- 6 -
3.
System Configuration Table
○: Equipped as standard ●: Option -: No setting
KE-3010A
KE-3010AC
KE-3020VA
KE-3020VRA
Basic configuration
Placement head
○
○
○
○
LNC60 (laser recognition head)
○
*11
○
*11
○
*11
○
*11
LNC61 (laser recognition head)/Placement monitor
●
*1 *12
●
*1 *12
-
-
LNC62 (laser recognition head)/Placement monitor
- -
●*1 *12 ●*1 *12
IC head (CDS)
-
-
○
-
IC head (FMLA)
-
-
-
○
OCC L (offset collection camera)
○ ○ ○ ○
OCC R (offset collection camera)
-
-
○
○
HMS (height measuring unit)
○
○
○
○
BMR (bad mark reader)
●
*1
●
*1
●
*1
●
*1
Multi-code reader
●
*1
●
*1
●
*1
●
*1
Vision recognition unit
●*1
-
○ ○
MNVC
●
*1 *2
-
○
○
Component recognition camera（VCS）
●*1 *2
-
○ ○
Standard camera
●
*1
-
○
○
High-resolution camera
●
*1
-
●
*1
●
*1
Power supply unit
○ ○ ○ ○
Emergency stop button
○
○
○
○
ATX power supply (with UPS function)
○
○
○
○
Electric leakage breaker
●*1 ●*1 ●*1 ●*1
I/O control unit
○
○
○
○
Motor control unit
○
○
○
○
X-Y control unit
○ ○ ○ ○
Interior/exterior finish and equipment
○
○
○
○
Signal light (with buzzer)
○
○
○
○
Mini signal light
●*1 ●*1 ●*1 ●*1
Super foot
●
*1
●
*1
●
*1
●
*1
Caster
●
*1 *3
●
*1 *3
●
*1 *3
●
*1 *3
Pneumatic device piping system
○ ○ ○ ○
Air regulator
○
○
○
○
Vacuum pump
○
○
○
○
Main line filter
- - - -
PWB transport unit
○
○
○
○
Placement station
○ ○ ○ ○
External shape reference
○
○
○
○
Pin reference
●
*1 *4
●
*1 *4
●
*1 *4
●
*1 *4
Auto PWB width adjustment unit
●*1 ●*1 ●*1 ●*1
L-Wide PWB
●
*1 *5
●
*1 *5
●
*1 *5
●
*1 *5
Longer sized PWB in X axis
●
*1
●
*1
●
*1
●
*1
Solder recognition lighting
●*1 ●*1 ●*1 ●*1
Component quantity control
●
*1
●
*1
●
*1
●
*1
Operation system
○
○
○
○
Liquid crystal display
○ ○ ○ ○
Keyboard with Trackball
○
○
○
○
SSD
○
○
○
○
Communication port Ethernet
○ ○ ○ ○
USB port
○
○
○
○
Rear-side operation unit
●
*1
-
●
*1
●
*1
HOD
●
*1
●
*1
●
*1
●
*1
- 7 -
KE-3010A
KE-3010AC
KE-3020VA
KE-3020VRA
DVD/CD-ROM drive (USB)
● ● ● ●
FD drive (USB)
●
●
●
●
Equipment device
Feeder float sensor
○ ○*16 ○ ○
Automatic tool change unit (ATC)
○
○
○
○
Large-shape component scrap box
-
-
○
○
Flexible calibration system（FCS）
○ ○ ○ ○
FCS adjusting jig
●
●
●
●
Feeder position indicator (FPI)
●*1 ●*1 *16 ●*1 ●*1
SOT direction inspection table
●
*1
●
*1
●
*1
●
*1
Component verification (CVS)
●
*1
●
*1
●
*1
●
*1
Coplanarity
●*1 *6 - ●*1 ●*1
Ionizer
●
*1
●
*1
●
*1
●
*1
Fluxer: Type 2 (To be attached on the main unit)
●*1 *13 *14
-
●*1 *13 *14 ●*1 *13 *14
Simplified load control
●
*1
●
*1
●
*1
●
*1
Solder print recognition placement position correction
●
*1
●
*1
●
*1
●
*1
Bottom View type multi-code reader
●
*1
●
*1
●
*1
●
*1
Production support system
Component database
○
*7
○
*7
○
*7
○
*7
External programing unit (EPU)
● ● ● ●
Floor productivity operating system
Production support system
・
IS
●
●
*17
●
●
・
IS Lite
●
●
*17
●
●
・
JaNets
●
●
*17
●
●
Production management system
・
IFS-NX
●
●
*17
●
●
White list type anti-virus software
○
○
○
○
Feeder bank (Mechanical type)
Mechanical feeder bank (fixed type)
○
○
*16
○
○
Mechanical overall change table system
●
*1
●
*1 *16
●
*1
●
*1
Overall change table for mechanical feeder
●*1 ●*1 *16 ●*1 ●*1
Intelli trolley for mechanical feeder
●
*8
●
*8 *16
●
*8
●
*8
Connector bracket
●
*1
●
*1
●
*1
●
*1
IC collection belt
● ● ● ●
Component supply unit
Tape feeder/bulk feeder
●
*8
●
*8
●
*8
●
*8
Stick feeder / Stacked stick
●*8 ●*8 ●*8 ●*8
Tray supply unit
MTC *14
●
*8 *9
-
●
*8 *9
●
*8 *9
MTS
●*8 *9 - ●*8 *9 ●*8 *9
DTS
●
*8 *9
-
●
*8 *9
●
*8 *9
Tray holder
●
*8 *9
-
●
*8 *9
