User Manual SIPLACE S-23 HM 1 Introduction, technical data
Software Version SR.406.xx 02/00 US Edition 1.5 Description of the machine
27
1.5.3 Technical data - machine overview
* The SIPLACE S-23 HM can be equipped to place 0201 components.
(Please contact the factory for details).
Procedure Collect&place
Range of components From 0402 (0201 *) to 18.7 mm x 18.7 mm
Maximum placement speed of the12-seg-
ment revolver head (DLM1)
23,000 components/hour
Cycle time at the revolver head 125 ms, regardless of the type of component
Angular accuracy
Placement accuracy
± 0.525°/ 3 σ, ± 0.70°/ 4 σ, ± 1.05°/ 6 σ
± 67.5µm / 3 σ, 90µm / 4 σ, 135µm / 6 σ
PCB format 50mm x 50mm to 460mm x 460mm
(optionally 460mm x 508mm,18" x 20")
Feeder capacity 40 locations for feeders
Types of feeder Component tapes, stick magazines, bulk cases
Operating system Microsoft Windows NT / RMOS
Combination options Inline or stand-alone
Space required 4 m² / module
1 Introduction, technical data User Manual SIPLACE S-23 HM
1.6 The line concept Software Version SR.406.xx 02/00 US Edition
28
1.6 The line concept
1.6.1 Overview
The placement system can be linked to input and output stations, screen printing systems, sol-
dering ovens and other automatic placement systems from the SIPLACE range (HS-50, S-20,
F4, F5, and the SIPLACE G glue application station). All SIPLACE modules are supplied with the
necessary data by the UNIX line computer. The placement system can also be linked to a higher
level data processing system through the use of suitable interfaces.
1.6.2 Technical data – line concept
1
*) SIPLACE HS-50, SIPLACE 80 S-20, SIPLACE 80 S-23 HM or SIPLACE 80 F
4
with 12-segment
revolver head 1
**) SIPLACE 80 F
4
/F
5
/F
5
HM 1
1
1
System SIPLACE placement lines
Modules SIPLACE HS-50 / SIPLACE 80 S-20 / SIPLACE S-23 HM
SIPLACE 80 F
4
/ SIPLACE F
5
/ SIPLACE F
5
HM
Peripherals Input/output stations
Screen printers
Soldering ovens
Inspection stations, etc.
Component range From 0402 * to 55 mm x 55 mm **
PCB conveyor Automatic width adjustment
PCB format 50 mm x 50 mm to 460 mm x 460 mm
Placement rate Depends on how the modules are connected to one another
Space required 4 m² / SIPLACE 80 module
7.5 m² / SIPLACE HS-50 module
User Manual SIPLACE S-23 HM 1 Introduction, technical data
Software Version SR.406.xx 02/00 US Edition 1.7 Connection data for the placement system
29
1.7 Connection data for the placement system
1.7.1 Electrical and pneumatic connection points on the placement system
1
Fig. 1.7 - 1 Electrical and pneumatic connection points on the placement system
(1) Compressed air unit
(2) Connection for compressed air line
(3) Main power filter Z1
(4) Hole for power cable
(5) Service socket
(6) Compressed air supply connection for component changeover table
(7) Power supply connection for component changeover table
(8) Communications connection for component changeover table
(9) LAN connection in the control unit
(10) Main power switch
