13-13-1 13-13 ＳＥＲＶＯ ユニット／トレイ SERVO UNIT / TRAY 23 29 12 14 13 14 13 8 29 26 21 2 29 9 7 17 29 6 4 11 11 29 22 27 28 10 3 16 18 30 1 15 29 15 29 20 5 24 22 10 29 29 29 25 29 29 29 19 22 3
13-12-2
13-12
ＥＸ２ ＩＯ分離ユニット
IO SEPARATE UNIT / EX2
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 1-789-716-11
EX2 IO
ﾌﾞﾝﾘｷﾊﾞﾝ
ASSY
EX2 IO SEPARATE BOARD ASSY
1
2 3-196-591-02
EX IO
ｺﾃｲﾌﾞﾗｹﾂﾄ
BRACKET, EX IO FIXED
1
13-13-1
13-13
ＳＥＲＶＯ ユニット／トレイ
SERVO UNIT / TRAY
23
29
12
14
13
14
13
8
29
26
21
2
29
9
7
17
29
6
4
11
11
29
22
27
28
10
3
16
18
30
1
15
29
15
29
20
5
24
22
10
29
29
29
25
29
29
29
19
22
3
13-13-2
13-13
ＳＥＲＶＯ ユニット／トレイ
SERVO UNIT / TRAY
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 1-243-498-11
ﾌﾈﾝｾｲﾏｷｾﾝﾃｲｺｳ
(GZG150W500J)1
RES, NONFLAMMABLE WIREWOUND
2
GZG150W500J
2 1-474-080-11
ﾓ
-
ﾀ
-
ﾄﾞﾗｲﾊﾞ
(ASD12ACME)
DRIVER, MOTOR (ASD12ACME)
1
ASD12ACME
3 1-478-864-11
AC
ｻ
-
ﾎﾞ
ﾊﾟﾂｸ
(SGDS04A12AY511)
SERVO PACK (SGDS04A12AY511)
2
SGDS04A12AY511
4 1-755-538-11
ﾘﾚ
- (RU4SDD24)
RELAY (RU4SDD24)
1
RU4SDD24
5 1-755-539-11
ﾘﾚ
-
ｿｹﾂﾄ
(SY4S05B)
SOCKET, RELAY (SY4S05B)
1
SY4S05B
6 1-755-546-11
ｺﾝﾀｸﾀ
(SDN11DC24V 1A)
CONTACTOR (SDN11DC24V 1A)
2
SDN11DC24V 1A
7 1-780-414-11
ﾀﾝｼﾀﾞｲ
(BNH15MW)
TERMINAL BOARD (BNH15MW)
20
BNH15MW
8 1-789-573-11
TRAY LS BOARDG
TRAY LS BOARDG
1
9 1-821-843-11
ﾘﾝｸ
ﾀ
-
ﾐﾈ
-
ﾀ
(JEPMCW6022E)
TERMINATOR (JEPMCW6022E)
1
JEPMCW6022E
10 1-835-002-21
ｻ
-
ﾎﾞ
ｹ
-
ﾌﾞﾙ
(JEPMCW6002A5E)
CABLE (JEPMCW6002A5E)
2
JEPMCW6002A5E
11 2-149-018-01
ﾎｼﾞ
ｶﾅｸﾞ
(SFA101)
BRACKET, HOLDING (SFA101)
1
SFA101
12 2-584-265-01
ﾀﾝｼﾀﾞｲ
ｶﾊﾞ
- (BNC230)
COVER (BNC230), TERMINAL TABLE
1
BNC230
13 2-679-204-01
ﾄﾒ
ｶﾅｸﾞ
(BNL6)
BRACKET (BNL6), STOPPER
2
BNL6
14 2-915-968-01
ｴﾝﾄﾞ
ﾌﾟﾚ
-
ﾄ
(BNE15W)
PLATE, END
2
BNE15W
15 3-282-767-03
ｶｲｾｲ
ﾃｲｺｳ
ﾌﾞﾗｹﾂﾄ
BRACKET, RESISTOR
1
16 3-282-768-03
ﾃﾞﾝｿｳ
ﾍﾞ
-
ｽ
ﾌﾟﾚ
-
ﾄ
PLATE, ELECTRICAL BASE
1
17 3-282-769-02
ﾃﾞﾝｿｳ
ｺﾈｸﾀ
ﾌﾞﾗｹﾂﾄ
BRACKET, ELECTRICAL CONNECTOR
1
18 3-283-017-02
ｻ
-
ﾎﾞ
ﾊﾟﾂｸ
ﾌﾞﾗｹﾂﾄ
ﾄﾘﾂｹ
ﾌﾚ
-
ﾑ
FRAME, SERVO PACK BRACKET
1
19 3-283-018-02
ｻ
-
ﾎﾞ
ﾊﾟﾂｸ
ﾌﾞﾗｹﾂﾄ
(1)
BRACKET (1), SERVO PACK
1
20 3-283-019-02
ｻ
-
ﾎﾞ
ﾊﾟﾂｸ
ﾌﾞﾗｹﾂﾄ
(2)
BRACKET (2), SERVO PACK
1
21 3-283-020-02
ｻ
-
ﾎﾞ
ﾊﾟﾂｸ
ﾌﾞﾗｹﾂﾄ
(3)
BRACKET (3), SERVO PACK
1
22 3-283-021-01
ｻ
-
ﾎﾞ
ﾊﾟﾂｸ
ﾌﾞﾗｹﾂﾄ
ｲﾁｷﾞﾒ
ﾋﾟﾝ
PIN, PACK BRACKET POSITIONING
1
23 3-294-647-01
ｻ
-
ﾎﾞ
ﾕﾆﾂﾄ
ｳｴ
ｶﾊﾞ
- (
ﾄﾚｲ
ﾕﾆﾂﾄ
)
COVER (TRAY UNIT)
1
24 4-701-543-01
ｱ
-
ｽ
ﾒｲﾊﾞﾝ
AMS550
LABEL (AMS550), GROUND
1
AMS550
25 4-706-153-01
ｶﾄﾞ
ｽﾍﾟ
-
ｻ
(KGLS4S)
SPACER (KGLS4S), CARD
4
KGLS4S
26 7-621-259-45
+P 2.6X6
SCREW +P 2.6X6
4
