Issue 6, Nov 14 5 Objective A1: Locate the hazardous areas of the machine W arning * Moving machine parts can cause injury . * During this course the machine may be operated with covers removed. * Always remove system po…
4 Issue 6, Nov 14
ET14* Describe linear motor X and Y homing sequence*
ET15* Measure phase to phase resistance of X and Y forcer*
ET16 Describe the homing sequence of each motor type
M-SC Settings and Calibrations
SC1 Backup machine configuration files
SC2 Demonstrate software recovery procedure
SC3 Identify global software machine settings
SC4 Check moving sub-assembly home positions
SC5 Check board clamp setting
SC6 Check conveyor belts
SC7 Check rail-to-table height
SC8 Set vision height
SC9 Check board stop X offset
SC10 Set print height
SC11 Set camera reference position
SC12 Calibrate vision scale
SC13 Calibrate vision offset
SC14 Calibrate squeegee height
SC15 Identify machine related causes of print defects
M-PM Preventative Maintenance
PM1 Carry out recommended monthly maintenance program
PM2 Test and optimize the under-screen cleaner settings
M-BT Benchmark Test
BT1 Interpret SPC output parameters
BT2 Setup machine for benchmark test
BT3 Perform benchmark test and record results
BT4 Identify common causes of poor performance
* Linear Motor objectives are for Galaxy Machines only
Issue 6, Nov 14
5
Objective A1: Locate the hazardous areas of the machine
Warning
* Moving machine parts can cause injury.
* During this course the machine may be operated with covers
removed.
* Always remove system power prior to undertaking any work on
machine.
* Ensure you DO NOT push or press any buttons or operate the
machine until all personnel are clear of danger.
Personal Safety
Tick each safety item as it is demonstrated to you by your instructor:
Strong Magnet Warning (Machines with Linear Motors only)
The linear motors inside the machine contain*
strong permanent magnets.
These may interfere with pacemakers and metallic implants.*
These magnets could potentially erase data on credit cards,*
ID cards etc.
))
((
Board clamps are sharp
Brake is hot
Wear eye protection and gloves when working with solder paste
and solvents.
If in doubt press the E-stop
Do not bypass camsafe switches
ESD Hazard
* The printer contains Electro-Static Sensitive Devices (ESD).
* Do not touch any electronic component of PCB unless wearing
a correctly grounded wrist strap.
Safety Objective
I have been briefed on the above safety aspects and I am fully satised with my
responsibilities..
Sign
Date
6 Issue 6, Nov 14
Objective A2: Locate the main assemblies of the machine
Preparation: Remove front, side and rear Covers
Tick off each sub-assembly as your instructor identifies it to you:
Front and rear safety covers (observe location of cam safe switch)
Monitor assembly
System button and jog buttons
Tri-Colour beacon
Chase assembly
Print carriage
Squeegee assembly / ProFlow
Paste dispenser
Screen load
Screen alignment actuators
Rail system
Camera system
Rising table
Mains isolator switch
Service panel / Circuit breakers
Under screen cleaner
Vacuum unit
NOTES:
