EDM V1.10 / Installation Manual 07/2011 Edition
3.3 Push mode
In push mode, the data preparation engineer selects the data he or she wishes to make available
to the lines they are responsible for. Under a graphical user interface, they use an application
template (see section 5.4.1 Application templates)) to select one or more line and the objects (e.g.
optimized recipes) that they want to transfer to the selected line(s). Depending on the settings in
the configuration, the line engineer is forced to accept these changes immediately or later, or can
reject them, or is simply informed of the receipt of changed data. With the EDM Data Transfer
Manager, the data preparation engineer always has an overview of the status of the individual
transfer packages on the EDM lines.
In contrast to the two pull mode variants, sovereignty over the status of the data in push mode
lies largely with the data preparation engineer.
Push mode and pull mode should be used independently. EDM can be operated in mixed mode
without problems.
12
EDM V1.10 / Installation Manual 07/2011 Edition
4 Installation
4.1 Requirements
4.1.1 EDM Master Server
Minimum Requirements
Hardware Intel Pentium 4.3 GHz
2 GB RAM
1 GB hard disk storage capacity
Network connection
Operating system Windows 2003 Server (SP2), Windows XP Professional SP3
(32-bit), Windows Vista SP2, Windows 7, Windows 2008 Server
(preferably 64-bit)
MSMQ runtime must be installed
SIPLACE Pro Version 9.3 Server installation
Microsoft SQL Server Preferably: SQL Server 2008, SQL Server 2008 Express Edition
Supported: SQL2000 SP 4, MSDE 2000 SP4, SQL Server 2005
SP3, SQL Server 2005 Express SP3
.NET Framework Microsoft .NET 3.5 SP 1
Table 4-1: EDM Master Server software requirements
CAUTION
Manually created maintenance jobs can be lost if SQL Server is updated.
13
EDM V1.10 / Installation Manual 07/2011 Edition
4.1.2 EDM Line Server
Minimum Requirements
Hardware Intel Pentium 4
1 GB RAM
Network connection
Operating system Windows 2003 Server (SP2), Windows XP Professional SP3
(32-bit), Windows Vista SP2, Windows 7
MSMQ runtime must be installed
SIPLACE Pro Version 9.3, complete installation
Microsoft SQL Server Preferably: SQL Server 2008, SQL Server 2008 Express Edition
Supported: SQL2000 SP 4, MSDE 2000 SP4, SQL Server 2005
SP3, SQL Server 2005 Express SP3
.NET Framework Microsoft .NET 3.5 SP 1
Table 4-2: EDM Line Server software requirements
4.1.3 Clearing Pool / Data Transfer Manager
Minimum Requirements
Hardware Intel Celeron 1.7 GHz
512 MB RAM
Network connection
Operating system Windows 2003 Server (SP2), Windows XP Professional SP3
(32-bit), Windows Vista SP2, Windows 7
MSMQ runtime must be installed
SIPLACE Pro SIPLACE Pro Desk 9.3
Table 4-3: Clearing Pool software requirements
CAUTION
Before installing a Clearing Pool on your local PC that has access to a remote EDM
master you must install SIPLACE Pro Desk on your local system. The local SIPLACE
Pro Desk installation must also have access to the remote EDM Master.
Push mode will also not work properly if this local installation does not access the
SIPLACE Pro server of the configured EDM Master.
14
