56 Issue 6, Nov 14 Objective SC10: Set print height Carried out in diagnostics - distance in millim eters from rising t able hom e position. NOTES: Objective SC11: Set camera reference position Carried out in diagnostics…

Issue 6, Nov 14

Objective SC7: Check rail-to-table height

Using the TB340 procedure and Co Planarity kit, check the rail to table height.

NOTES:

Objective SC8: Set vision height

Carried out in diagnostics - distance in millimeters from rising table home position.

NOTES:

Objective SC9: Check board stop X offset

Carried out in diagnostics - a measurement in millimeters which is entered in Maintenance

/ Machine Setup to allow board file compatibility.

NOTES:

56 Issue 6, Nov 14

Objective SC10: Set print height

Carried out in diagnostics - distance in millimeters from rising table home position.

NOTES:

Objective SC11: Set camera reference position

Carried out in diagnostics - distance in millimeters in X and Y from the camera home

position (used for all camera measurements/distances).

NOTES:

Issue 6, Nov 14

Objective SC12: Calibrate vision Scale

Carried out in maintenance function - calculates a scaling factor (pixels/mm), the centre of

rotation of the stencil and fiducial capture accuracy for use by the vision system during

alignment.

NOTES:

Objective SC13: Calibrate vision offset

Carried out in maintenance function - calculates the camera offset for use during

alignment.

NOTES:
