2. Error Messages 0005-002 2-4 Tg0248-PM-ER 2. Error Messages Ma i n S e ctio n Err or M e ssa ge s A 01H XA AXIS 01H XA-AXIS O R IG I N 02H XA-AXIS T IMI N G 03H XA-AXIS D AT A 04H XA-AXIS L IM I T 05H XA-AXIS SER VOMOT…
A : Shows an ERROR message.
B : Shows the ERROR description.
C : Indicates the Cause and Remedy of Error
(There are some errors for which the indication may not be displayed).
D : Shows an error code consisting of 6 digits
E : Press the [NEXT PAGE] key to open the next page. Pressing the [PREV.
PAGE] key opens the previous page.
F : When several errors are displayed, the displayed page No. and the number
of errors appear at the upper right corner of the display.
G : This key is used to stop buzzer sound.
Ref.: When the [RESET] button on the operation panel is pressed, buzzer
sound stops and the display before an error has occurred resumes.
H : The displayed 4 digits represents a code which clarifies the error spot in
the software and is used only by a service personnel. Or, 8 digits will
appear, representing a recognition error code.
Refer to “3. Trouble Shooting after Error Display of Section 2” for details.
Remedial Procedure after Error Display
(1) Press the [CLEAR ALARM] key. (Fig. 2.2)
The buzzer stops sounding.
(2) Check the contents of the error message and the remedial procedure dis-
played on the operation monitor.
(3) Remove the cause of error.
(4) Press the [RESET] key to resume the original display.
0005-002 2-3 Tg0248-PM-ER
1. “ERROR” Display
2. Error Messages
0005-002 2-4 Tg0248-PM-ER
2. Error Messages
Main Section Error Messages A
01H XA AXIS 01H XA-AXIS ORIGIN
02H XA-AXIS TIMING
03H XA-AXIS DATA
04H XA-AXIS LIMIT
05H
XA-AXIS SERVOMOTOR DRIVER
06H XA-AXIS INTERLOCK
02H YA AXIS 01H YA-AXIS ORIGIN
02H YA-AXIS TIMING
03H YA-AXIS DATA
04H YA-AXIS LIMIT
05H
YA-AXIS SERVOMOTOR DRIVER
06H YA-AXIS INTERLOCK
03H XB AXIS 01H XB-AXIS ORIGIN
02H XB-AXIS TIMING
03H XB-AXIS DATA
04H XB-AXIS LIMIT
05H
XB-AXIS SERVOMOTOR DRIVER
06H XB-AXIS INTERLOCK
04H YB AXIS 01H YB-AXIS ORIGIN
02H YB-AXIS TIMING
03H YB-AXIS DATA
04H YB-AXIS LIMIT
05H
YB-AXIS SERVOMOTOR DRIVER
06H YB-AXIS INTERLOCK
05H 01H LA1-AXIS ORIGIN
02H LA1-AXIS TIMING
03H LA1-AXIS DATA
04H LA1-AXIS LIMIT
05H
LA1-AXIS SERVOMOTOR DRIVER
LA1 AXIS
06H LA1-AXIS INTERLOCK
06H 01H LA2-AXIS ORIGIN
03H LA2-AXIS DATA
04H LA2-AXIS LIMIT
05H
LA2-AXIS SERVOMOTOR DRIVER
LA2 AXIS
06H LA2-AXIS INTERLOCK
01H LB1-AXIS ORIGIN07H
03H
LB1-AXIS DATA
04H LB1-AXIS LIMIT
05H
LB1-AXIS SERVOMOTOR DRIVER
LB1 AXIS
06H LB1-AXIS INTERLOCK
08H LB2 AXIS 01H LB2-AXIS ORIGIN
03H LB2-AXIS DATA
04H LB2-AXIS LIMIT
05H
LB2-AXIS SERVOMOTOR DRIVER
06H LB2-AXIS INTERLOCK
09H ZA1 AXIS 01H ZA1-AXIS ORIGIN
03H ZA1-AXIS DATA
04H
ZA1-AXIS COMMUNICATION
