Issue 6, Nov 14 55 Objective SC7: Check rail-to-table height Using the TB340 procedure and Co Planarit y kit, check the rail to table height. NOTES: Objective SC8: Set vision height Carried out in diagnostics - distance …

54 Issue 6, Nov 14

Objective SC5: Check board clamp setting

Using the technical reference manual check the board clamp operation and clearance.

NOTES:

Objective SC6: Check conveyor belts

Check the conveyor belts for damage and stretch.

NOTES:

Issue 6, Nov 14

Objective SC7: Check rail-to-table height

Using the TB340 procedure and Co Planarity kit, check the rail to table height.

NOTES:

Objective SC8: Set vision height

Carried out in diagnostics - distance in millimeters from rising table home position.

NOTES:

Objective SC9: Check board stop X offset

Carried out in diagnostics - a measurement in millimeters which is entered in Maintenance

/ Machine Setup to allow board file compatibility.

NOTES:

56 Issue 6, Nov 14

Objective SC10: Set print height

Carried out in diagnostics - distance in millimeters from rising table home position.

NOTES:

Objective SC11: Set camera reference position

Carried out in diagnostics - distance in millimeters in X and Y from the camera home

position (used for all camera measurements/distances).

NOTES:
