(Cause 1) Check whether or not solenoid valves (YSV01A) and (YSV01B) for YA-axis stationary
position stopper forward and backward movement are working normally.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Check whether or not YA-axis stationary position stopper forward sensor (BPH029) is
functioning correctly.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
0005-002 2-89 Tg0248-PM-ER
3. Trouble Shooting after Error Display
Error Code Display A Display B
60 04 0C INTERLOCK YA AXIS POSITIONING BACKWARD WAS NOT
DETECTED.;BPH029
60 04 0B INTERLOCK YA AXIS POSITIONING FORWARD WAS NOT
DETECTED.;BPH028
(Cause 1) Check whether or not solenoid valves (YSV01A) and (YSV01B) for YA-axis stationary
position stopper forward and backward movement are working normally.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Check whether or not YA-axis stationary position stopper forward sensor (BPH028) is
functioning correctly.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
60 04 0A INTERLOCK P.C.B. POSITIONING ERROR WAS DETECTED.
;BPH150 E / NR
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
60 04 09 INTERLOCK BEAM-A UNIT CAME VERY CLOSE TO BEAM-B
UNIT.;BPH027 E / NR
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
60 05 02 SAFETY CIRCUIT AREA SENSORS FOR BEAM-B SIDE WERE
ACTIVATED.;BPH083,BPH084 E / NR
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
Error Code Display A Display B
0005-002 2-90 Tg0248-PM-ER
3. Trouble Shooting after Error Display
60 05 01 SAFETY CIRCUIT AREA SENSORS FOR BEAM-A SIDE WERE
ACTIVATED.;BPH081,BPH082 E / NR
(Cause 1) This is the device's self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
60 04 0E INTERLOCK YB AXIS POSITIONING BACKWARD WAS NOT
DETECTED.;BPH031
(Cause 1) Check whether or not solenoid valves (YSV02A) and (YSV02B) for YB-axis stationary
position stopper forward and backward movement are working normally.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Check whether or not YB-axis stationary position stopper forward sensor (BPH031) is
functioning correctly.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
60 04 0D INTERLOCK YB AXIS POSITIONING FORWARD WAS NOT
DETECTED.;BPH030
(Cause 1) Check whether or not solenoid valves (YSV02A) and (YSV02B) for YB-axis stationary
position stopper forward and backward movement are working normally.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Check whether or not YB-axis stationary position stopper forward sensor (BPH030) is
functioning correctly.
(3) Press the [ZERO] button to return all the axes to their original positions.
(4) Re-start.
(5) If the device can’t be re-started, contact our service personnel.
0005-002 2-91 Tg0248-PM-ER
Error Code Display A Display B
3. Trouble Shooting after Error Display
60 05 05 SAFETY CIRCUIT
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
60 05 04 SAFETY CIRCUIT
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
60 05 03 SAFETY CIRCUIT
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [CLEAR ALARM] key and the buzzer stops sounding.
(2) Press the [ZERO] button to return all the axes to their original positions.
(3) Re-start.
(4) If the device can’t be re-started, contact our service personnel.
