3-5-1 3-5 Ｂヘッドユニット（３／４） HEAD UNIT, B (3/4) 2 4 5 7 8 10 14 15 16 17 18 19 20 21 23 24 25 27 28 29 31 32 33 34 35 12 36 37 38 39 40 42 43 44 45 46 47 48 49 51 53 22 5 11 5 11 28 29 30 29 28 28 5 31 10 45 52 26 13 A B B A …
3-4-4
3-4
Ｂヘッドユニット（２／４）
HEAD UNIT, B (2/4)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
54 4-719-916-01
ﾍﾞｱﾘﾝｸﾞ
(7302CTDBC8P4)
BEARING (7302CTDBC8P4)
1
7302CTDBC8P4
55 4-719-917-01
ﾊﾟﾜ
-
ﾛﾂｸ
(PL015X019E)
LOCK, POWER (PL015X019E)
1
PL015X019E
56 4-719-918-11
O
ﾘﾝｸﾞ
(
ﾐﾆ
ﾌﾘﾂｸ
P8)
O RING (MINIATURE FLICK P8)
2
MINIATURE FLICK P8
57 7-683-239-08
6
ｶｸ
ｱﾅ
ﾂｷ
ﾄﾒ
ﾈｼﾞ
H3X5
SCREW H3X5
2
58 7-683-245-08
ﾄﾒﾈｼﾞ
6
ｶｸｱﾅ
4X4,
ﾋﾗｻｷ
SET-SCT,HEX, 4X4,PLAT POINT
4
59 7-683-308-07
6
ｶｸﾎﾞﾙﾄ
3X16
BOLT,HEXAGON 3X16
2
60 7-688-003-01
W 3, SMALL
W 3, SMALL
6
61 7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
4
62 7-688-005-01
W 5, SMALL
W 5, SMALL
2
63 7-689-000-00
6
ｶｸｱﾅﾂｷ
ﾄﾒﾈｼﾞ
3X8,
ﾋﾗｻｷ
SET-SCT, HEX. 3X8 FLAT POINT
2
64 7-689-000-38
6
ｶｸｱﾅﾂｷ
ﾄﾒﾈｼﾞ
2.5X4
ﾋﾗｻｷ
SET-SCT, HEX. 2.5X4 FLAT POINT
18
3-5-1
3-5
Ｂヘッドユニット（３／４）
HEAD UNIT, B (3/4)
2
4
5
7
8
10
14
15
16
17
18
19
20
21
23
24
25
27
28
29
31
32
33
34
35
12
36
37
38
39
40
42
43
44
45
46
47
48
49
51
53
22
5
11
5
11
28
29
30
29
28
28
5
31
10
45
52
26
13
A
B
B
A
1
54
3-5-2
3-5
Ｂヘッドユニット（３／４）
HEAD UNIT, B (3/4)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 A-1376-888-A
REC
ﾌﾟﾗﾝｼﾞﾔ
KIT
SOLENOID KIT, REC
1
2 1-455-007-13
REC
ﾌﾟﾗﾝｼﾞﾔ
(L)
PLUNGER, REC (L)
2
4 4-718-721-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M2X3 SUS)
BOLT, HEXAGON SOCKET(M2X3 SUS)
8
M2X3 SUS
5 4-718-721-04
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M2X6 SUS)
BOLT, HEXAGON SOCKET(M2X6 SUS)
2
M2X6 SUS
7 1-417-874-11
ｷﾊﾞﾝ
ｶﾒﾗ
(B) (TS-336)
CAMERA, PC BOARD (B) (TS-336)
1
8 X-2187-322-1
H
ｼﾞｸ
ﾍﾞ
-
ｽ
ﾌﾟﾚ
-
ﾄ
(B) ASSY
PLATE (B) ASSY, H SHAFT BASE
1
10 1-480-834-11
(S)
ﾌｵﾄｾﾝｻ
ASSY (EE-SX771A)
SENSOR ASSY, (S) PHOTO (EE-SX*
2
EE-SX771A, OMRON
11 1-480-811-11
(S)
ﾌｵﾄ
ｾﾝｻ
ASSY (PM-L24)
SENSOR ASSY, (S) PHOTO (PM-L2*
2
PM-L24, SUNX
12 1-478-890-12
ﾌｱｲﾊﾞ
(E32-D24R-2)
FIBER (E32-D24R-2)
1
E32-D24R-2
13 1-787-220-11
ｻ
-
ﾎﾞ
ﾓ
-
ﾀ
- (SGMAS-C2ACA21)
MOTOR, SERVO (SGMAS-C2ACA21)
1
SGMAS-C2ACA21
14 2-148-082-01
ﾐﾆﾁﾕｱ
ｶﾑ
ﾌｵﾛｱ
(CFS2.5)
FOLLOWER, MINIATURE CAM (CFS2*
1
CFS2.5
15 2-514-330-01
ﾍｲｺｳﾋﾟﾝ
(
ﾔｷｲﾚ
) (
ﾌｱｲ
4X6H7)
PIN (HARDENING) (DIA. 4X6H7)
1
DIA. 4X6H7
16 3-278-120-01
ﾌﾟﾗﾝｼﾞﾔ
-
ﾌﾞﾗｹﾂﾄ
ﾌﾞﾛﾂｸ
BLOCK, SOLENOID BRACKET
1
17 3-278-121-01
ﾌﾟﾗﾝｼﾞﾔ
ﾌﾞﾗｹﾂﾄ
(B)
BRACKET (B), SOLENOID
1
18 3-278-146-01
H
ｼﾞｸ
ｾﾝｻ
ﾌﾞﾛﾂｸ
BLOCK, H SHAFT SENSOR
1
19 3-278-148-01
ﾌﾟﾗﾝｼﾞﾔ
ｶﾊﾞ
-
COVER, SOLENOID
1
20 3-278-149-01
ﾗﾂｸ
(B)
RACK (B)
1
21 3-278-150-01
LM
ｶﾞｲﾄﾞ
(SRS9MUU+70LM)
GUIDE (SRS9MUU+70LM), LM
1
SRS9MUU+70LM
22 3-278-151-01
ﾚ
-
ﾙ
ﾎﾙﾀﾞ
(B)
HOLDER (B), RAIL
1
23 3-278-178-01
ｶﾒﾗ
ｻﾎﾟ
-
ﾄ
SUPPORT, CAMERA
1
24 3-278-179-01
H
ｼﾞｸ
ﾚﾊﾞ
-
ﾍﾞ
-
ｽ
(B)
BASE (B), H SHAFT LEVER
1
25 3-279-323-01
H
ｼﾞｸ
ｾﾝｻ
ﾄﾞｸﾞ
(B)
DOG (B), H SHAFT SENSOR
1
26 4-706-724-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X5)
BOLT (M3X5), HEXAGON SOCKET
8
M3X5
27 4-706-724-02
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X4SUS)
BOLT (M3X4SUS), HEXAGON SOCKET
6
M3X4SUS
28 4-706-724-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X6)
BOLT (M3X6), HEXAGON SOCKET
14
M3X6
29 4-706-724-21
ﾛﾂｶﾅ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X8)
BOLT (M3X8), HEXAGON SOCKET
19
M3X8
