Objective SC3: Identify global software machine settings
On the machine, view the machine settings, basic parameters menu that contains the
global machine settings
NOTES:
52 Issue 6, Nov 14
Module M-SC
Settings and Calibrations
Issue 6, Nov 14
53
Objective SC4: Check moving sub-assembly home positions
Using the technical reference manuals as a guide measure the home positions of each
axis and complete the details below.
Print Carriage ______ mm to _______mm
Measured from the ____________________________________
to the________________________________________________
adjusted by ___________________________________________
Rising Table ______ mm to _______mm
Measured from the ____________________________________
to the________________________________________________
adjusted by ___________________________________________
Rear Rail ______ mm to _______mm
Measured from the ____________________________________
to the________________________________________________
adjusted by ___________________________________________
Note: There is no home setting for camera X and Y.
NOTES:
