EDM V1.10 / Installation Manual 07/2011 Edition 5.2.3 Configuration file The configuration file is an XML-base d file that uses the format of the Microsoft configuration files. The configuration file for all EDM applica …

EDM V1.10 / Installation Manual 07/2011 Edition

● SIPLACE Pro lines:

The SIPLACE Pro lines for which each Line Server is responsible must be configured:

– If the EDM VDM BLOB functions are to be used (especially for the Extended Difference

Editor)

– If protection against overwriting current product data is to be activated in push mode (see

section 5.2.4.4 Protection against overwriting current production data).

Otherwise, BLOBs will be accepted for all SIPLACE Pro lines present in the local SIPLACE Pro

database (see section 5.2.3.24 Assigned SIPLACE Pro lines).

● The configuration setting

xmlImportVisionDataAdvancedAction controls the correct

overwriting of Vision data (if the EDM VDM BLOB functions are used, this entry can be

modified as described in section 5.2.3.33 Advanced vision data actions.

● Comment categories:

These categories are available for selection when entering a comment on a new notification. If

this section is empty, no categories are shown in the dialog box (see section 5.2.3.29 Comment

categories).

5.2.2 Registry

This section describes the part of configuration performed using the Windows Registry. This

includes all user-defined settings as well as all settings that need to be accessed before the

application starts. The installation program presets these with sensible values.

All keys are sub-keys of HKEY_LOCAL_MACHINE\Software\Siemens\SIPLACE\EDM

Key Type Contents

ConfigDir String Folder for configuration files. If the key is not present,

then the search continues in the "config" subfolder of the

installation folder.

EdmServiceLanguage String Language setting for the EDM Master Server and Line

Servers. Default: English. Can be changed in the EDM

configuration.

EdmClientLanguage String Language setting for the EDM Client. Default: English.

Can be changed in the EDM Client.

ClearingPoolLanguage String Language setting for the Clearing Pool and Line Data

Transfer Manager. Default: English. Can be changed in

the Clearing Pool.

Table 5-1: Entries in the Registry

EDM V1.10 / Installation Manual 07/2011 Edition

5.2.3 Configuration file

The configuration file is an XML-based file that uses the format of the Microsoft configuration files.

The configuration file for all EDM applications is named EDM.config and is located in the

configuration folder. A change therefore applies, for example, to both the EDM master service as

well as to the Clearing Pool installed on this computer.

NOTICE

A change only takes effect after the applications are restarted.

The permitted keys used are described in brief in Table 5-3. The individual entries are specified in

details in the sections 5.2.3.1 Server type to 5.2.3.34 Customer configuration. For purposes of

legibility, abbreviations are used in the table. The abbreviations are explained in brief in Table 5-2.

Table entry Meaning

Enum Enumeration type. The ordinals valid for each key are shown in the

corresponding explanation.

String Character string

Time Time specification in the format "P0Y0M0DT0H15M0S"

Class .NET class in the format [ClassName][,Assembly]

Path Windows path specification

File Windows file specification

Endpoint Communication endpoint. The exact format depends on the transfer protocol.

Section Subsection with several values. The entries valid for each key are shown in the

corresponding explanation.

C Valid for: Clearing Pool

L Valid for: Line Server

M Valid for: Master Server

T Valid for: EDM Tool

R Required

D Default value. Input is only necessary if a different setting is desired.

Table 5-2: Legend

EDM V1.10 / Installation Manual 07/2011 Edition

Example: basic structure of an EDM configuration file

<!- - This is a comment - - >

Value

</appSettings>

<! - - This is a configuration parameter of the type "Section" - ->

</endpointConfig>

<! - - These are the services provided by the Master Server - - >

<add key="objectData" value=

"Siemens.SiplacePro.EDM.DataExchange.Commands.RequestDataCommand,DataExchange"

</requestCommandConfig>

</configuration>

The keys and sections permitted are listed in the following table:

Key Format Type Contents

clientWorkflowConfig File L;D File with EDM Client

process definition (5.2.3.21)

commentCategories Section M;T Comment categories for

change notifications

(5.2.3.29)

communicationTimeout Time L;M;C;D Timeout for communication

between line and Master

Server (5.2.3.16)

compressionType Enum L;M;C;D Compression for data

transfer (5.2.3.20)

customConfig Section L;M ;C ;T Space for additional

attributes (5.2.3.32)

edmToolEndPoint Endpoint L;M;T;R End point for messages to

the EDM tool. (5.2.3.14)

endpointConfig Section M;R Endpoint configuration for

the exchange of data (0)

helpDirectory Path L;M;C;T;D lp files (5.2.3.2) Path for he

incomingClearingPoolRequests int

Pool

Endpo M;C;R Endpoint for incoming

queries to the Clearing

(5.2.3.13)

incomingNotifications Endpoint M;R r incoming

the

Endpoint fo

change notifications to

master (5.2.3.12)

Endpoint

Time Key

Section

Class