●
*8 *9
Fluxer: Type 3 (To be attached on a bank/rear side only)
●*1 *13 - ●*1 *13 ●*1 *13
Rotary-type solder transfer device
(To be attached on a bank/front side only)
●*1 *13
-
●*1 *13 ●*1 *13
Feeder setup stand for E-feeder
● ● ● ●
Tape cutter
●
●
●
●
Trash box
●
●
●
●
Wafer supply unit
T Multi-die server (DF01)
●
*15
-
●
*15
●
*15
- 8 -
KE-3010A
KE-3010AC
KE-3020VA
KE-3020VRA
Feeder bank (Electric type and both mechanical type and electric type)
Electric feeder bank (fixed type)
●
*1
●
*1 *16
●
*1
●
*1
Electric overall change table system
●
*1
●
*1 *16
●
*1
●
*1
Overall change table for electric feeder (EF)
●*1 ●*1 *16 ●*1 ●*1
Overall change table for electric feeder (RF)
●
*1
-
●
*1
●
*1
Intelli trolley for electric feeder
●
*8
●
*8 *16
●
*8
●
*8
Tape cutter unit
●*1 ●*1 ●*1 ●*1
IC collection belt
● ● ● ●
Component supply unit
EF series electric feeder
●
*8 *19
●
*8 *19
●
*8 *19
●
*8 *19
RF series electric feeder
● - ● ●
Stick feeder
●
*8 *19
●
*8 *19
●
*8 *19
●
*8 *19
Tray supply unit
MTC *14
●
*8 *9
-
●
*8 *9
●
*8 *9
MTS
●
*8 *9
-
●
*8 *9
●
*8 *9
DTS
●*8*9*20
-
●*8*9*20 ●*8*9*20
Tray holder
●*8*9
-
●*8*9 ●*8*9
Wafer supply unit
T Multi-die server (DF01)
●
*15
-
●
*15
●
*15
Fluxer: Type 3 (To be attached on a bank/rear side only)
●
*1*13*20
- ●
*1*13*20
●
*1*13*20
Rotary-type solder transfer device
(To be attached on a bank/front side only)
●*1*13*20 - ●*1*13*20 ●*1*13*20
Feeder setup stand for E-feeder (EF)
● ● ● ●
Feeder setup stand for E-feeder (RF)
● - ● ●
RF_ETF_Attachment
●*19 - ●*19 ●*19
Offline power supply for an electric bank
● ● ● ●
Feeder bank for both mechanical type and electric type ●*1*10*18 - ●*1*10*18 ●*1*10*18
*1 This option is a factory-set option.
*2 Both MNVC and component recognition camera are provided as a set.
*3 This is applicable to the M PWB machine and L PWB machine.
*4 When the L-wide PWB specification is adopted, pin reference cannot be selected.
*5 Applicable only to the L PWB machine.
*6 The MNVC function is required.
*7 To use the component database, PC is separately required.
*8 To use the production management system, Applicable to FRID is required.
(For mountable models and models for which a countermeasure can be taken later, refer to the
PRODUCT SPECIFICATIONS of production management system.)
*9 For installing MTS, it is necessary to change the rear side of the main unit into an overall change tabl
e
t
ype.
*10 For the options of both mechanical and electric feeder banks, refer to the description of each feeder
bank.
*11 This is not mounted on the machine when a placement monitor is selected.
*12 An LNC 61 and an LNC62 are heads exclusively designed for a placement monitor into which
an
u
ltra-miniature camera is incorporated.
The specifications of recognition with laser are equivalent with those of an LNC60.
*13 Select either of a fluxer and a rotary-type solder transfer device.
*14 You cannot select both a fluxer (Type 2: to be attached on the main unit) and an MTC at the same
time.
*15 This unit can be attached on the rear bank of the main unit designed for a feeder exchange trolley.
*16 This unit can be attached on the front side of the main unit only.
*17 This is handled as a KE-3010A.
*18 Only an EN specification machine for a large-sized board is supported.
*19 Attach the RF_ETF_Attachment when electric feeders are used by a feeder trolley (RF). (If you use t
he
R
F_ETF_Attachment, non-teaching and synchronous adsorption guarantee are excluded.)
*20 It does not correspond to the Feeder exchange trolley RF.
