9.
Safety specifications
9.1. Standards specifications
Emergency stop
The machine is provided with the two (2) emergency stop buttons each at the front and
rear sides. (The one (1) emergency stop button is provided when the optional HOD is
attached on the machine.) Depressing these emergency stop buttons immediately stops
each axis to cut off the power supply for driving the motors.
Safety covers
The machine is provided with covers, each at the front and rear sides, for both of which
the cover open switch detects either status of opening or closing to suspend the
continuous operation temporarily upon opening either cover or both. Moreover, the
machine is provided with the "Switching key" on the operation panel that switches
"Maintenance mode" or "Operation mode" to perform switching operation of safety
covers according to each mode.
･ Operation mode
It is a mode that enables a safety cover to be locked, and limits opening of cover during
normal production. Moreover, it releases the safety cover from being locked in
operation, and frees the servomotor "SERVO FREE state" for the safety operation
while the safety cover opens.
･ Maintenance mode
It is a mode that enables the low-speed operation while a safety cover is not locked
and opened, and is used for maintenance.
9.2. Specifications for the CE Marking (for EN Machine)
This shall comply with the following EC (European committee) instructions
− EC mechanical instructions： 2006/42/EC
− EC EMC instructions： 2014/30/EU
Applicable standard
・Machinery Directive EN ISO12100-1:2003, EN ISO12100-2:2003, EN ISO14121-1:2007,
EN ISO13849-1:2008, EN 60204-1: 2006, others
・EMC Directive EN 61000-3-2: 2006, EN 61000-3-3: 1995/A1: 2001/A2: 2005,
EN 61000-3-11: 2001, EN 61000-6-4: 2007, EN 55016-1-2 : 2004,
EN 55016-2-1: 2004, EN 55016-2-3 : 2006, EN 61000-6-2: 2005,
EN 61000-4-2: 1995/A1: 1998/A2: 2001, EN 61000-4-3: 2006,
EN 61000-4-4: 2004, EN 61000-4-5: 2006, EN 61000-4-6: 2007,
EN 61000-4-8: 1998, EN 61000-4-11: 2004
- 74 -
10.
Reliability specifications
10.1. Lifetime of devices
For five (5) years： Excluding either the consumable components or the following
regularly replaceable components.
Refer to the Instruction Manual for the details.
− Periodic replacement parts: These must be replaced at intervals of 2 to 3 years as
standard. (The replacement interval varies depending on the operating conditions.)
Criteria for calculating the lifetime
：
22 hours per day
300 days per year
Therefore, 22 x 300 x 5 = 33,000 hours/5 years
Cableveyor
Bare cable assembly
Air tube
Optical fiber cable (in a plastic rail)
1394 robot cable assembly
Magnetic scale wiper
Filter element
Gas spring
Battery unit
Mouse
HOD
Cutter unit
Electric feeder IF cable assembly
Ionizer (electrode section)
◆
Revision record
Rev. Date Revised locations Revision contents Remarks
00 Jul.2014 First Edition
01 Aug.2014 P6,10,20,42
Corresponded
IS Lite Ver3.00
Revised
02 May.2015 P4,7,43
Addition of the specifications for
using both a mechanical feeder and
an electric feeder
Revised
03 Jul. 2016 Fully revised Support of RF series Electric feeder Revised
04 Dec. 2016 P72 EC EMC instructions Revised
05 May. 2017 Fully revised Support of JaNets Revised
06 Jul. 2017 Fully revised Support of JaNets Revised
07 Jan. 2018 Fully revised Support of Ver8.20A Revised
