3-6-1 3-6 Ｂヘッドユニット（４ ／４） HEAD UNIT, B (4/4) 2 3 5 7 10 11 13 14 15 16 17 18 19 20 21 22 23 54 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 43 44 49 50 51 52 27 28 31 38 49 44 2 35 8 9 12 53
3-5-4
3-5
Ｂヘッドユニット（３／４）
HEAD UNIT, B (3/4)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
3-6-1
3-6
Ｂヘッドユニット（４／４）
HEAD UNIT, B (4/4)
2
3
5
7
10
11
13
14
15
16
17
18
19
20
21
22
23
54
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
43
44
49
50
51
52
27
28
31
38
49
44
2
35
8
9
12
53
3-6-2
3-6
Ｂヘッドユニット（４／４）
HEAD UNIT, B (4/4)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
2 1-417-872-11
ﾀﾁ
ｹﾝｼﾕﾂ
ｶﾒﾗ
(B) (QQJ-2172)
CAMERA, DETECTION (B)(QQJ-2172
1
3 X-2187-323-1
ﾒｲﾝ
ﾌﾞﾗｹﾂﾄ
ASSY
BRACKET ASSY, MAIN
1
5 X-2187-324-1
ﾀﾁ
ｶﾒﾗ
ﾎﾙﾀﾞ
ASSY
HOLDER ASSY, CAMERA
1
7 1-809-416-11
ﾌｵﾄ
ﾏｲｸﾛ
ｾﾝｻ
(EE-SY672)
SENSOR, PHOTO MICRO (EE-SY672)
1
EE-SY672,OMRON
8 2-915-874-01
ｽﾋﾟ
-
ﾄﾞ
ｺﾝﾄﾛ
-
ﾗ
(AS1001F-04)
CONTROLLER (AS1001F-04), SPEED
4
AS1001F-04,SMC
9 2-918-867-01
ﾕﾆｵﾝ
ﾜｲ
(KJ04-00)
UNION Y (KJ04-00)
2
KJ04-00
10 3-278-105-01
ｽﾄﾂﾊﾟ
-
ﾌﾞﾛﾂｸ
BLOCK, STOPPER
1
11 3-278-106-01
ｱﾌﾞｿ
-
ﾊﾞ
-
ﾌﾞﾛﾂｸ
BLOCK, ABSORBER
1
12 3-278-107-01
ｼﾘﾝﾀﾞ
ｶﾊﾞ
-
COVER, CYLINDER
1
13 3-278-111-01
RN
ｾﾝｻ
-
ﾄﾞｸﾞ
DOG, RN SENSOR
1
14 3-278-154-01
ｼﾘﾝﾀﾞ
-
ｼﾞﾖｲﾝﾄ
JOINT, CYLINDER
1
15 3-278-155-01
ｼﾞﾖｲﾝﾄ
ｶﾗ
-
COLLAR, JOINT
1
16 3-278-156-01
ｼﾘﾝﾀﾞ
ｾﾝｻ
ﾎﾙﾀﾞ
HOLDER, CYLINDER SENSOR
1
17 3-278-157-01
ｷﾊﾞﾝ
ﾌﾞﾗｹﾂﾄ
BRACKET, PC BOARD
1
18 3-278-160-01
ｼﾖｳﾒｲ
ﾖｳ
ﾛﾂｶｸ
ﾎﾞﾙﾄ
BOLT, ILLUMINATION HEXAGON
3
19 3-278-181-01
ｶﾞｲﾄﾞ
ﾎﾙﾀﾞ
-
HOLDER, GUIDE
1
20 3-278-182-01
ｽﾗｲﾄﾞ
ﾌﾞﾛﾂｸ
BLOCK, SLIDE
1
21 3-278-947-01
ｼﾖﾂｸ
ｱﾌﾞｿ
-
ﾊﾞ
(RB0604)
ABSORBER (RB0604), SHOCK
1
RB0604,SMC
22 3-278-948-01
ｴﾝﾁﾖｳ
ﾂｷﾞﾃ
(M-5J)
JOINT (M-5J), EXTENSION
1
M-5J
23 3-279-051-01
ｴｱ
-
ｽﾗｲﾄﾞ
ﾃ
-
ﾌﾞﾙ
(MXQ6L-20AT-M*
TABLE (MXQ6L-20AT-M9NV), SLIDE
1
MXQ6L-20AT-M9NV
24 1-480-825-11
(S)
ｿﾚﾉｲﾄﾞ
ﾊﾞﾙﾌﾞ
ASSY (SY3120)
VALVE ASSY, (S) SOLENOID (SY3*
1
SY3120
25 3-279-053-01
ﾐﾆ
ﾌﾘ
-
ﾏｳﾝﾄ
ｼﾘﾝﾀﾞ
(CDUJB6-15D*
CYLINDER (CDUJB6-15D-F8N)
1
CDUJB6-15D-F8N
26 3-279-322-01
ﾘﾆｱ
ｳｴｲ
(MLC9C1R37S1E080)
RAIL (MLC9C1R37S1E080), LINEAR
1
MLC9C1R37S1E080
27 3-661-588-02
ｽﾍﾟ
-
ｻ
- 3X5
SPACER (3X5)
4
3X5
28 4-701-306-01
ｻｲﾚﾝｻ
- (AN120-M5)
SILENCER (AN120-M5)
2
AN120-M5,SMC
29 4-702-269-01
ﾎ
-
ｽ
ﾆﾂﾌﾟﾙ
(M-5H-4)
NIPPLE (M-5H-4), HOSE
1
M-5H-4,SMC
