si-g200bb_doc_par_nothing_xx_3rd_20091207_level01.pdf - 第59页
5-2-2 5-2 コンベアユニット（右側） CONVEYANCE UNIT (R), G ｲﾗｽﾄ番号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 1 2-148-232-01 ｶﾄﾞｳ ﾍﾞ - ｽ (R) BASE (R), MOVABLE 1 2 4-705-597-31 ﾍｲｺｳ ﾋﾟﾝ ( ﾌｱｲ 5)…
5-2-1
5-2
コンベアユニット（右側）
CONVEYANCE UNIT (R), G
27
55
19
36
55
55
55
55
10
15
22
38
21
66
67
82
50
62
62
49
62
54
53
6
7
8
5
4
3
4
48
45
60
61
75
10
86
38
10
47
38
59
58
51
52
798081
88
65
57
24
49
62
62
49
62
62
49
62
50
50
50
72
40
84
76
13
26
77
17
29
44
71
30
89
30
55
55
31
31
64
69
55
55
55
55
55
55
46
26
11
43
66
67
82
12
77
78
88
44
71
29
18
18
28
71
44
55
86
38
2
1
74
68
55
70
64
69
14
68
20
35
36
9
25
5-2-2
5-2
コンベアユニット（右側）
CONVEYANCE UNIT (R), G
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 2-148-232-01
ｶﾄﾞｳ
ﾍﾞ
-
ｽ
(R)
BASE (R), MOVABLE
1
2 4-705-597-31
ﾍｲｺｳ
ﾋﾟﾝ
(
ﾌｱｲ
5)
PIN (DIA. 5), PARALLEL
1
DIA. 5
3 2-689-930-01
ｺﾃｲ
ﾍﾞ
-
ｽ
(R) +50
BASE (R) +50, FIXED
1
4 4-705-597-11
ﾍｲｺｳ
ﾋﾟﾝ
(
ﾌｱｲ
5)
PIN (DIA. 5), PARALLEL
2
DIA. 5
5 4-705-597-31
ﾍｲｺｳ
ﾋﾟﾝ
(
ﾌｱｲ
5)
PIN (DIA. 5), PARALLEL
1
DIA. 5
6 1-480-826-11
(S)
ｿﾚﾉｲﾄﾞ
ﾊﾞﾙﾌﾞ
ASSY (VQZ2150)
VALVE ASSY, (S) SOLENOID (VQZ*
2
VQZ2150
7 1-480-827-11
(S)
ｿﾚﾉｲﾄﾞ
ﾊﾞﾙﾌﾞ
ASSY (VQZ2250)
VALVE ASSY, (S) SOLENOID (VQZ*
1
VQZ2250
8 1-480-802-11
(S)
ｺｳﾃﾞﾝｾﾝｻ
ASSY (E3S-LS3N)
SENSOR ASSY, (S) (E3S-LS3N)
1
E3S-LS3N, OMRON
9 1-480-803-11
(S)
ﾋﾞ
-
ﾑ
ｾﾝｻ
ASSY (CX-424)
SENSOR ASSY, (S) BEAM (CX-424)
1
CX-424, SUNX
10 1-480-805-11
(S) DC
ﾓ
-
ﾀ
- ASSY (AXH230K-10)
MOTOR ASSY, (S) DC (AXH230K-10
3
AXH230K-10,
ORIENTAL MOTOR
11 2-109-823-01
ﾌﾗﾂﾄ
ｹ
-
ﾌﾞﾙ
ﾌﾞﾗｹﾂﾄ
(R)
BRACKET (R), FLAT CABLE
1
12 2-109-824-01
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
(3)
CLAMP (3), CABLE
1
13 2-109-825-01
ｹ
-
ﾌﾞﾙ
ｸﾗﾝﾌﾟ
(4)
CLAMP (4), CABLE
1
14 2-148-111-02
ﾌﾚ
-
ﾑ
(B)
FRAME (B)
1
15 2-149-044-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X18 SUS)
BOLT, HEXAGON SOCKET (M6X18SUS
4
M6X18 SUS
- 2-176-600-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X22 SUS)
BOLT (M3X22 SUS), SOCKET
2
M3X22 SUS
17 2-592-195-01
ﾀｲﾐﾝｸﾞ
ﾍﾞﾙﾄ
(562.5-1.5GT-2.5)
BELT (562.5-1.5GT-2.5), TIMING
1
562.5-1.5GT-2.5
18 4-127-551-01
ﾋﾗ
ﾍﾞﾙﾄ
(SE-GS-SBC)
BELT, FLAT (SE-GS-SBC)
2
SE-GS-SBC
19 2-689-860-02
ｷﾊﾞﾝ
ｶﾞｲﾄﾞ
(A)
GUIDE (A), PC BOARD
1
20 2-689-860-12
ｷﾊﾞﾝ
ｶﾞｲﾄﾞ
(A)
GUIDE (A), PC BOARD
1
21 2-694-051-01
ｶﾞｲﾄ
(LWFF42C1R450S1E076)
GUIDE (LWFF42C1R450S1E076)
1
LWFF42C1R450S1E076
22 2-694-055-01
D
ﾈｼﾞ
(TMR20-RX555/TTM20-R)
SCREW (TMR20-RX555/TTM20-R), D
1
TMR20-RX555/TTM20-R
- 2-694-057-01
ｷﾊﾞﾝ
ﾊﾝﾆﾕｳ
ｾﾝｻ
ﾌﾞﾗｹﾂﾄ
(1)(A)
BRACKET (1)(A)
1
24 2-694-057-11
ｷﾊﾞﾝ
ﾊﾝﾆﾕｳ
ｾﾝｻ
ﾌﾞﾗｹﾂﾄ
(1)(B)
BRACKET (1)(B)
1
25 2-696-148-01
ｹﾞﾝｱﾂﾍﾞﾝ
(ARJ210-M5-X251)
DECOMPRESSION (ARJ210-M5-X251)
1
ARJ210-M5-X251, SMC
26 2-890-881-01
ｺﾞﾑ
ｼ
-
ﾄ
