EDM V1.10 / Installation Manual 07/2011 Edition 5.2.3.3 Distribution list for EDM notifications Key: notificationDistributorClass Type: Class Default: Siemens.SiplacePro.EDM.DataExchange.EmailDistributor, DataExchange Va…
EDM V1.10 / Installation Manual 07/2011 Edition
templateStorage Path L;M;D Storage location for
application templates
(5.2.3.23)
transceiverClass Class L;M;C;T;D Class of data transfer
(5.2.3.8)
useAdvancedNotification
Filtering
String
(true/false)
M;D Activate/deactivate direct
import/rejection of
notifications in the Master
Server (5.2.3.17)
useModifiedObjectProtection String
(true/false)
L;D Forced overwriting of
changed objects with older
master data (5.2.3.18)
useBlobExtension String
(true/false)
L;M;D Activates/deactivates EDM
VDM BLOB extensions
(5.2.3.32)
xmlImportVisionData
AdvancedAction
Integer L;M;C;D Sets the
VisionDataAdvancedAction
property of XmlImport.
Table 5-3: Contents of the configuration file
5.2.3.1 Server type
Key: serverType
Type: Enum
Values: LINE
MASTER
BOTH
CLEARINGPOOL
Valid for: Line server
Master server
Clearing pool
Description: Specifies the type of installation. The EDM server is started as a Line Server,
Master Server or hybrid depending on this setting (should only be used for test
purposes).
5.2.3.2 Help folder
Key: helpDirectory
Type: Path
Default: [AppDir]\help
Valid for: Line server
Master server
Clearing pool
EDM Tool
Description: Folder for online documentation
31
EDM V1.10 / Installation Manual 07/2011 Edition
5.2.3.3 Distribution list for EDM notifications
Key: notificationDistributorClass
Type: Class
Default: Siemens.SiplacePro.EDM.DataExchange.EmailDistributor,
DataExchange
Valid for: Master server
Description: Class, i.e. implementation of the notification service. At the present, distribution via
email is available using the default value as a reference.
5.2.3.4 Configuration of EDM notification traffic
Key: notificationDistributorConfiguratorClass
Type: Class
Default: Siemens.SiplacePro.EDM.UserInterface.EmailConfigurator,
UserInterface
Valid for: Master server
Description: Configuration dialog box for the notification service. The actual configuration of the
notification service depends on its implementation. Configuration of an email
service referenced using the default value is currently supported.
5.2.3.5 Notification interval
Key: notificationInterval
Type: Time
Default: P0Y0M0DT0H15M0S (= 15 minutes)
Valid for: Line server
Description: Time period during which the change notifications will be collected on the Line
Servers before they are sent to the Master Server. The other options are as follows
(from left to right):
Y = years
M = months
D = days
H = hours
M = minutes
S = seconds
The period should not be shorter than 5 minutes.
5.2.3.6 Notification storage
Key: notificationStorage
Type: Endpoint
Default: notificationStorage
Valid for: Line server
Description: Buffer for collected change notifications.
32
EDM V1.10 / Installation Manual 07/2011 Edition
5.2.3.7 Master server
Key: masterServer
Type: String
Valid for: Line server
Master server
Clearing pool
Description: Network ID of the Master Server. Windows computer name only. IP addresses are
not permitted.
5.2.3.8 Transceiver
Key: transceiverClass
Type: Class
Default: Siemens.SiplacePro.EDM.DataExchange.MsmqTransceiver,
DataExchange
Valid for: Line server
Master server
Clearing pool
EDM Tool
Description: Implements the data transfer between the Line Servers and Master Server. This
entry must be identical on all installed systems. The exact format of the "endpoint"
values depend on this value. The default setting uses MSMQ to transfer the data.
Endpoint: An endpoint entry has the following format for the MSMQ transceiver:
Private$\[queue-name].
Note that private queues absolutely must be used here. Only private queues can
be used in both a domain/active directory-based network environment as well as in
a pure workgroup installation.
5.2.3.9 Outgoing requests
Key: masterRequests
Type: Endpoint
Valid for: Line server
Clearing pool
Description: Target address for service requests sent by a Line Server to the Master Server.
The setting must be identical to the Incoming Requests setting on the Master
Server.
5.2.3.10 Outgoing change notifications
Key: masterNotifications
Type: Endpoint
Valid for: Line server
Description: Target address for change notifications sent by a Line Server to the Master Server.
The setting must be identical to the incoming change notifications setting on the
Master Server.
