- 45 -
(5) IS Lite : Production management system
Juki software, the IS, has been simplified to develop the IS Lite. This software
consolidates and optimizes information on JUKI mounters allocated on the whole a
line (production site) to improve productivity and to reduce production cost of each
line.
Applicable models : RX-6 series, RX-7, KE-3000
series, FX-3 series,
KE-2070/80 series, KE-2050/60 series
(6) JaNets : Production support system
As with our software IS and IS Lite, This software consolidates and optimizes
information on JUKI mounters allocated on the several lines (production site) to
improve productivity and production quality and to reduce production cost of each line.
Applicable models : RS-1, RX-7, RX-6 series, KE-3000
series, FX-3 series,
KE-2070/80 series, KE-2050/60 series, KD-2077
* For
line configuration that the RS-1 is located, JaNets is required.
- 46 -
6.
Component supply unit
6.1. List of Feeder Bank Specifications
A bank is selected from four types shown below, which supplies components.
It is possible to combine with a front bank and/or a rear bank according to your usage.
Bank type Attachable feeder type
Attachable feeder change
trolley
①
Mechanical feeder bank (fixed
type)
Mechanical feeder
-
②
Electric feeder bank (fixed type) Electric feeder
-
③
Mechanical feeder bank feeder
change trolley type
Mechanical feeder
Mechanical feeder change
trolley only
④
Electric feeder bank feeder
change trolley type
Electric feeder
Electric feeder change trolley
only
⑤
Mechanical/electric combined
feeder bank
(EN machine for a large-sized
board: supported only if it is
designed to use a feeder
exchange trolley.)
Mechanical feeder
Electric feeder
Mechanical feeder change
trolley
Electric feeder change trolley
* C
ompatibility of the electric feeder bank of our mounter KE-3020/3020R
For setting the electric trolley for this model in KE-3020/20R, a modification kit is required
depending on conditions.
- When there is a cutter unit in KE-3020/3020R
→ A modification kit is required.
- When there is no cutter unit in KE-3020/3020R
→ A modification kit is not required.
For
setting the change trolley of KE-3020/20R in this model, no modification kit is
required.
- 47 -
6.2. Maximum Number of Feeders Available on a Mounter
(1) Mechanical feeders
Name
The number of
feeders available
on the front side
The number
of feeders
available on
the rear side
Total number
of feeders
available
The number
of slots
occupied
Mounting
pitch
8 mm tape feeder 40 40 80 (80 types) 2 17.0 mm
12 mm tape feeder
26 26 52 3 25.5 mm
16 mm tape feeder
26 26 52 3 25.5 mm
24 mm tape feeder
20 20 40 4 34.0 mm
32 mm tape feeder
16 16 32 5 42.5 mm
32 mm paper adhesive
tape feeder
16 16 32 5 42.5 mm
44 mm tape feeder 10 10 20 8 68.0 mm
56 mm tape feeder 10 10 20 8 68.0 mm
72 mm tape feeder 8 8 16 10 85.0 mm
Stick feeder type N 26 26 52 3 25.5 mm
Stick feeder type W 13 13 26 6 51.0 mm
Stack stick feeder
(Note 1)
5 ― 5 8 68.0 mm
Bulk feeder 40 ― 40 2 17.0 mm
Note 1: The number of feeders that can be installed on the front side is up to five.
(2) Electric feeders
Name
The number of
feeders
available on the
front side
The number
of feeders
available on
the rear side
Total number
of feeders
available
The number
of lanes
occupied
(*1)
Mounting
pitch
4 mm tape feeder
40
40
80 (80 types)
1
17.0 mm
8 mm tape feeder
40
40
80 (80 types)
1
17.0 mm
8 mm double lane tape
feeder
(
*
2)
40 40 80 (160 types) 1 17.0 mm
12 mm tape feeder
40 40 80 1 17.0 mm
16 mm tape feeder
20 20 40 2 34.0 mm
24 mm tape feeder
20 20 40 2 34.0 mm
32 mm tape feeder
13 13 26 3 51.0 mm
44 mm tape feeder
13 13 26 3 51.0 mm
56 mm tape feeder
10 10 20 4 68.0 mm
72 mm tape feeder (*3)
6 6 12 5 85.0 mm
88 mm tape feeder (*3)
5 5 10 6 102.0 mm
Stick feeder type N (*4)
20 20 40 2 34.0 mm
Stick feeder type W (*4)
13 13 26 3 51.0 mm
*1: One lane occupied by electric feeders is mostly equivalent to two slots occupied by mechanical
feeders.
*2: To use an 8 mm double lane tape feeder, be sure to use a tape reel attaching platform for electric
feeder.
*3: Since five lanes on each side of the bank, left and right are not to be used, the number of lanes show
n
i
n the table above can be used.
*4: Attach the RF_ETF_ATTACHMENT when Stick feeders are used by a feeder trolley (RF)
