EDM V1.10 / Installation Manual 07/2011 Edition

Example: basic structure of an EDM configuration file

<!- - This is a comment - - >

Value

</appSettings>

<! - - This is a configuration parameter of the type "Section" - ->

</endpointConfig>

<! - - These are the services provided by the Master Server - - >

<add key="objectData" value=

"Siemens.SiplacePro.EDM.DataExchange.Commands.RequestDataCommand,DataExchange"

</requestCommandConfig>

</configuration>

The keys and sections permitted are listed in the following table:

Key Format Type Contents

clientWorkflowConfig File L;D File with EDM Client

process definition (5.2.3.21)

commentCategories Section M;T Comment categories for

change notifications

(5.2.3.29)

communicationTimeout Time L;M;C;D Timeout for communication

between line and Master

Server (5.2.3.16)

compressionType Enum L;M;C;D Compression for data

transfer (5.2.3.20)

customConfig Section L;M ;C ;T Space for additional

attributes (5.2.3.32)

edmToolEndPoint Endpoint L;M;T;R End point for messages to

the EDM tool. (5.2.3.14)

endpointConfig Section M;R Endpoint configuration for

the exchange of data (0)

helpDirectory Path L;M;C;T;D lp files (5.2.3.2) Path for he

incomingClearingPoolRequests int

Pool

Endpo M;C;R Endpoint for incoming

queries to the Clearing

(5.2.3.13)

incomingNotifications Endpoint M;R r incoming

the

Endpoint fo

change notifications to

master (5.2.3.12)

Endpoint

Time Key

Section

Class

EDM V1.10 / Installation Manual 07/2011 Edition

incomingRequests Endpoint M;R Endpoint for incoming

queries to the master

(5.2.3.11)

machineAliasNames Section L;M;C;R Assignment of readable

names to the network IDs of

the individual EDM

computers (Line Servers,

Clearing Pool, etc.)

(5.2.3.31)

masterNotifications Endpoint L;R Destination for change

notifications (5.2.3.10)

masterRequests Endpoint L;C;R Requests to the Master

Server (5.2.3.9)

masterServer String L;M;C;R Network identification of the

Master Server (5.2.3.7)

notificationDistributorClass Class M;D Class for external

notifications (e.g. email)

notificationDistributor

ConfiguratorClass

Class M;D Configuration for external

notification system (e.g.

email) (5.2.3.4)

notificationInterval Time L;D Time to transfer the change

notification to the master

(5.2.3.5)

notificationStorage Endpoint L;D Temporary storage for

change notifications

responseTimeout Time L;D Timeout for replies from the

master (5.2.3.19)

requestCommandConfig Section M;R Scope of functionality of

Master Server (5.2.3.30)

serverType Enum L;M;C;R Operating mode of the

installation (5.2.3.1)

serviceRemotingEndpoint String L;R .NET remoting configuration

for communication with the

line service (5.2.3.22)

spiLines Section L SIPLACE Pro lines

associated with this Line

Server. (5.2.3.24)

startingPoints Section M List of permissible object

types for starting points

(5.2.3.28)

sqlDataSource String C;M;R SQL Server access for the

Clearing Pool (5.2.3.24)

sqlUserName String C;M;R User name for SQL Server

access (5.2.3.26)

sqlUserPassword String C;M;R Password for SQL Server

access (5.2.3.27)

EDM V1.10 / Installation Manual 07/2011 Edition

templateStorage Path L;M;D Storage location for

application templates

(5.2.3.23)

transceiverClass Class L;M;C;T;D Class of data transfer

(5.2.3.8)

useAdvancedNotification

Filtering

String

(true/false)

M;D Activate/deactivate direct

import/rejection of

notifications in the Master

Server (5.2.3.17)

useModifiedObjectProtection String

(true/false)

L;D Forced overwriting of

changed objects with older

master data (5.2.3.18)

useBlobExtension String

(true/false)

L;M;D Activates/deactivates EDM

VDM BLOB extensions

(5.2.3.32)

xmlImportVisionData

AdvancedAction

Integer L;M;C;D Sets the

VisionDataAdvancedAction

property of XmlImport.

Table 5-3: Contents of the configuration file

5.2.3.1 Server type

Key: serverType

Type: Enum

Values: LINE

MASTER

BOTH

CLEARINGPOOL

Valid for: Line server

Master server

Clearing pool

Description: Specifies the type of installation. The EDM server is started as a Line Server,

Master Server or hybrid depending on this setting (should only be used for test

purposes).

5.2.3.2 Help folder

Key: helpDirectory

Type: Path

Default: [AppDir]\help

Valid for: Line server

Master server

Clearing pool

EDM Tool

Description: Folder for online documentation
