2-4 2 Ｙ軸ユニット Y-AXIS UNIT ｲﾗｽﾄ番号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl.

100%1 / 240
2-3
2
Ｙ軸ユニット
Y-AXIS UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
26 2-693-623-01
ｳﾚﾀﾝ
ｽﾄﾂﾊﾟ
- (C)
STOPPER (C), URETHANE
1
27 2-697-045-01
ﾎﾞ
-
ﾙ
ﾈｼﾞ
(SBK2020YS-5.6RRGT+9*
SCREW (SBK2020YS-5.6RRGT+9*)
2
SBK2020YS-5.6RRGT+9*
28 2-698-404-01
ｽﾁ
-
ﾙ
ｽﾍﾟ
-
ｻ
(BSF-408E)
SPACER (BSF-408E), STEEL
4
BSF-408E, HIROSUGI
29 3-095-923-01
ﾀｶｻ
ﾁﾖｳｾｲ
ｼﾑ
(
ﾌﾚ
-
ﾑ
ﾖｳ
) A
SHIM (FRAME),HEIGHT ADJUSTMENT
8
30 3-095-923-11
ﾀｶｻ
ﾁﾖｳｾｲ
ｼﾑ
(
ﾌﾚ
-
ﾑ
ﾖｳ
) B
SHIM (FRAME),HEIGHT ADJUSTMENT
4
31 4-703-128-01
ﾌｱｲﾝ
U
ﾅﾂﾄ
(FU02SS)
NUT (FU02SS), FINE (U)
2
FU02SS, FUJI SEIMITSU
32 4-703-129-01
ﾌｶﾐｿﾞ
ﾀﾏ
ｼﾞｸｳｹ
(6002ZZ)
BEARING (6002ZZ), BALL
2
6002ZZ, NTN
33 4-706-724-21
ﾛﾂｶﾅ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X8)
BOLT (M3X8), HEXAGON SOCKET
16
M3X8
34 4-706-725-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
20
M4X8
35 4-706-725-06
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X25SUS)
BOLT (M4X25SUS),HEXAGON SOCKET
16
M4X25SUS
36 4-706-725-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X10)
BOLT (M4X10), HEXAGON SOCKET
12
M4X10
37 4-706-725-61
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
8
M4X15
38 4-706-726-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X20)
BOLT (M5X20), HEXAGON SOCKET
40
M5X20
39 4-706-740-07
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X20SUS)
BOLT (M6X20SUS),HEXAGON SOCKET
8
M6X20SUS
40 4-716-148-06
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M8X25 SUS)
BOLT (M8X25 SUS), SOCKET
4
M8X25 SUS
41 4-716-148-08
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M8X35 SUS)
BOLT (M8X35 SUS), SOCKET
4
M8X35 SUS
42 4-716-148-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M8X50 SUS)
BOLT (M8X50 SUS), SOCKET
8
M8X50 SUS
43 4-716-151-07
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M16X50 SUS)
BOLT (M16X50 SUS), SOCKET
20
M16X50 SUS
44 4-719-803-04
X
ﾎﾞ
-
ﾙﾈｼﾞ
ｼｼﾞ
ﾌﾞﾗｹﾂﾄ
BRACKET, X BALL SCREW SUPPORT
2
45 4-721-723-01
X
ﾍﾞｱﾘﾝｸﾞ
ｺﾃｲ
ﾌﾗﾝｼﾞ
FLANGE, X BEARING FIXED
2
46 4-721-724-01
X
ﾍﾞｱﾘﾝｸﾞ
ｺﾃｲ
ｶﾗ
-
COLLAR, X BEARING FIXED
2
47 4-721-725-03
X
ﾓ
-
ﾀ
-
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
BRACKET, X MOTOR FITTING
2
48 4-721-726-01
ｱﾝｷﾞﾕﾗ
ﾀﾏｼﾞｸｳｹ
(7302BTDFC8P5)
BALL BEARING, ANGULAR
2
7302BTDFC8P5
49 7-624-197-21
C
ｶﾞﾀ
ﾄﾒﾜ
15 (
ｼﾞｸﾖｳ
)
STOP RING 15, TYPE-C
2
50 7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
10
W 4, MIDDLE
51 2-689-953-01
ｼﾂﾋﾟﾝｸﾞｸﾗﾝﾌﾟ
SHIPPING CLAMP
2
2-4
2
Ｙ軸ユニット
Y-AXIS UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
3-1-1
3-1
Ｘ軸（Ｂ）ユニット
X-AXIS (B) UNIT
21
6
15
13
13
14
23
24
24
3
4
19
16
22
22
22
17
20
26
18
25
25