01H ZA2-AXIS ORIGIN0AH ZA2 AXIS
03H ZA2-AXIS DATA
04H
ZA2-AXIS COMMUNICATION
0BH ZB1 AXIS 01H ZB1-AXIS ORIGIN
03H ZB1-AXIS DATA
04H
ZB1-AXIS COMMUNICATION
0CH ZB2 AXIS 01H ZB2-AXIS ORIGIN
03H ZB2-AXIS DATA
04H
ZB2-AXIS COMMUNICATION
0DH BPC AXIS 01H BPC-AXIS ORIGIN
03H
BPC-AXIS DATA
04H
BPC-AXIS LIMIT
05H
BPC-AXIS SERVOMOTOR DRIVER
06H
BPC-AXIS INTERLOCK
Main Section Error Messages A
0EH PWC AXIS 01H PWC-AXIS ORIGIN
03H PWC-AXIS DATA
04H PWC-AXIS LIMIT
06H PWC-AXIS INTERLOCK
20H 01H TFA1-AXIS ORIGIN
02H TFA1-AXIS TIMING
FEEDER BASE1
03H SEND CYLINDER
01H TFA2-AXIS ORIGIN21H
02H
TFA2-AXIS TIMING
FEEDER BASE2
03H SEND CYLINDER
01H TFB1-AXIS ORIGIN
02H TFB1-AXIS TIMING
22H
FEEDER BASE3
03H SEND CYLINDER
0005-002 2-5 Tg0248-PM-ER
2. Error Messages
Main Section Error Messages A
01H TFB2-AXIS ORIGIN
02H TFB2-AXIS TIMING
23H
FEEDER BASE4
03H SEND CYLINDER
01H LOAD POWER SHUT-OFF
02H BEAM-A POWER SHUT-OFF
03H BEAM-B POWER SHUT-OFF
04H INTERLOCK
60H
SAFETY DEVICE
05H SAFETY CIRCUIT
01H PLACEMENT NOZZLE
02H
INSIDE RECOGNITION XXXXXXXX
61H DATA
03H
COMPONENT RECOGNITION DATA
02H L-CONVEYOR OVERTIME
03H P-CONVEYOR OVERTIME
04H R-CONVEYOR OVERTIME
05H ER-CONVEYOR OVER TIME
07H
L-CONVEYOR P.C.B. DETECTION
08H
P-CONVEYOR P.C.B. DETECTION
62H CONVEYOR
09H
R-CONVEYOR P.C.B. DETECTION
63H
SELF DIAGNOSTICS
01H CONTROL BOARD
65H
RECOG
COMMUNICATION
01H
RECOG. COMMUNICATION
XXXXXXXX
02H
LIGHTING CONTROL BOARD
COMMUNICATION XXXXXXXX
66H
P.E.C.
RECOGNITION
01H
P.E.C. MARK #1 (GLOBAL)
XXXXXXXX
02H
P.E.C. MARK #2 (GLOBAL)
XXXXXXXX
03H
P.E.C. MARK #3 (GLOBAL)
XXXXXXXX
04H
P.E.C. MARK #1 (IMAGE)
XXXXXXXX
05H
P.E.C. MARK #2 (IMAGE)
XXXXXXXX
06H
P.E.C. MARK #1 (LOCAL)
XXXXXXXX
07H
P.E.C. MARK #2 (LOCAL)
XXXXXXXX
08H
P.E.C. MARK #3 (LOCAL)
XXXXXXXX
09H
P.E.C. MARK #4 (LOCAL)
XXXXXXXX
67H COMPONENT
RECOGNITION
01H
COMPONENT RECOGNITION
XXXXXXXX
68H 01H CMPNT MISSING(SENSOR)
02H VACUUM SENSOR ERROR
03H CMPNT MISSING(RECOG)
04H CMPNT RECOG ERROR
05H SHORTAGE OF CMPNT
PICK-UP ERROR
07H
SHORTAGE OF COMP.
㧔
ALTN FDR
㧕
01H NOZZLE ATTACH69H
NOZZLE
CHANGE
02H NOZZLE STORE
Main Section Error Messages A
01H ILLEAGAL OPERATION
02H FEEDER NOT READY
03H NO CONTINUOUS STARTING
6CH OTHERES
04H INTERNAL DATA ERROR
01H JIG COMPONENT
02H TEACH P.E.C. CAMERA
OFFSET XXXXXXXX
03H TEACH BEAM
OFFSET XXXXXXXX
04H TEACH COMP. CAMR. MAG.
XXXXXXXX
05H TEACH COMP. CAMR.
OFFSET XXXXXXXX
06H TEACH HEAD ROTATION
CTR XXXXXXXX
07H TEACH HEAD OFFSET
XXXXXXXX
08H HEAD ROTATION OFFSET
XXXXXXXX
09H TEACH CAMERA
REFERENCE GAIN/LEVEL
0AH
TEACH CAMERA SHUTTER
SPEED
0BH
TEACH COMP.RECOG.
BRIGHTNESS
0CH
OFFSET TEACHING
BRIGHTNESS
6DH TEACHING
0DH
TEACH HD. OFS.
(GET BOTH IMAGE)
XXXXXXXX
01H COMPONENT REJECT CUP [A]6EH COMPONENT
REJECT
02H COMPONENT REJECT CUP [B]