(UNSETA2-80-30)
SHEET (UNSETA2-80-30), RUBBER
2
UNSETA2-80-30
5-2-3
5-2
コンベアユニット（右側）
CONVEYANCE UNIT (R), G
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
27 3-106-480-01
ｾﾝｻ
ﾌﾞﾗｹﾂﾄ
(5)
BRACKET (5), SENSOR
1
28 3-276-517-01
O
ﾘﾝｸﾞ
(51G
ｸﾄﾞｳ
)
O RING (51G DRIVING)
1
51G DRIVING
29 3-276-518-01
O
ﾘﾝｸﾞ
(49G
ﾊﾝｿｳ
)
O RING (49G CONVEYANCE)
2
49G CONVEYANCE
30 4-700-061-11
ﾍﾞｱﾘﾝｸﾞ
(6000ZZNR)
BEARING (6000ZZNR)
2
6000ZZNR, NTN
31 4-702-261-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ｻﾗ
ﾎﾞﾙﾄ
(M3X4)
BOLT (M3X4), HEXAGON SOCKET
4
M3X4
- 4-706-724-05
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X16SUS)
BOLT (M3X16SUS),HEXAGON SOCKET
8
M3X16SUS
- 4-706-724-08
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X30SUS)
BOLT (M3X30SUS),HEXAGON SOCKET
2
M3X30SUS
- 4-706-724-09
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X35SUS)
BOLT (M3X35SUS),HEXAGON SOCKET
2
M3X35SUS
35 4-706-724-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X6)
BOLT (M3X6), HEXAGON SOCKET
16
M3X6
36 4-706-724-21
ﾛﾂｶﾅ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X8)
BOLT (M3X8), HEXAGON SOCKET
2
M3X8
- 4-706-725-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
6
M4X8
38 4-706-725-04
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X16SUS)
BOLT (M4X16SUS),HEXAGON SOCKET
18
M4X16SUS
- 4-706-725-05
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X20SUS)
BOLT (M4X20SUS),HEXAGON SOCKET
8
M4X20SUS
40 4-706-725-12
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X12SUS)
BOLT (M4X12SUS),HEXAGON SOCKET
6
M4X12SUS
- 4-706-725-21
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X22)
BOLT (M4X22), HEXAGON SOCKET
1
M4X22
- 4-706-725-41
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X50)
BOLT (M4X50), HEXAGON SOCKET
10
M4X50
43 4-706-725-51
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X6)
BOLT (M4X6), HEXAGON SOCKET
3
M4X6
44 4-706-725-61
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
3
M4X15
45 4-706-725-71
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X40)
BOLT (M4X40), HEXAGON SOCKET
4
M4X40
46 4-706-740-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X25)
BOLT (M6X25), HEXAGON SOCKET
4
M6X25
47 4-706-740-04
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X10SUS)
BOLT (M6X10SUS),HEXAGON SOCKET
1
M6X10SUS
48 4-707-030-21
ﾊｲｶﾝﾖｳ
ﾃ
-
ﾊﾟ
-
ｽｸﾘﾕ
-
ﾌﾟﾗｸﾞ
(MSWT2)
PLUG, TAPER SCREW (MSWT2)
2
MSWT2
49 4-708-047-01
ｽﾋﾟ
-
ﾄﾞ
ｺﾝﾄﾛ
-
ﾗ
(AS1001F-04-GR)
CONTROLLER (AS1001F-04), SPEED
4
AS1001F-04-GR, SMC
50 4-708-048-01
ﾕﾆｵﾝ
ﾜｲ
(KJU04-00)
UNION (Y) (KJU04-00)
4
KJU04-00, SMC
51 4-708-184-21
ｽﾍﾟ
-
ｽ
ｶﾗ
- (CLBI 10-17-17)
COLOR, SPACE (CLBI 10-17-17)
1
CLBI 10-17-17
52 4-713-509-11
ﾍﾞｱﾘﾝｸﾞ
(6201ZZNR)
BEARING (6201ZZNR)
1
6201ZZNR, NTN
