4-4 4 中継ユニット REL AY UNIT ｲﾗｽ ﾄ番号 Re f.No. 部品コ ード Parts Code 部品名 Part s Name Serial No. 個数 Q't y 備考 Rem arks 同期 Repl. 54 2-698-399-02 ｺﾞｸ ﾃｲﾄｳ ﾛﾂ ｶ ｸ ｱﾅﾂｷ ﾎﾞ ﾙﾄ (CBS T* CAP S CREW, EX TRA LOW HEAD 4 55 3-197-060-01 ﾃ…
4-3
4
中継ユニット
RELAY UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
28 4-719-686-31
ﾂｷﾞﾃ
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L04-M5)
UNION, JOINT ELBOW(KQ2L04-M5)
2
KQ2L04-M5, SMC
29 4-719-686-41
ﾂｷﾞﾃ
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L06-M5)
UNION, JOINT ELBOW(KQ2L06-M5)
6
KQ2L06-M5, SMC
30 4-720-189-01
ﾂｷﾞﾃ
ﾁ
-
ｽﾞ
(KQ2T04-00)
JOINT, JOINT TEE (KQ2T04-00)
2
KQ2T04-00, SMC
31 4-720-189-11
ﾂｷﾞﾃ
ﾁ
-
ｽﾞ
(KQ2T06-00)
JOINT, JOINT TEE (KQ2T06-00)
1
KQ2T06-00, SMC
32 4-761-739-01
ｹ
-
ﾌﾞﾙ
ｵｻｴ
ｶﾗ
- (X
ｼﾞｸ
)
COLLAR, CABLE RETAINER(X AXIS)
4
33 4-761-755-01
ﾎﾞｳｼﾞﾝ
ｺﾞﾑ
(C-300-B-10X20)
RUBBER, DUST PROTECTION
4
C-300-B-10X20
34 4-761-758-01
ﾒｽ
ﾕﾆｵﾝ
(KQ2F12-03)
UNION, FEMALE (KQ2F12-03)
2
KQ2F12-03, SMC
35 4-761-761-01
ﾌﾞﾗﾝﾁ
(KQ2U08-03S)
BRANCH (KQ2U08-03S)
2
KQ2U08-03S, SMC
36 4-761-868-01
NOZZLE
ｼ
-
ﾙ
SEAL, NOZZLE
2
37 7-632-385-40
ﾎﾟﾘｳﾚﾀﾝﾁﾕ
-
ﾌﾞ
(TU0425B)2.5X4X12M
TUBE, POLYURETHAN (TU0425B)
7000
TU0425B, SMC
38 7-632-385-50
ﾎﾟﾘｳﾚﾀﾝ
ﾁﾕ
-
ﾌﾞ
(TU0604B) 4X6X3M
TUBE, POLYURETHAN (TU0604B)
4000
TU0604B, SMC
39 1-761-262-12
LS
ｷﾊﾞﾝ
ASSY
PC BOARD ASSY, LS
2
40 2-109-636-01
ｹ
-
ﾌﾞﾙ
ｵｻｴ
RETAINER, CABLE
1
41 2-693-602-01
ﾎﾞｳｼﾞﾝ
ｺﾞﾑ
RUBBER, DUST PROTECTION
2
42 2-693-603-02
ｲﾀ
ﾅﾂﾄ
NUT, PLATE
4
43 2-693-606-01
X
ｹ
-
ﾌﾞﾙ
ｵｻｴｲﾀ
RETAINER, X CABLE
2
44 2-693-610-01
ｺﾃｲ
ﾀﾝ
ｶﾅｸﾞ
(TKP 0450 KA)
BRACKET,FIXD (TKP 0450 KA)
1
TKP 0450 KA
45 2-693-611-01
ｲﾄﾞｳ
ﾀﾝ
ｶﾅｸﾞ
(TKP 0450 IA)
BRACKET,MOVE (TKP 0450 IA)
1
TKP 0450 IA
46 2-693-619-01
ﾃﾌﾛﾝ
ｼ
-
ﾄ
(A)
SHEET (A), TEFLON
1
47 2-693-619-11
ﾃﾌﾛﾝ
ｼ
-
ﾄ
(B)
SHEET (B), TEFLON
1
48 2-693-629-01
ｺﾈｸﾀ
-
ﾁﾕｳｹｲ
ﾌﾟﾚ
-
ﾄ
PLATE, CONNECTOR RELAY
1
49 2-693-633-01
ｹ
-
ﾌﾞﾙ
ﾍﾞﾔ
(TKP0450 58B 50R 14L
BARE (TKP0450 58B 50R 14L)
1
TKP0450 58B 50R 14L
50 2-693-634-01
ﾌｲ
-
ﾄﾞ
ｶﾊﾞ
-
COVER, FEED
1
51 2-693-635-01
ｹ
-
ﾌﾞﾙ
ﾍﾞｱ
ｶﾞｲﾄﾞ
GUIDE, CABLE BARE
1
52 2-693-661-01
ﾍﾂﾄﾞ
ｺﾈｸﾀ
-
ﾁﾕｳｹｲ
ﾌﾟﾚ
-
ﾄ
PLATE, HEAD CONNECTOR RELAY
1
53 2-693-665-04
ﾍﾂﾄﾞ
ｺﾈｸﾀ
-
ﾌﾟﾚ
-
ﾄ
PLATE, HEAD CONNECTOR
1
4-4
4
中継ユニット
RELAY UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
54 2-698-399-02
ｺﾞｸ
ﾃｲﾄｳ
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(CBST*
CAP SCREW, EXTRA LOW HEAD
4
55 3-197-060-01
ﾃﾌﾛﾝ
ｼ
-
ﾄ
(C)
SHEET (C), TEFLON
1
56 3-213-369-01
Y
ｹ
-
ﾌﾞﾙ
ｵｻｴ
ﾍﾞ
-
ｽ
BASE, Y CABLE RETAINER
1
57 3-288-074-01
ﾍﾂﾄﾞ
ｺﾈｸﾀ
-
ｶﾊﾞ
-
COVER, HEAD CONNECTOR
1
58 3-288-092-01
ｹ
-
ﾌﾞﾙ
ﾁﾕｳｹｲ
ﾌﾟﾚ
-
ﾄ
PLATE, CABLE RELAY
1
59 4-706-724-02
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X4SUS)
BOLT (M3X4SUS), HEXAGON SOCKET
12
M3X4SUS
60 4-706-724-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X6)
BOLT (M3X6), HEXAGON SOCKET
4
M3X6
61 4-706-725-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
8
M4X8
62 4-706-725-05
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X20SUS)
BOLT (M4X20SUS),HEXAGON SOCKET
2
M4X20SUS
63 4-706-725-31
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X30)
BOLT (M4X30), HEXAGON SOCKET
4
M4X30
64 4-706-725-51
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X6)
BOLT (M4X6), HEXAGON SOCKET
4
M4X6
65 4-706-726-31
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X10)
BOLT (M5X10), HEXAGON SOCKET
4
M5X10
66 4-706-740-21
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X8)
BOLT (M6X8), HEXAGON SOCKET
6
M6X8
67 4-720-755-01
ｲﾄﾞｳ
ﾔｼﾞﾙｼ
ｼ
-
ﾙ
(
ｼﾖｳ
)
SEAL, MOVE ARROW MARK (SMALL)
1
68 4-720-769-01
ｽﾄﾚ
-
ﾄ
(KQ2H06-00)
STRAIGHT (KQ2H06-00)
1
KQ2H06-00, SMC
69 4-720-769-21
ｽﾄﾚ
-
ﾄ
(KQ2H08-00)
STRAIGHT (KQ2H08-00)
2
KQ2H08-00, SMC
70 4-761-739-01
ｹ
-
ﾌﾞﾙ
ｵｻｴ
ｶﾗ
- (X
ｼﾞｸ
)
COLLAR, CABLE RETAINER(X AXIS)
2
71 4-761-747-01
ｹ
-
ﾌﾞﾙ
ｵｻｴ
ｶﾗ
- (Y
ｼﾞｸ
)
COLLAR, CABLE RETAINER(Y AXIS)
4
72 4-761-755-01
ﾎﾞｳｼﾞﾝ
ｺﾞﾑ
(C-300-B-10X20)
RUBBER, DUST PROTECTION
1
C-300-B-10X20
73 7-681-000-11
+K M4X6
SCREW +K M4X6
3
+K M4X6
74 7-682-950-01
+PSW 3X12
SCREW +PSW 3X12
8
+PSW 3X12
75 7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
4
W 4, MIDDLE
76 7-688-005-11
W 5, MIDDLE
W 5, MIDDLE
4
W 5, MIDDLE
5-1-1
5-1
コンベアユニット（左側）
CONVEYANCE UNIT (L), G
28
9
34
34
49
59
23
61
8
59
49
24
34
49
17
49
49
31
26
19
20
11
19
16
27
68
21
29
6236
12
25
34
51
27
18
35
53
36
62
30
22
34
68
15
37
22
34
7
52
41
74
33
14
13
34
55
33
80
4
4
6
7
3
5
30
6236
77
33
73
47
46
54
45
44
78
57
50
1072
37
12
34
41
31
67
49
49
49
32 56
58
35
77
66
63
32
56
58
17
49
49
49
49
49
49
12
37
77
49
43
69
79
