cleaner or paste dispense strategies are transferable - these should

always be confirmed through test and observation.

The board dimensions are width, length and thickness. It is very important that these are

programmed accurately as the printer software uses these values as the basis for many

other board file and machine parameters.

For each board dimension state what other board file parameter or mechanical settings will

be automatically adjusted:

Board Width

Board Length

Board Thickness

NOTES:
