4-1
4
中継ユニット
RELAY UNIT
76
65
48
59
58
66
59
57
39
60
50
54
67
74
43
63
75
71
41
42
44
75
61
42
45
46
49
55
47
41
63
75
43
53
61
71
64
56
62
40
72
70
21
11
12
3
20
22
2
22
1
23
18
29
20
37
28
38
29
51
73
31
24
5
4
36
25
19
12
3
11
19
30
31
13
30
34
35
19
26
17
32
33
27
25
14
15
16
19
36
23
23
75
35
27
17
32
25
22
23
29
1
20
21
33
26
23
10
23
10
4-2
4
中継ユニット
RELAY UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 1-480-815-11
(S)
ﾃﾞﾝｼﾞﾍﾞﾝ
ASSY (VQZ115R)
RELAY ASSY, (S) (VQZ115R)
2
VQZ115R
2 1-480-830-11
(S)
ﾊﾞﾙﾌﾞ
ASSY (SYJ512)
VALVE ASSY, (S) (SYJ512)
2
SYJ512
3 2-022-773-01
ﾃｲﾄｳ
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(CBSS4-10)
BOLT, HEXAGON SOCKET (CBSS4-10
8
CBSS4-10
4 2-689-707-01
ｾｲﾐﾂ
ｹﾞﾝｱﾂﾍﾞﾝ
(IR-1000-01BG)
DECOMPRESSION (IR-1000-01BG)
1
IR-1000-01BG
5 2-689-708-01
ｹﾞﾝｱﾂﾍﾞﾝ
ﾌﾞﾗｹﾂﾄ
(1)
BRACKET (1), DECOMPRESSION
1
6 2-689-710-01
ﾊﾞﾙﾌﾞ
ﾌﾞﾗｹﾂﾄ
(2)
BRACKET (2), VALVE
1
7 2-689-711-02
Y
ｺﾃｲ
ﾁﾕｳｹｲ
ﾌﾟﾚ
-
ﾄ
(1)
PLATE (1), Y FIXED RELAY
2
9 2-689-713-02
Y
ｺﾃｲ
ﾍﾞｱ
ｻﾎﾟ
-
ﾄ
(1)
SUPPORT (1), Y FIXED BARE
2
10 3-295-106-01
Y
ｺﾃｲ
ﾍﾞｱ
ｻﾎﾟ
-
ﾄ
(2)
SUPPORT (2), Y FIXED BARE
2
11 2-887-481-02
Y
ｹ
-
ﾌﾞﾙ
ｶﾞｲﾄﾞ
GUIDE, Y CABLE
2
12 2-887-482-02
Y
ｹ
-
ﾌﾞﾙ
ｼﾁﾕｳ
POST, Y CABLE
8
13 2-918-766-01
ﾕﾆｵﾝ
ﾜｲ
(KQ2U06-00)
UNION Y (KQ2U06-00),
1
KQ2U06-00, SMC
14 3-094-750-01
ﾚｷﾞﾕﾚ
-
ﾀ
-
ﾌﾞﾗｹﾂﾄ
BRACKET, REGULATOR
1
15 3-100-351-01
ｾｲﾐﾂ
ﾚｷﾞﾕﾚ
-
ﾀ
(IR1000-01-B)
REGULATOR (IR1000-01-B)
1
IR1000-01-B
16 3-100-352-01
ｱﾂﾘﾖｸｹｲ
(G33-2-01)
GAUGE (G33-2-01), PRESSUER
1
G33-2-01
17 3-213-232-01
Y
ｹ
-
ﾌﾞﾙ
ｵｻｴｲﾀ
(2)
RETAINER (2), Y CABLE
2
18 3-277-348-01
ﾊﾞﾙﾌﾞ
ﾌﾞﾗｹﾂﾄ
(F)
BRACKET (F), VALVE
1
19 4-701-253-01
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQL06-01S)
UNION (KQL06-01S), ELBOW
4
KQL06-01S, SMC
20 4-701-306-01
ｻｲﾚﾝｻ
- (AN120-M5)
SILENCER (AN120-M5)
4
AN120-M5, SMC
21 4-706-519-01
ﾊｰﾌ
ﾕﾆｵﾝ
(KQH06-M5)
UNION (KQH06-M5), HALF
2
KQH06-M5, SMC
22 4-706-724-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X5)
BOLT (M3X5), HEXAGON SOCKET
12
M3X5
23 4-706-725-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
9
M4X8
24 4-706-725-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X10)
BOLT (M4X10), HEXAGON SOCKET
2
M4X10
25 4-706-725-51
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X6)
