Parameters
Setting Default Valid for Explanation
LineDataTransferStatusMonitor.
OldEntriesThreshold
30 days Data
Transfer
Manager
Specifies the period after
which an entry in the status
monitor is classified as "old" in
the Data Transfer Manager
(and is therefore removed with
the Delete old entries
button).
History.MaxiumLength 10 Data
Transfer
Manager
Maximum number of history
entries in the Data Transfer
Manager.
Table 5-9: Settings for data transfer - parameters
5.2.5 Configuration of the VDM BLOB functions
To use the VDM BLOB functions, the names of the SIPLACE Pro lines assigned to each Line
Server must be entered in the Line Server's configuration file (see section 5.2.3.24 Assigned
SIPLACE Pro lines). If this section is left empty, BLOBs are accepted for all lines.
45
EDM V1.10 / Installation Manual 07/2011 Edition
5.3 Configuration of the workflow
The production process design varies greatly from customer to customer, which means the data
storage process also varies. Two aspects in particular stand out in this regard:
● the actual process of data flow – the dynamic part – between the central server (EDM Master
Server) and the local clients (EDM Line Servers)
● the type and amount of data to be transferred – the static part.
Both parts of the process may differ, though, in customer processes. This section deals with the
dynamic part, the actual control of the flow of data. The configuration of the static part – the
application templates – is dealt with in 5.4.1 Application templates.
NOTICE
The workflow only needs to be configured if the default values do not work in your
environment.
5.3.1 Theory
The production process of the customer is depicted in a workflow using a finite state machine. A
finite state machine is a concept from theoretical computer science. It helps to know a little
terminology to understand this concept.
A finite state machine generally consists of:
● a set of states. In the following, this set is called Q.
● exactly one start state belonging to Q.
● a subset of Q that contains the valid end states.
● a subset of Q that contains the error states.
● a set of Events.
● a set of state transitions that cause a state q
1
to move to state q
2
when a certain event occurs.
A maximum of one transition can be defined for each state/event pair.
5.3.2 Application
5.3.2.1 Syntax and options
The theory presented in the previous section must now be implemented in a manageable form for
actual use. This is done in the client workflow configuration file (see also section 5.2.3.21 Client
workflow configuration). This file is in XML format. The following text deals with the contents of this
file and how they relate to the theory.
46
EDM V1.10 / Installation Manual 07/2011 Edition
When starting, you will first need to declare all states, events and transitions. This is necessary so
that the workflow engine operating on the configuration file can more easily verify the finite state
machine.
First, we define the start state:
<state name="clientIdle" isStartState="true" />
In the following state declarations, isStartState="true" is not allowed to appear any more
because a finite state machine has exactly one start state.
A "normal" state is declared:
<state name="selectObjects" />
This state is marked as an end state:
<state name="done" isEndState="true" />
Error states are declared as follows:
<state name="timedOut" isErrorState="true" />
A state can be an error state and an end state at the same time:
<state name="failed" isErrorState="true" isEndState="true" />
The names of the states must be unique. Next, the events that the workflow engine can react to are
declared in the configuration file:
<event name="pullData" />
The names of the events also need to be unique because they are referenced in the definitions of
the transitions just like the states.
The transitions are the heart of the workflow definition. They are a kind of "building block" that can
be used to model a customer workflow.
They determine the reactions to incoming events. Every transition can execute any number of
actions when triggered by an event. To permit a certain degree of control, a transition can be
equipped with a special action that has a return value. Such actions are called controllers. In this
case, the initial state, event and result of the action are passed to the next state. An example of this
is shown below:
