si-g200bb_doc_par_nothing_xx_3rd_20091207_level01.pdf - 第80页
6-1 6 フィーダーステ ージキット STAGE KI T, FEEDER 24 T B A C B A B A 1 20 26 6 16 28 16 4 28 3 16 28 16 28 26 20 5 1 24 18 17 19 18 25 9 25 19 18 17 9 18 2 27 21 13 27 21 13 2 8 18 31 32 30 7
5-6-2
5-6
ベルト押さえＡＳＳＹ
RETAINER ASSY, BELT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 3-875-210-01
ｹ
-
ﾌﾞﾙ
ﾌﾞﾗｹﾂﾄ
(L)
BRACKET (L), CABLE
1
2 3-875-210-11
ｹ
-
ﾌﾞﾙ
ﾌﾞﾗｹﾂﾄ
(R)
BRACKET (R), CABLE
1
3 3-875-211-01
ﾊｲｾﾝ
ﾍﾞ
-
ｽ
BASE, WIRING
1
4 3-875-212-01
ﾊｲｾﾝ
ｶﾊﾞ
-
COVER, WIRING
1
5 3-875-213-01
ﾍﾞｱﾘﾝｸﾞ
ｼﾁﾕｳ
SUPPORT, BEARING
2
6 3-875-214-01
ﾍﾞﾙﾄ
ﾛ
-
ﾗ
-
ROLLER, BELT
4
7 3-875-215-01
ﾍﾞｱﾘﾝｸﾞ
ｶﾗ
-
COLLAR, BEARING 2
2
8 3-875-216-01
ﾍﾞｱﾘﾝｸﾞ
(F696ZZ1)
BEARING (F696ZZ1)
8
F696ZZ1, NSK
9 4-706-725-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
6
10 4-706-725-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X10)
BOLT (M4X10), HEXAGON SOCKET
4
6-1
6
フィーダーステージキット
STAGE KIT, FEEDER
24
T
B
A
C
B
A
B
A
1
20
26
6
16
28
16
4
28
3
16
28
16
28
26
20
5
1
24
18
17
19
18
25
9
25
19
18
17
9
18
2
27
21
13
27
21
13
2
8
18
31
32
30
7
6-2
6
フィーダーステージキット
STAGE KIT, FEEDER
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 1-480-806-11
(S)
ﾌｵﾄ
ｾﾝｻ
ASSY (LR-9922-1)
SENSOR ASSY, (S) PHOTO (LR-99*
2
LR-9922-1
2 2-108-863-01
ｼﾕ
-
ﾄ
ﾌﾞﾗｹﾂﾄ
BRACKET, SHOOT
2
3 2-689-731-01
ｾﾝｻ
-
ﾍﾞ
-
ｽ
(F-R)
BASE (F-R), SENSOR
1
4 2-689-732-01
ｾﾝｻ
-
ﾍﾞ
-
ｽ
(F-L)
BASE (F-L), SENSOR
1
5 2-689-733-01
ｾﾝｻ
-
ﾍﾞ
-
ｽ
(B-R)
BASE (B-R), SENSOR
1
6 2-689-734-01
ｾﾝｻ
-
ﾍﾞ
-
ｽ
(B-L)
BASE (B-L), SENSOR
1
7 2-689-735-02
ｼﾕ
-
ﾄ
ｼﾀ
(F)
SHOOT (LOWER (F))
1
8 2-689-736-02
ｼﾕ
-
ﾄ
ｼﾀ
(R)
SHOOT (LOWER (R))
1
9 2-893-378-01
ｼﾕ
-
ﾄ
(SUS)
SHOOT (SUS)
C 2
- 4-700-047-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾀﾝ
ﾎﾞﾙﾄ
(M3X6)
BOLT (M3X6), BUTTON
10
M3X6
- 4-700-048-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾀﾝ
ﾎﾞﾙﾄ
(M4X6)
BOLT (M4X6), BUTTON
22
M4X6
- 4-702-994-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾀﾝ
ﾎﾞﾙﾄ
(M6X8)
BOLT (M6X8), BUTTON
28
M6X8
13 4-706-725-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
16
M4X8
- 4-706-725-51
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X6)
BOLT (M4X6), HEXAGON SOCKET
2
M4X6
- 4-706-726-03
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X8SUS)
BOLT (M5X8SUS), HEXAGON SOCKET
4
M5X8SUS
16 4-706-726-31
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X10)
BOLT (M5X10), HEXAGON SOCKET
2
M5X10
17 4-719-770-02
ｱﾄﾞﾚｽ
ﾋﾖｳｼﾞﾊﾞﾝ
PLATE, ADRESS INDICATION
C 2
18 4-720-190-01
ｼﾞﾕｳｼﾞ
ｱﾅﾂｷ
ﾄﾗｽ
ｺﾈｼﾞ
(+T4X6)
SCREW (+T4X6), (HOLE) TRUSS
24
+T4X6
19 4-761-765-01
ｶｾﾂﾄ
ｳｷ
ﾎﾞｳｼﾊﾞﾝ
(F)
PLATE (F), FLOAT PREVENTION
C 2
20 7-623-208-22
SW 3,TYPE 2
SW 3,TYPE 2
8
SW 3,TYPE 2
21 7-623-210-22
SW 4,TYPE 2
SW 4,TYPE 2
32
SW 4,TYPE 2
- 7-681-000-45
+P M3X6
SCREW +P M3X6
8
+P M3X6
- 7-682-152-02
+P M3X16
SCREW +P M3X16
8
+P M3X16
24 7-682-153-01
+P 3X20
SCREW +P 3X20
8
+P 3X20
25 7-682-246-02
+K M3X5
SCREW +K M3X5
C 6
+K M3X5
26 7-684-013-08
N 3, TYPE 1
N 3, TYPE 1
4
N3, TYPE 1
