18 Issue 6, Nov 14 Objective MO7: Demonstrate how to recover from common error messages Fill in the appropriate recovery actions for the error messages shown in the table below: Message Recovery action Fiducial not found…
Issue 6, Nov 14
17
Objective MO6: Identify print cycle sequence
Observe the machine as it carries out a print cycle.
Number these actions in the correct sequence:
__Camera Moves to Board Stop
position
__Tooling clearance check
__Fiducial positions are captured
__Board travels to Board Stop position
__Press RUN
_ Board is clamped in rails
__Camera homes
__Board lifts to stencil
__Board exits machine
__Board Stop is lowered
__Board separates from stencil
__Stencil alignment completed
__Board is unclamped
__Board stop is raised
__Print stroke carried out
NOTES:
18 Issue 6, Nov 14
Objective MO7: Demonstrate how to recover from common error messages
Fill in the appropriate recovery actions for the error messages shown in the table below:
Message Recovery action
Fiducial not found
Screen cleaner out of position
Rail lift error
Actuator close to limits
Squeegee pressure error
System power down
NOTES:
Issue 6, Nov 14
19
