- 5 -
Operability
① Displaying the graphics in rich facilitated an ease of operating the data inputs
② Key operations can be made easier by using a touch panel.
③ Provided with an option of feeder position indicator (FPI), the stocked components run
out or warns that the number of the remaining components is below the regulated
number with lighting the corresponding LED. This feature indicates which feeder is to
be replaced. (Option)
④ In addition to display the language (English, Japanese and Chinese) the display can
be switched in real time.
⑤ Installing a USB port permits using a memory unit such as USB flash memory.
This allows you to move a production program more easily.
⑥ The database sharing with two or more machines becomes possible by enabling the
external PC to edit the "Component database" that recorded data for the sizes of
components and the vision recognition data.
High Maintainability
① The maintainability has been enhanced by displaying the screens of pick-up
frequencies per nozzle and of X/Y axis traveling distances to call a checking time, in
addition to the hour meter (energized hours).
② Protecting the passwords has hierarchically stratified the maintenance levels to
increase a degree of freedom in setting the machines.
③ A head filter is installed in the upper part of the head to facilitate replacement.
Response to the safety standards
① The machine marked with Europe CE directive is added to the line-up.
(KE-3010AC is excluded.)
Environment and energy saving
① Power consumption has been reduced by 25% by adopting AC servomotor and ball screw
control for the axis control compared with the former machine. The energy efficiency has
been thus improved. (Compared with KE-2080)
- 6 -
3.
System Configuration Table
○: Equipped as standard ●: Option -: No setting
KE-3010A
KE-3010AC
KE-3020VA
KE-3020VRA
Basic configuration
Placement head
○
○
○
○
LNC60 (laser recognition head)
○
*11
○
*11
○
*11
○
*11
LNC61 (laser recognition head)/Placement monitor
●
*1 *12
●
*1 *12
-
-
LNC62 (laser recognition head)/Placement monitor
- -
●*1 *12 ●*1 *12
IC head (CDS)
-
-
○
-
IC head (FMLA)
-
-
-
○
OCC L (offset collection camera)
○ ○ ○ ○
OCC R (offset collection camera)
-
-
○
○
HMS (height measuring unit)
○
○
○
○
BMR (bad mark reader)
●
*1
●
*1
●
*1
●
*1
Multi-code reader
●
*1
●
*1
●
*1
●
*1
Vision recognition unit
●*1
-
○ ○
MNVC
●
*1 *2
-
○
○
Component recognition camera（VCS）
●*1 *2
-
○ ○
Standard camera
●
*1
-
○
○
High-resolution camera
●
*1
-
●
*1
●
*1
Power supply unit
○ ○ ○ ○
Emergency stop button
○
○
○
○
ATX power supply (with UPS function)
○
○
○
○
Electric leakage breaker
●*1 ●*1 ●*1 ●*1
I/O control unit
○
○
○
○
Motor control unit
○
○
○
○
X-Y control unit
○ ○ ○ ○
Interior/exterior finish and equipment
○
○
○
○
Signal light (with buzzer)
○
○
○
○
Mini signal light
●*1 ●*1 ●*1 ●*1
Super foot
●
*1
●
*1
●
*1
●
*1
Caster
●
*1 *3
●
*1 *3
●
*1 *3
●
*1 *3
Pneumatic device piping system
○ ○ ○ ○
Air regulator
○
○
○
○
Vacuum pump
○
○
○
○
Main line filter
- - - -
PWB transport unit
○
○
○
○
Placement station
○ ○ ○ ○
External shape reference
○
○
○
○
Pin reference
●
*1 *4
●
*1 *4
●
*1 *4
●
*1 *4
Auto PWB width adjustment unit
●*1 ●*1 ●*1 ●*1
L-Wide PWB
●
*1 *5
●
*1 *5
●
*1 *5
●
*1 *5
Longer sized PWB in X axis
●
*1
●
*1
●
*1
●
*1
Solder recognition lighting
●*1 ●*1 ●*1 ●*1
Component quantity control
●
*1
●
*1
●
*1
●
*1
Operation system
○
○
○
○
Liquid crystal display
○ ○ ○ ○
Keyboard with Trackball
○
○
○
○
SSD
○
○
○
○
Communication port Ethernet
○ ○ ○ ○
USB port
○
○
○
○
Rear-side operation unit
●
*1
-
●
*1
●
*1
HOD
●
*1
●
*1
●
*1
●
*1
- 7 -
KE-3010A
KE-3010AC
KE-3020VA
KE-3020VRA
DVD/CD-ROM drive (USB)
● ● ● ●
FD drive (USB)
●
●
●
●
Equipment device
Feeder float sensor
○ ○*16 ○ ○
Automatic tool change unit (ATC)
○
○
○
○
Large-shape component scrap box
-
-
○
○
Flexible calibration system（FCS）
○ ○ ○ ○
FCS adjusting jig
●
●
●
●
Feeder position indicator (FPI)
●*1 ●*1 *16 ●*1 ●*1
SOT direction inspection table
●
*1
●
*1
●
*1
●
*1
Component verification (CVS)
●
*1
●
*1
●
*1
●
*1
Coplanarity
●*1 *6 - ●*1 ●*1
Ionizer
●
*1
●
*1
●
*1
●
*1
Fluxer: Type 2 (To be attached on the main unit)
●*1 *13 *14
-
●*1 *13 *14 ●*1 *13 *14
Simplified load control
●
*1
●
*1
●
*1
●
*1
Solder print recognition placement position correction
●
*1
●
*1
●
*1
●
*1
Bottom View type multi-code reader
●
*1
●
*1
●
*1
●
*1
Production support system
Component database
○
*7
○
*7
○
*7
○
*7
External programing unit (EPU)
● ● ● ●
Floor productivity operating system
Production support system
・
IS
●
●
*17
●
●
・
IS Lite
●
●
*17
●
●
・
JaNets
●
●
*17
●
●
Production management system
・
IFS-NX
●
●
*17
●
●
White list type anti-virus software
○
○
○
○
Feeder bank (Mechanical type)
Mechanical feeder bank (fixed type)
○
○
*16
○
○
Mechanical overall change table system
●
*1
●
*1 *16
●
*1
●
*1
Overall change table for mechanical feeder
●*1 ●*1 *16 ●*1 ●*1
Intelli trolley for mechanical feeder
●
*8
●
*8 *16
●
*8
●
*8
Connector bracket
●
*1
●
*1
●
*1
●
*1
IC collection belt
● ● ● ●
Component supply unit
Tape feeder/bulk feeder
●
*8
●
*8
●
*8
●
*8
Stick feeder / Stacked stick
●*8 ●*8 ●*8 ●*8
Tray supply unit
MTC *14
●
*8 *9
-
●
*8 *9
●
*8 *9
MTS
●*8 *9 - ●*8 *9 ●*8 *9
DTS
●
*8 *9
-
●
*8 *9
●
*8 *9
Tray holder
●
*8 *9
-
●
*8 *9
●
*8 *9
Fluxer: Type 3 (To be attached on a bank/rear side only)
●*1 *13 - ●*1 *13 ●*1 *13
Rotary-type solder transfer device
(To be attached on a bank/front side only)
●*1 *13
-
●*1 *13 ●*1 *13
Feeder setup stand for E-feeder
● ● ● ●
Tape cutter
●
●
●
●
Trash box
●
●
●
●
Wafer supply unit
T Multi-die server (DF01)
●
*15
-
●
*15
●
*15
