0103-001 4-55-5 Tg0248-PM-ER
5. Component Recognition Error Code and List of Error Messages
Error Code Display A Display B
20672154 COMPONENT DETECTION
ERROR
THE LEADS CANNOT BE DETECTED ADEQUATELY.
20672171 COMPONENT DETECTION
ERROR
SOME BALLS CANNOT BE DETECTED.
20672163 COMPONENT DETECTION
ERROR
LEAD POSITION (LEAD LENGTH DIRECTION) WAS
OUT OF TOLERANCE.
(Cause 1) Any part (mold, etc.) other than the leads is as bright as the leads or brighter than the
leads.
(Cause 2) When much part other than the leads is as bright as the leads, the component may not
be recognized. In this case, set "CONNECTOR" in the "PACKAGE TYPE" data box
and perform the recognition.
(Cause 3) No component is picked up.
(Cause 4) The lighting is not ON.
(Reset Procedure in the case of Causes 1, 2, 3 and 4)
Reset Procedure
(1) Press the [ZERO] button to return all the axes to their original positions.
(2) Re-start.
(3) If the device can’t be re-started, contact our service personnel.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [ZERO] button to return all the axes to their original positions.
(2) Re-start.
(3) If the device can’t be re-started, contact our service personnel.
0103-001 4-55-6 Tg0248-PM-ER
5. Component Recognition Error Code and List of Error Messages
Error Code Display A Display B
20672182 COMPONENT DETECTION
ERROR
BALL NOT FOUND.
20672183 COMPONENT DETECTION
ERROR
THE BALLS CANNOT BE DETECTED ADEQUATELY.
20672184 COMPONENT DETECTION
ERROR
THE DETECTED BALL POSITION DOES NOT MATCH
THE POSITION DATA.
20672172 COMPONENT DETECTION
ERROR
CONTRAST BETWEEN BALL AND BACKGROUND IS
TOO LOW.
20672186 COMPONENT DETECTION
ERROR
THE DETECTED GRID SIZE DOES NOT MATCH THE
SIZE DATA.
20672185 COMPONENT DETECTION
ERROR
THE COMPONENT DIRECTION DOES NOT MATCH
THE CORRESPONDING DATA.
(Cause 1) The lighting is not ON.
(Cause 2) The camera shutter speed is not suitable.
(In normal cases, the speed should be "5.0 to 11.0 ms".)
(Cause 3) The gain and level of the camera are not suitable.
(In normal cases, the gain should be "160 to 190" and the level "0 to 10".)
(Reset Procedure in the case of Causes 1, 2 and 3)
Reset Procedure
(1) Press the [ZERO] button to return all the axes to their original positions.
(2) Re-start.
(3) If the device can’t be re-started, contact our service personnel.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [ZERO] button to return all the axes to their original positions.
(2) Re-start.
(3) If the device can’t be re-started, contact our service personnel.
0103-001 4-55-7 Tg0248-PM-ER
5. Component Recognition Error Code and List of Error Messages
Error Code Display A Display B
20672196 COMPONENT DETECTION
ERROR
CONTRAST BETWEEN BALL AND BACKGROUND IS
TOO LOW.
20672197 COMPONENT DETECTION
ERROR
THE BALLS CANNOT BE DETECTED ADEQUATELY.
20672223 COMPONENT DETECTION
ERROR
CONTRAST BETWEEN BALL AND BACKGROUND IS
TOO LOW.
20672198 COMPONENT DETECTION
ERROR
THE BALLS CANNOT BE DETECTED ADEQUATELY.
(Cause 1) The lighting is not ON.
(Cause 2) The camera shutter speed is not suitable.
(In normal cases, the speed should be "5.0 to 11.0 ms".)
(Cause 3) The gain and level of the camera are not suitable.
(In normal cases, the gain should be "160 to 190" and the level "0 to 10".)
(Reset Procedure in the case of Causes 1, 2 and 3)
Reset Procedure
(1) Press the [ZERO] button to return all the axes to their original positions.
(2) Re-start.
(3) If the device can’t be re-started, contact our service personnel.
(Cause 1) This is the device’s self-diagnostic message.
(Reset Procedure in the case of Cause 1)
Reset Procedure
(1) Press the [ZERO] button to return all the axes to their original positions.
(2) Re-start.
(3) If the device can’t be re-started, contact our service personnel.
(Cause 1) The lighting is not ON.
(Cause 2) The camera shutter speed is not suitable.
(In normal cases, the speed should be "5.0 to .0 ms".)
(Cause 3) The gain and level of the camera are not suitable.
(In normal cases, the gain should be "160 to 190" and the level "0 to 10".)
(Reset Procedure in the case of Causes 1, 2 and 3)
Reset Procedure
(1) Press the [ZERO] button to return all the axes to their original positions.
(2) Re-start.
(3) If the device can’t be re-started, contact our service personnel.