BOLT (M4X6), HEXAGON SOCKET
6
M4X6
26 4-706-725-81
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X18)
BOLT (M4X18), HEXAGON SOCKET
4
M4X18
27 4-706-726-31
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X10)
BOLT (M5X10), HEXAGON SOCKET
8
M5X10
4-3
4
中継ユニット
RELAY UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
28 4-719-686-31
ﾂｷﾞﾃ
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L04-M5)
UNION, JOINT ELBOW(KQ2L04-M5)
2
KQ2L04-M5, SMC
29 4-719-686-41
ﾂｷﾞﾃ
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L06-M5)
UNION, JOINT ELBOW(KQ2L06-M5)
6
KQ2L06-M5, SMC
30 4-720-189-01
ﾂｷﾞﾃ
ﾁ
-
ｽﾞ
(KQ2T04-00)
JOINT, JOINT TEE (KQ2T04-00)
2
KQ2T04-00, SMC
31 4-720-189-11
ﾂｷﾞﾃ
ﾁ
-
ｽﾞ
(KQ2T06-00)
JOINT, JOINT TEE (KQ2T06-00)
1
KQ2T06-00, SMC
32 4-761-739-01
ｹ
-
ﾌﾞﾙ
ｵｻｴ
ｶﾗ
- (X
ｼﾞｸ
)
COLLAR, CABLE RETAINER(X AXIS)
4
33 4-761-755-01
ﾎﾞｳｼﾞﾝ
ｺﾞﾑ
(C-300-B-10X20)
RUBBER, DUST PROTECTION
4
C-300-B-10X20
34 4-761-758-01
ﾒｽ
ﾕﾆｵﾝ
(KQ2F12-03)
UNION, FEMALE (KQ2F12-03)
2
KQ2F12-03, SMC
35 4-761-761-01
ﾌﾞﾗﾝﾁ
(KQ2U08-03S)
BRANCH (KQ2U08-03S)
2
KQ2U08-03S, SMC
36 4-761-868-01
NOZZLE
ｼ
-
ﾙ
SEAL, NOZZLE
2
37 7-632-385-40
ﾎﾟﾘｳﾚﾀﾝﾁﾕ
-
ﾌﾞ
(TU0425B)2.5X4X12M
TUBE, POLYURETHAN (TU0425B)
7000
TU0425B, SMC
38 7-632-385-50
ﾎﾟﾘｳﾚﾀﾝ
ﾁﾕ
-
ﾌﾞ
(TU0604B) 4X6X3M
TUBE, POLYURETHAN (TU0604B)
4000
TU0604B, SMC
39 1-761-262-12
LS
ｷﾊﾞﾝ
ASSY
PC BOARD ASSY, LS
2
40 2-109-636-01
ｹ
-
ﾌﾞﾙ
ｵｻｴ
RETAINER, CABLE
1
41 2-693-602-01
ﾎﾞｳｼﾞﾝ
ｺﾞﾑ
RUBBER, DUST PROTECTION
2
42 2-693-603-02
ｲﾀ
ﾅﾂﾄ
NUT, PLATE
4
43 2-693-606-01
X
ｹ
-
ﾌﾞﾙ
ｵｻｴｲﾀ
RETAINER, X CABLE
2
44 2-693-610-01
ｺﾃｲ
ﾀﾝ
ｶﾅｸﾞ
(TKP 0450 KA)
BRACKET,FIXD (TKP 0450 KA)
1
TKP 0450 KA
45 2-693-611-01
ｲﾄﾞｳ
ﾀﾝ
ｶﾅｸﾞ
(TKP 0450 IA)
BRACKET,MOVE (TKP 0450 IA)
1
TKP 0450 IA
46 2-693-619-01
ﾃﾌﾛﾝ
ｼ
-
ﾄ
(A)
SHEET (A), TEFLON
1
47 2-693-619-11
ﾃﾌﾛﾝ
ｼ
-
ﾄ
(B)
SHEET (B), TEFLON
1
48 2-693-629-01
ｺﾈｸﾀ
-
ﾁﾕｳｹｲ
ﾌﾟﾚ
-
ﾄ
PLATE, CONNECTOR RELAY
1
49 2-693-633-01
ｹ
-
ﾌﾞﾙ
ﾍﾞﾔ
(TKP0450 58B 50R 14L
BARE (TKP0450 58B 50R 14L)
1
TKP0450 58B 50R 14L
50 2-693-634-01
ﾌｲ
-
ﾄﾞ
ｶﾊﾞ
-
COVER, FEED
1
51 2-693-635-01
ｹ
-
ﾌﾞﾙ
ﾍﾞｱ
ｶﾞｲﾄﾞ
GUIDE, CABLE BARE
1
52 2-693-661-01
ﾍﾂﾄﾞ
ｺﾈｸﾀ
-
ﾁﾕｳｹｲ
ﾌﾟﾚ
-
ﾄ
PLATE, HEAD CONNECTOR RELAY
1
53 2-693-665-04
ﾍﾂﾄﾞ
ｺﾈｸﾀ
-
ﾌﾟﾚ
-
ﾄ
PLATE, HEAD CONNECTOR
1
